BD433: Description4 A, 32 V, NPN, Si, POWER TRANSISTOR, TO-225AA; CategoryDiscrete semiconductor The transistor; File Size65KB，3 Pages; ManufacturerCOMSET; Websitehttp://comset.halfin.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

BD433 Overview

4 A, 32 V, NPN, Si, POWER TRANSISTOR, TO-225AA

BD433 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	COMSET
package instruction	,
Reach Compliance Code	unknow
Maximum collector current (IC)	4 A
Configuration	Single
Minimum DC current gain (hFE)	85
Maximum operating temperature	150 °C
Polarity/channel type	NPN
Maximum power dissipation(Abs)	36 W
surface mount	NO
Nominal transition frequency (fT)	7 MHz

Preview

Download Datasheet

View All

NPN BD433 – BD435 – BD437

SILICON NPN POWER TRANSISTORS.

The BD433-BD435-BD437 are NPN Transistors mounted in Jedec TO-126 plastic package.

They are recommended for use in medium power linear and switching applications.

PNP complements are BD434-BD436-BD438.

Compliance to RoHS.

ABSOLUTE MAXIMUM RATINGS

Symbol

CBO

Ratings

Collector-Base Voltage (I

= 0)

BD433

BD435

BD437

BD433

BD435

BD437

Value

150

-65 to +150

Unit

CEO

EBO

Stg

Collector-Emitter Voltage (I

= 0)

Emitter-Base Voltage (I

= 0)

Collector Current

Collector Current Peak

Base Current

Total power Dissipation

Junction Temperature

Storage Temperature

°C

= 25°C

THERMAL CHARACTERISTICS

Symbol

thJ-c

thJ-a

Ratings

Thermal Resistance, Junction-Case

Thermal Resistance, Junction-ambient in free air

Value

3.5

100

Unit

°C/W

25/09/2012

COMSET SEMICONDUCTORS

1|3

BD433 Related Products

	BD433	BD435	BD437
Description	4 A, 32 V, NPN, Si, POWER TRANSISTOR, TO-225AA	4 A, 32 V, NPN, Si, POWER TRANSISTOR, TO-225AA	4 A, 45 V, NPN, Si, POWER TRANSISTOR, TO-126
Is it Rohs certified?	conform to	conform to	conform to
Maker	COMSET	COMSET	COMSET
Reach Compliance Code	unknow	unknow	unknow
Maximum collector current (IC)	4 A	4 A	4 A
Configuration	Single	Single	Single
Minimum DC current gain (hFE)	85	85	850
Maximum operating temperature	150 °C	150 °C	150 °C
Polarity/channel type	NPN	NPN	NPN
Maximum power dissipation(Abs)	36 W	36 W	36 W
surface mount	NO	NO	NO
Nominal transition frequency (fT)	7 MHz	7 MHz	3 MHz
