MCC
Micro Commercial Components
TM
omponents
20736 Marilla
Street Chatsworth
!"#
$
% !"#
BD882-R
BD882-O
BD882-Y
BD882-GR
Silicon
NPN epitaxial planer
Transistors
•
Features
Lead Free Finish/RoHS Compliant ("P" Suffix designates
RoHS Compliant. See ordering information)
Epoxy meets UL 94 V-0 flammability rating
Moisure Sensitivity Level 1
Marking: D882
C
•
•
•
Maximum Ratings @ 25
O
C Unless Otherwise Specified
Symbol
V
CEO
V
CBO
V
EBO
I
C
P
C
T
J
T
STG
Rating
Collector-Emitter Voltage
Collector-Base Voltage
Emitter-Base Voltage
Collector Current-Continuous
Collector Dissipation
Operating Junction Temperature
Storage Temperature
Rating
30
40
6
3
0.5
150
-55 to +150
Unit
V
V
V
A
W
Electrical Characteristics @ 25
O
C Unless Otherwise Specified
Symbol
V
(BR)CEO
V
(BR)CBO
V
(BR)EBO
I
CBO
I
CEO
I
EBO
h
FE
V
CE(sat)
V
BE(sat)
Parameter
Collector-Emitter Breakdown Voltage
(I
C
=10mAdc, I
B
=0)
Collector-Base Breakdown Voltage
(I
C
=100uAdc, I
E
=0)
Collector-Emitter Breakdown Voltage
(I
E
=100uAdc, I
C
=0)
Collector Cutoff Current
(V
CB
=40Vdc, I
E
=0)
Collector Cutoff Current
(V
CB
=30Vdc, I
B
=0)
Emitter Cutoff Current
(V
EB
=6Vdc, I
C
=0)
DC Current Gain
(I
C
=1Adc, V
CE
=2Vdc)
Collector-Emitter Saturation Voltage
(I
C
=2Adc, I
B
=0.2Adc)
Base-Emitter Saturation Voltage
(I
C
=2Adc, I
B
=0.2Adc)
Transition frequency
(V
CE
=5Vdc, f=10MHz, I
C
=0.1A)
Min
30
40
6
---
---
---
60
---
---
50
Typ
---
---
---
---
---
---
----
----
----
---
Max
---
---
---
1
10
1
400
0.5
1.5
---
Vdc
Vdc
MHz
Units
Vdc
Vdc
Vdc
uAdc
uAdc
uAdc
D
G
1
SOT-89
A
B
K
E
H
J
F
2
3
1.
BASE
2.
COLLETOR
3.
EMITTER
1.55
.061
25
f
t
REF.
CLASSIFICATION OF h
FE
Rank
Range
R
60-120
O
100-200
Y
160-320
GR
200-400
www.mccsemi.com
Revision:
A
1 of 3
2011/01/01
MCC
Ordering Information :
TM
Micro Commercial Components
Device
Part Number-TP
Packing
Tape&Reel;1Kpcs/Reel
***IMPORTANT NOTICE***
Micro Commercial Components Corp.
reserves the right to make changes without further notice to any product herein to
make corrections, modifications , enhancements , improvements , or other changes .
Micro Commercial Components
Corp .
does not assume any liability arising out of the application or use of any product described herein; neither does it
convey any license under its patent rights ,nor the rights of others . The user of products in such applications shall assume all
risks of such use and will agree to hold
Micro Commercial Components Corp .
and all the companies whose products are
represented on our website, harmless against all damages.
***LIFE SUPPORT***
MCC's products are not authorized for use as critical components in life support devices or systems without the express written
approval of Micro Commercial Components Corporation.
***CUSTOMER AWARENESS***
Counterfeiting of semiconductor parts is a growing problem in the industry. Micro Commercial Components (MCC) is taking
strong measures to protect ourselves and our customers from the proliferation of counterfeit parts. MCC strongly encourages
customers to purchase MCC parts either directly from MCC or from Authorized MCC Distributors who are listed by country on
our web page cited
below.
Products customers buy either from MCC directly or from Authorized MCC Distributors are genuine
parts, have full traceability, meet MCC's quality standards for handling and storage.
MCC will not provide any warranty
coverage or other assistance for parts bought from Unauthorized Sources.
MCC is committed to combat this global
problem and encourage our customers to do their part in stopping this practice by buying direct or from authorized
distributors.
www.mccsemi.com
Revision:
A
3 of 3
2011/01/01
