BFP181TW

Description
Silicon NPN Planar RF Transistor
CategoryDiscrete semiconductor    The transistor
File Size264KB,5 Pages
ManufacturerVishay
Websitehttp://www.vishay.com
Download Datasheet Parametric Compare View All

BFP181TW Overview

Silicon NPN Planar RF Transistor

BFP181TW Parametric

Parameter NameAttribute value
MakerVishay
package instruction,
Reach Compliance Codeunknow
Maximum collector current (IC)0.02 A
ConfigurationSingle
Minimum DC current gain (hFE)50
Maximum operating temperature150 °C
Polarity/channel typeNPN
Maximum power dissipation(Abs)0.16 W
surface mountYES
Nominal transition frequency (fT)8000 MHz
Base Number Matches1
BFP181T / BFP181TW / BFP181TRW
Vishay Semiconductors
Silicon NPN Planar RF Transistor
2
1
SOT-143
Features
Low noise figure
High power gain
e3
Lead (Pb)-free component
Component in accordance to RoHS 2002/95/EC
and WEEE 2002/96/EC
3
2
4
1
SOT-343
Applications
For low noise and high gain broadband amplifiers at
collector currents from 0.5 mA to 12 mA.
3
1
4
2
SOT-343R
Mechanical Data
Typ:BFP181T
Case:
SOT-143 Plastic case
Weight:
approx. 8.0 mg
Marking:
18
Pinning:
1 = Collector, 2 = Emitter,
3 = Base, 4 = Emitter
Typ:
BFP181TW
Case:
SOT-343 Plastic case
Weight:
approx. 6.0 mg
Marking:
W18
Pinning:
1 = Collector, 2 = Emitter,
4
3
18383
Electrostatic sensitive device.
Observe precautions for handling.
3 = Base, 4 = Emitter
Typ:
BFP181TRW
Case:
SOT-343R Plastic case
Weight:
approx. 6.0 mg
Marking:
WSF
Pinning:
1 = Collector, 2 = Emitter,
3 = Base, 4 = Emitter
Absolute Maximum Ratings
T
amb
= 25 °C, unless otherwise specified
Parameter
Collector-base voltage
Collector-emitter voltage
Emitter-base voltage
Collector current
Total power dissipation
Junction temperature
Storage temperature range
T
amb
78 °C
Test condition
Symbol
V
CBO
V
CEO
V
EBO
I
C
P
tot
T
j
T
stg
Value
15
10
2
20
160
150
- 65 to + 150
Unit
V
V
V
mA
mW
°C
°C
Maximum Thermal Resistance
Parameter
Junction ambient
1)
1)
Test condition
Symbol
R
thJA
Value
450
Unit
K/W
on glass fibre printed board (25 x 20 x 1.5) mm
3
plated with 35
µm
Cu
Document Number 85012
Rev. 1.4, 02-Mar-05
www.vishay.com
1

BFP181TW Related Products

BFP181TW BFP181T BFP181TRW
Description Silicon NPN Planar RF Transistor Silicon NPN Planar RF Transistor Silicon NPN Planar RF Transistor
Reach Compliance Code unknow unknow unknow
Maximum collector current (IC) 0.02 A 0.02 A 0.02 A
Configuration Single Single Single
Minimum DC current gain (hFE) 50 50 50
Maximum operating temperature 150 °C 150 °C 150 °C
Polarity/channel type NPN NPN NPN
Maximum power dissipation(Abs) 0.16 W 0.16 W 0.16 W
surface mount YES YES YES
Base Number Matches 1 1 1
