BZX84C…CCW Series
SILICON PLANAR ZENER DIODES
3
1
2
Absolute Maximum Ratings (T
a
= 25
O
C)
Parameter
Power Dissipation
Operating Junction and Storage Temperature Range
Symbol
P
D
T
j
,T
S
1. Anode 2. Anode 3. Cathode
Value
200
- 55 to + 150
Unit
mW
O
C
Electrical Characteristics
at T
a
= 25
O
C
(V
F
= 0.9 V Max. at I
F
= 10 mA)
Type
BZX84C2V4CCW
BZX84C2V7CCW
BZX84C3V0CCW
BZX84C3V3CCW
BZX84C3V6CCW
BZX84C3V9CCW
BZX84C4V3CCW
BZX84C4V7CCW
BZX84C5V1CCW
BZX84C5V6CCW
BZX84C6V2CCW
BZX84C6V8CCW
BZX84C7V5CCW
BZX84C8V2CCW
BZX84C9V1CCW
BZX84C10CCW
BZX84C11CCW
BZX84C12CCW
BZX84C13CCW
BZX84C15CCW
BZX84C16CCW
BZX84C18CCW
BZX84C20CCW
BZX84C22CCW
BZX84C24CCW
BZX84C27CCW
BZX84C30CCW
BZX84C33CCW
BZX84C36CCW
BZX84C39CCW
1)
Marking
Code
NA
NB
NC
ND
NE
NF
NH
NJ
NK
NM
NN
NP
NR
NX
NY
NZ
PA
PB
PC
PD
PE
PF
PH
PJ
PK
PM
PN
PP
PR
PX
Zener Voltage Range
1)
V
Z
Min.(V)
2.2
2.5
2.8
3.1
3.4
3.7
4
4.4
4.8
5.2
5.8
6.4
7
7.7
8.5
9.4
10.4
11.4
12.4
13.8
15.3
16.8
18.8
20.8
22.8
25.1
28
31
34
37
Max.(V)
2.6
2.9
3.2
3.5
3.8
4.1
4.6
5
5.4
6
6.6
7.2
7.9
8.7
9.6
10.6
11.6
12.7
14.1
15.6
17.1
19.1
21.2
23.3
25.6
28.9
32
35
38
41
at l
ZT
mA
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
2
2
2
2
2
Z
ZT
Max.(Ω)
100
100
95
95
90
90
90
80
60
40
10
15
15
15
15
20
20
25
30
30
40
45
55
55
70
80
80
80
90
130
Dynamic Resistance
at l
ZT
mA
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
2
2
2
2
2
Z
ZK
Max.(Ω)
600
600
600
600
600
600
600
600
500
480
400
150
80
80
80
100
150
150
150
170
200
200
225
225
250
250
300
300
325
350
at I
ZK
mA
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
0.5
0.5
0.5
0.5
0.5
Reverse Current
I
R
Max.(µA)
50
20
20
5
5
3
3
3
2
1
3
2
1
0.7
0.5
0.2
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
at V
R
V
1
1
1
1
1
1
1
2
2
2
4
4
5
5
6
7
8
8
8
10.5
11.2
12.6
14
15.4
16.8
18.9
21
23.1
25.2
27.3
