SHEET 1 OF 1
22.00
[.866 in]
[.528 in]
19.00
[.748 in]
13.40
15.50 ILLUMINATED RING
[.610 in]
PANEL CUTOUT
MAX. PANEL THICKNESS
11.0mm [.433]
ACTUATOR FINISH
MACHINED STAINLESS
FLAT ACTUATOR
BODY FINISH
MACHINED STAINLESS
2.00
[.079 in]
NOTE 15
HARDWARE
SUPPLIED
M19x1.0
SWITCH FUNCTION
POS. 1
POS. 2
ON
1-3, 4-6
ON
1-2, 4-5
37.00
.50
[1.457
.020
in]
28.50
.50
[1.122
.020
in]
36.00
.50
[1.417
.020
in]
1.8v
R
(-)
(+)
4
1
2.60
[.102 in]
1
3
1
1
4
4
C
3
2
6
5
RED
+
NOTE:
1. ALL DIMENSIONS IN mm [INCH]
2. GENERAL TOLERANCE: X.X=±0.4
X.XX=±0.25
3. TERMINAL NUMBERS FOR REF ONLY
4. CONTACT MATERIAL: SILVER
5. RATING: 2A 48VDC
6. ELECTRIC LIFE: 50,000 MAKE-AND-BREAK CYCLES
AT FULL LOAD.
7. INSULATION RESISTANCE: 1,000 MΩ MIN.
8. DIELECTRIC STRENGTH: 2,000 VAC MIN. FOR 1 MINUTE
9. CONTACT RESISTANCE: 50mΩ MAX. @ 1A 12VDC
10. OPERATING TEMP.: -20°C to 55°C
11. TRAVEL: 2.8mm
12. DENOTES CRITICAL PARAMETER.
13. LAMP VOLTAGE: 20mA 1.8V
14. INGRESS PROTECTION: IP65
15. HARDWARE SUPPLIED: O-RING AND HEXNUT
16. ILLUMINATION COLOR: RED
B
A
REV
21615
20642
PCR NO
Inluded 1.8v R on part
INITIAL RELEASE
DESCRIPTION
.50
[.020 in]
4
(-)
_
NO
NC
DPDT
CONTACT CONFIGURATION
10/14/14
06/14/12
DATE
AS
drg
BY
TITLE
SCALE
PV4F2G0SS-311
NONE
DATE
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
6/14/2012
DR
BGL
DWG
52-PV4F2G0SS311
REV
B
