QBLP679-XXK_series
PLCC6 LED
---------------------------------------------------------------------------------------------------------------------------------------
QT-Brightek PLCC-6 Series
PLCC6 LED
Part No.: QBLP679-XXK
Product: QBLP679-XXK_series
Date: March 27, 2014
Version# 2.0
Page 1 of 12
QBLP679-XXK_series
PLCC6 LED
---------------------------------------------------------------------------------------------------------------------------------------
Tablet of Contents:
Introduction ........................................................................................................................................... 3
Electrical / Optical Characteristic (Ta=25
o
C) ........................................................................................ 4
Absolute Maximum Rating .................................................................................................................... 4
Characteristic Curves ............................................................................................................................ 7
Solder Profile & Footprint ...................................................................................................................... 9
Packing ............................................................................................................................................... 10
Labeling .............................................................................................................................................. 11
Ordering Information ........................................................................................................................... 11
Revision History .................................................................................................................................. 12
Disclaimer ........................................................................................................................................... 12
Product: QBLP679-XXK_series
Date: March 27, 2014
Version# 2.0
Page 2 of 12
QBLP679-XXK_series
PLCC6 LED
---------------------------------------------------------------------------------------------------------------------------------------
Introduction
Feature:
Package in tape and reel
Ultra bright PLCC6
InGaN technology for IB/IG
AlInGaP technology for R/Y/O/S
120 degree viewing angle
Application:
Status indication
Industrial equipment backlighting
Architecture lighting
Certification & Compliance:
TS16949
ISO9001
RoHS Compliant
Description:
This PLCC6 LEDs have a height profile of 1.60mm.
Combination of high brightness output and robust
package, this LED is ideal for architecture lighting,
status indication, and general application.
Dimension:
Units: mm / tolerance = +/-0.2mm
Product: QBLP679-XXK_series
Date: March 27, 2014
Version# 2.0
Page 3 of 12
QBLP679-XXK_series
PLCC6 LED
---------------------------------------------------------------------------------------------------------------------------------------
Electrical / Optical Characteristic (Ta=25
o
C)
Product
QBLP679-IBK
QBLP679-IGK
QBLP679-RK
QBLP679-YK
QBLP679-OK
Color
Blue
True Green
Red
Yellow
Orange
I
F
(mA)*
60
60
60
60
60
V
F
(V)
Typ.
Max.
3.3
3.7
3.3
2.0
2.0
2.0
2.0
3.7
2.5
2.5
2.5
2.5
λ
D
(nm)
Min.
Typ. Max.
462.5
467 472.5
520
620
585
600
630
525
625
590
605
640
535
630
595
610
650
I
V
(mcd)
Min.
Typ.
780
1100
3600
350
1250
350
125
4700
630
1600
780
220
QBLP679-SK
Deep Red
60
*Total forward current for three dies
Absolute Maximum Rating
Material
InGaN (IB/IG)
AlInGaP (R/Y/O/S)
P
d
(mW) I
F
(mA) I
FP
(mA)* V
R
(V)
333
225
90
90
125
125
5
5
T
OP
(
o
C)
T
ST
(
o
C)
T
SOL
(
o
C)** ESD (V)
260
260
HBM
2000
HBM
8000
-40 ~ +80 -40 ~ +85
-40 ~ +80 -40 ~ +85
*Duty 1/8 @ 1KHz
**IR Reflow for no more than 10 sec @ 260
o
C
Forward Voltage V
F
for AlInGaP @ I
F
=60mA
Bin
□
Bin
f
g
h
Min.
1.7
Max.
2.5
Unit
V
Forward Voltage V
F
for InGaN @ I
F
=60mA
Min.
2.8
3.1
3.4
Max.
3.1
3.4
3.7
Unit
V
Product: QBLP679-XXK_series
Date: March 27, 2014
Version# 2.0
Page 4 of 12
QBLP679-XXK_series
PLCC6 LED
---------------------------------------------------------------------------------------------------------------------------------------
Luminous Intensity I
V
for Blue @ I
F
=60mA
Bin
14
15
Min.
780
1000
Max.
1000
1300
Luminous Intensity I
V
for True Green @ I
F
=60mA
Bin
20
21
Min.
3600
4600
Max.
4600
6000
Luminous Intensity I
V
for Red @ I
F
=60mA
Bin
11
12
13
14
15
Min.
350
460
600
780
1000
Max.
460
600
780
1000
1300
Luminous Intensity I
V
for Yellow @ I
F
=60mA
Bin
U
V
W
Min.
1250
1600
2000
Max.
1600
2000
2500
Luminous Intensity I
V
for Orange @ I
F
=60mA
Bin
11
12
13
14
15
Min.
350
460
600
780
1000
Max.
460
600
780
1000
1300
Luminous Intensity I
V
for Deep Red @ I
F
=60mA
Bin
K
L
M
N
O
Min.
125
160
200
250
320
Max.
160
200
250
320
400
Product: QBLP679-XXK_series
Date: March 27, 2014
Version# 2.0
Page 5 of 12
