QBS56XXZ_series
0.56” Single Digit Display
---------------------------------------------------------------------------------------------------------------------------------------
QT-Brightek Display Series
0.56” Single Digit Display
Part No.: QBS56XXZ
XX= Color
Z= 1: Common Cathode
Z = 0: Common Anode
Product: QBS56XXZ_series
Date: April 17, 2015
Version# 1.5
Page 1 of 13
QBS56XXZ_series
0.56” Single Digit Display
---------------------------------------------------------------------------------------------------------------------------------------
Table of Contents:
Introduction ........................................................................................................................................... 3
Electrical / Optical Characteristic (Ta=25
o
C) ........................................................................................ 4
Absolute Maximum Rating .................................................................................................................... 4
Pin Configuration .................................................................................................................................. 7
Characteristic Curves ............................................................................................................................ 8
Solder Profile ...................................................................................................................................... 10
Packing ............................................................................................................................................... 11
Ordering Information ........................................................................................................................... 12
Revision History .................................................................................................................................. 13
Disclaimer ........................................................................................................................................... 13
Product: QBS56XXZ_series
Date: April 17, 2015
Version# 1.5
Page 2 of 13
QBS56XXZ_series
0.56” Single Digit Display
---------------------------------------------------------------------------------------------------------------------------------------
Introduction
Feature:
0.56” Single digit seven segments display
Low power consumption
Packed in foam
AlInGaP Technology R/S/Y/AG/O
InGaN Technology IB/IG
Z= 1: Common Cathode or 0:Common Anode
XX= color
Description:
These 0.56” Single-digit, seven-segment displays are
made with white segments and a grey surface. The
viewing distance is up to seven meters.
Application:
Instrument panels
Indoor/Outdoor display board
Audio equipment
Certification & Compliance:
TS16949
ISO9001
RoHS Compliant
Dimension:
PART NO.
DATE CODE
Units: mm / tolerance = +/-0.25mm
Product: QBS56XXZ_series
Date: April 17, 2015
Version# 1.5
Page 3 of 13
QBS56XXZ_series
0.56” Single Digit Display
---------------------------------------------------------------------------------------------------------------------------------------
Electrical / Optical Characteristic (Ta=25
o
C)
Product
Material
CC
CA
Red
Deep
Red
Yellow
20
20
20
20
20
20
20
QBS56R1 QBS56R0 AllnGaP
QBS56S1
QBS56Y1
QBS56S0 AlInGaP
QBS56Y0 AllnGaP
Color I
F
(mA)
Typ.
2.0
2.0
2.0
2.0
2.0
3.2
3.2
Max.
2.6
2.6
2.6
2.6
2.6
4.0
3.6
Min.
619
636
585
601
566
500
460
Typ.
625
639
590
606
571
525
465
Max.
629
647
595
611
574
535
475
Typ.
60
30
60
60
25
200
60
V
F
(V)
λ
D
(nm)
I
V
(mcd)
QBS56O1 QBS56O0 AlInGaP Orange
Yellow
QBS56AG1 QBS56AG0 AllnGaP
Green
True
QBS56IG1 QBS56IG0 InGaN
Green
QBS56IB1 QBS56IB0 InGaN
Blue
Absolute Maximum Rating
Material P
d
(mW)
AllnGaP
70
Derating liner from 25
I (mA) I
PF
(mA)*
o
C per dice (mA/
o
C)
F
0.33
0.4
25
30
90
120
V
R
(V)
5
5
T
OP
(
o
C)
-25 to +85
-25 to +85
T
ST
(
o
C)
-25 to +85
-25 to +85
InGaN
120
*Duty 1/10 @ 1KHz
Luminous Intensity I
V
for Red @ I
F
=20mA
Bin
N
O
P
Min
30
50
70
Max
50
70
90
Unit
mcd
Luminous Intensity I
V
for Deep Red @ I
F
=20mA
Bin
M
N
O
Min
10
30
50
Max
30
50
70
Unit
mcd
Product: QBS56XXZ_series
Date: April 17, 2015
Version# 1.5
Page 4 of 13
QBS56XXZ_series
0.56” Single Digit Display
---------------------------------------------------------------------------------------------------------------------------------------
Luminous Intensity I
V
for Yellow @ I
F
=20mA
Bin
N
O
P
Min.
30
50
70
Max.
50
70
90
Unit
mcd
Luminous Intensity I
V
for Orange @ I
F
=20mA
Bin
N
O
P
Min
30
50
70
Max
50
70
90
Unit
mcd
Luminous Intensity I
V
for Yellow Green @ I
F
=20mA
Bin
M
N
O
Min.
10
30
50
Max.
30
50
70
Unit
mcd
Luminous Intensity I
V
for True Green @ I
F
=20mA
Bin
R
S
Min
160
200
Max
200
350
Unit
mcd
Luminous Intensity I
V
for Blue @ I
F
=20mA
Bin
N
O
P
Min
30
50
70
Max
50
70
90
Unit
mcd
Product: QBS56XXZ_series
Date: April 17, 2015
Version# 1.5
Page 5 of 13
