BAT86S
www.vishay.com
Vishay Semiconductors
Small Signal Schottky Diode
FEATURES
• Integrated
discharge
protection
ring
against
static
• Very low forward voltage
• AEC-Q101 qualified
• Material categorization:
For definitions of compliance please see
www.vishay.com/doc?99912
APPLICATIONS
MECHANICAL DATA
Case:
DO-35
Weight:
approx. 125 mg
Cathode band color:
black
Packaging codes/options:
TR/10K per 13" reel (52 mm tape), 50K/box
TAP/10K per ammopack (52 mm tape), 50K/box
• Applications where a very low forward voltage is required
PARTS TABLE
PART
BAT86S
ORDERING CODE
BAT86S-TR or BAT86S-TAP
INTERNAL CONSTRUCTION
Single diode
TYPE MARKING
BAT86S
REMARKS
Tape and reel/ammopack
ABSOLUTE MAXIMUM RATINGS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Reverse voltage
Peak forward surge current
Repetitive peak forward current
Forward continuous current
Average forward current
PCB mounting, I = 4 mm;
V
RWM
= 25 V, T
amb
= 50 °C
t
p
10 ms
t
p
1 s
TEST CONDITION
SYMBOL
V
R
I
FSM
I
FRM
I
F
I
FAV
VALUE
50
5
500
200
200
UNIT
V
A
mA
mA
mA
THERMAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Thermal resistance junction to ambient air
Junction temperature
Storage temperature range
TEST CONDITION
I = 4 mm, T
L
= constant
SYMBOL
R
thJA
T
j
T
stg
VALUE
320
125
- 65 to + 150
UNIT
K/W
°C
°C
ELECTRICAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
TEST CONDITION
I
F
= 0.1 mA
I
F
= 1 mA
Forward voltage
I
F
= 10 mA
I
F
= 30 mA
I
F
= 100 mA
Reserve current
Diode capacitance
V
R
= 40 V
V
R
= 1 V, f = 1 MHz
SYMBOL
V
F
V
F
V
F
V
F
V
F
I
R
C
D
MIN.
TYP.
MAX.
300
380
450
600
900
5
8
UNIT
mV
mV
mV
mV
mV
μA
pF
Rev. 1.9, 06-May-13
Document Number: 85514
1
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
BAT86S
www.vishay.com
TYPICAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
P - Reverse Power Dissipation (mW)
R
500
450
400
350
300
250
200
150
100
50
0
25
0.1
50
75
100
125
150
15829
Vishay Semiconductors
1000
V
R
= 50
V
T
j
= 125 °C
I
F
- Forward Current (A)
100
T
j
= 25 °C
10
P
R
- Limit
at 100 %
V
R
R
thJA
= 540 K/W
P
R
- Limit
at 80 %
V
R
1
0
0.5
1.0
1.5
15827
T
j
- Junction Temperature (°C)
Fig. 1 -
Max. Reverse Power Dissipation vs.
Junction Temperature
V
F
- Forward
Voltage
(V)
Fig. 3 -
Forward Current vs. Forward Voltage
10000
V
R
=
V
RRM
C
D
- Diode Capacitance (pF)
I
R
- Reverse Current (µA)
1000
10
9
8
7
6
5
4
3
2
1
0
15830
f = 1 MHz
100
10
1
25
15828
50
75
100
125
150
0.1
1
10
100
T
j
- Junction Temperature (°C)
V
R
- Reverse
Voltage
(V)
Fig. 2 -
Reverse Current vs. Junction Temperature
Fig. 4 -
Diode Capacitance vs. Reverse Voltage
PACKAGE DIMENSIONS
in millimeters (inches):
DO-35
Ø 0.6 max. [0.024]
Ø 0.4 min. [0.015]
1.7 [0.067]
26 min. [1.024]
3.9 max. [0.154]
3.1 min. [0.120]
26 min. [1.024]
Rev. 6 - Date: 19. December 2011
Document no.: SB-V-3906.04-031(4)
94 9366
Rev. 1.9, 06-May-13
Document Number: 85514
2
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
1.3 [0.050]
