HIGH FREQUENCY DEVICES
COAXIAL CONNECTORS
SMT, MICROMINIATURE
FEATURES
GSC Series
I
High engagement with new structure (50% up compared with
ESC type)
I
Ultra-miniature (LxWxH: 3.4x3.4x1.5mm) for high density
mounting (11.6mm
2
)
I
Ultra-low profile (3.0mm max.)
I
SMD and reflow soldering applicable
I
Taping package applicable
I
Mountable by automatic placer
I
High performance (VSWR: 1.2 max. at 3GHz)
I
Matched with ultra-thin FEP coaxial cables (0.8mm dia.)
APPLICATIONS
Portable, mobile and cordless telephone, GPS, and other
microwave radio and measurement equipment
PART NUMBERING – RECEPTACLE
Part Number
MM9329-2700
MM9329-2700TB1
MM9329-2700TB2
Packaging
Bulk package
178mm Dia. Taping
330mm Dia. Taping
Quantity
Specify
1000pcs/reel
DIMENSIONS (MM9329-2700): mm
(R0.15)
0.15
±
0.03
1
±
0.1
0.5
±
0.1
PART NUMBERING – CABLE ASSEMBLY
MX
TK
92
XX
200
0
0.15
±
0.03
2.6
3
2
±
0.1
1.15
(R0.15)
0.12
±
0.03
0.5
±
0.1
2.3
Hot Terminal
Ground Terminal
Tolerances unless
otherwise specified:
±0.2
Cable assembly
Connector code for each end of cable
Code
TK
XX
Cable code
Outer
Cable Diameter
0.4D
0.8mm
Outer
Conductor
Construction
Single shield
Minimum
Bending
Radius
4.8mm
Connector
GSC type Plug connector for 92 cable
No connector
0.1
2.6
3
2.1
5000pcs/reel
HIGH FREQUENCY
DEVICES
DIMENSIONS (MXTK92
Insulation
Material
PFA
2.8
): mm
Code
92
Full length of cable assembly
Length L (mm) =
x10
Ex. 500mm = 500x10
0
= 5000
1000mm = 100x10
1
= 1001
M
SPECIFICATIONS
Item
Frequency
VSWR
Nominal Impedance
Temperature Range
Voltage
Contact Resistance
Withstand Voltage
Insulation Resistance
Mating Cycles
Rating and Characteristics
From DC to 6GHz
1.2 max. (DC ~ 3GHz); 1.3 max. (3 ~ 6GHz)
50
–40°C to +90°C
250Vrms
15m
500M
max.
min.
300(AC) rms
100 cycles
1.5
3.5
±
0.5
2.55
Tolerances unless
otherwise specified:
±0.3
CG01-J
315
HIGH FREQUENCY DEVICES
COAXIAL CONNECTORS
SMT, MICROMINIATURE
MATERIALS AND FINISH
MM9329-2700 – RECEPTACLE
Part Name
Center Contact
Outer Contact
Insulator
Materials
Stainless Steel
Copper Alloy
Engineering Plastic
Finish
Gold plated
Silver plated
None
Cable Length L (mm)*
Finish
Gold plated
Gold plated
None
From
40
100
500
1000
*L must be 20mm min.
GSC Series
CABLE LENGTH TOLERANCE
L
MXTK92
Part Name
Center Contact
Outer Contact
Insulator
– CONNECTOR
Materials
Copper Alloy
Copper Alloy
Engineering Plastic
To
100
500
1000
—
Dimensional
Tolerance (mm)
± 3
± 4
±10
+2% of L
–0% of L
TAPE DIMENSIONS: mm
PO
P2
E
DO
T
REEL DIMENSIONS: mm
3° max.
W1
D
B
B
B
N
C
F
W
A
3° max.
P1
A
K
W2
A
3.8 ± 0.1
K
B
3.8 ± 0.1
P0
W
12 ± 0.2
P1
D0
1.5
+0.1
–0
E
1.75 ± 0.1
P2
2 ± 0.1
F
5.5 ± 0.1
T
0.3 ± 0.05
Part No.
MM9329-2700TB1
A± 2 B± 0.5 C±0.8 D±0.5 N min. W1±1.5 W2 min.
178
330
13
13
21
21
2
2
50
50
13.5
13.5
18.5
18.5
0.15 ± 0.125
4 ± 0.1
8 ± 0.1
MM9329-2700TB2
RECOMMENDED MOUNTING DIMENSIONS: mm
5.2
3.6
2.3
1
0.6
DIMENSIONS: mm
1
1.9
1.5
2
1.5
1.05 1.05
(2.37)
2.5
2 max.
2.8 max.
(3– 0.6)
(Through Holes)
Land
0.6
(1.5) (1.74) (1.5)
Electrode
316
0.7 min.
CG01-J
HIGH FREQUENCY DEVICES
COAXIAL CONNECTORS
SMT, MICROMINIATURE
APPLICATION NOTES
I
PCB mounting pattern dimensions: Dimensions shown
on page 319 “Recommended Mounting Dimensions”
should be used for PCB design.
I
Disengagement and engagement:
Use tool P/N M22001. The connector to be disengaged
and engaged should be pulled out or insert to the vertical
direction using the tool. Do not try and pull out the cable
by hand or wire breakage may result.
GSC Series
I
Cable and connector handling: Do not apply a twisting
torque to the cable and connector.
I
REFLOW SOLDERING CONDITION: Reflow soldering
should be carried out according to condition shown
in Fig. 3.
DISENGAGEMENT TOOL (Fig. 1): mm
M22001
35
±
2
7.95
±
2
How to use disengagement tool
Dia. 8
2.3
±
0.6
45
±
2
3.9
±
0.6
SMA-GSC ADAPTERS (Fig. 2): mm
STANDARD REFLOW SOLDERING
CONDITIONS (Fig. 3)
260
5.08
7.95
2.3
Temperature (°C)
MM121471
SMA - Jack
5.33
18
2
250
GSC - Contact
240
230
220
210
200
190
180
30
60
90
120
150
180
HIGH FREQUENCY
DEVICES
MM121470
SMA - Jack
5.33
13.4
5.08
7.4
4.4
2.
1
GSC - Female
4.06
5.33
6.5
Time [sec.]
Solder : Sn60%– Pb40%
Allowable temperature and time of reflow soldering
3
4.6
5.33
2.55
Peak temperature 225 ± 5°C
Temperature (°C)
220
200
150
100
25
0
Pre-heating 150 ± 10°C
MM121480
SMA - Jack
5.33
13.4
8.55
5.08
0.85
GSC – Male
2.1
Time [sec.]
10 sec. max.
60 ~ 120 sec.
20 ~ 30 sec. max.
• Measuring point of temperature in-out terminals of the device.
• Reflow Soldering
• Hot air
• Both convection and infrared rays
• Hot plate
CG01-J
317
