UG3KB05-UG3KB100
BRIDGE RECTIFIERS
T
RRJ
X
Features
·
Glass Passivated Die Construction
·
High case dielectric strength
·
High surge current capability
·
Ideal for printed circuit board
Mechanical Data
·
Terminal: Plated leads solderable
per MIL-STD 202E,Method 208C
· Case: UL-94 Class V-0 recognized Flame
Retardant Epoxy
·
Polarity: Polarity symbol marked on body
·
Mounting Position:Any
Maximum Ratings and Electrical Characteristics
@TA=25℃ unless otherwise specified
Single Phase,half wave,60Hz,resistive or inductive load.For capacitive load,derate current by 20%.
Parameter
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum Average forward output rectified
current
Peak forward surge current 8.3ms single
sine-wave superimposed on rated load(JEDEC
Method)
Maximum instantaneous forward voltage drop
per diode @3.0A
Maximum DC reverse current at TA=25℃
rated DC blocking voltage per leg TA=125℃
Typical thermal resistance per leg
Operating junction temperature range
storage temperature range
Note:
Symbol
UG3KB UG3KB UG3KB UG3KB UG3KB UG3KB UG3KB
UNIT
05
10
20
40
60
80
100
50
100
200
400
600
800
1000
V
35
50
70
100
140
200
280
400
3.0
420
600
560
800
700
1000
V
V
A
V
RRM
V
RMS
V
DC
I(AV)
IF
SM
VF
IR
RθJA
RθJL
TJ
Tstg
60
1.1
5.0
500
34
15
-55 to +150
-55 to +150
A
V
uA
℃/W
℃
℃
