LA6584

Description
IC,MOTOR CONTROLLER,BIPOLAR,SSOP,20PIN
CategoryOther integrated circuit (IC)    The signal circuit
File Size158KB,5 Pages
ManufacturerON Semiconductor
Websitehttp://www.onsemi.cn
Download Datasheet Parametric View All

LA6584 Overview

IC,MOTOR CONTROLLER,BIPOLAR,SSOP,20PIN

LA6584 Parametric

Parameter NameAttribute value
MakerON Semiconductor
package instructionSSOP, SSOP20,.25
Reach Compliance Codecompliant
JESD-30 codeR-PDSO-G20
Number of terminals20
Maximum operating temperature90 °C
Minimum operating temperature-30 °C
Package body materialPLASTIC/EPOXY
encapsulated codeSSOP
Encapsulate equivalent codeSSOP20,.25
Package shapeRECTANGULAR
Package formSMALL OUTLINE, SHRINK PITCH
power supply12 V
Certification statusNot Qualified
Maximum supply current (Isup)9 mA
Nominal supply voltage (Vsup)12 V
surface mountYES
technologyBIPOLAR
Temperature levelOTHER
Terminal formGULL WING
Terminal pitch0.635 mm
Terminal locationDUAL

LA6584 Preview

Ordering number : ENA0007
Monolithic Linear IC
LA6584
Overview
BTL Driver Single-Phase Full-Wave
Fan Motor Driver
The LA6584 is Single-phase bipolar fan motor is put into silent driving by means of BTL output linear drive, offering high
efficiency and power saving by suppressing the reactive current. Lock protection and rotation signal (FG, RD) circuits are
built in, ensuring optimum application to small fans for notebook PC, consumer equipment power supply, car audio system,
CPU cooler, etc. that require high reliability and low noise.
Functions and Applications
Single-phase full-wave driver for fan motor
Specitications
Absolute Maximum Ratings
at Ta = 25°C
Parameter
Output voltage
Allowable dissipation
Output current
Output withstand voltage
RD/FG output pin output
Withstand voltage
RD/FG output current
HB output voltage
Operating temperature range
Storage temperature range
IRD/FG max
IB max
Topr
Tstg
5
10
-30 to +90
-55 to +150
mA
mA
°C
°C
Symbol
VCC max
Pd max
IOUT max
VOUT max
VRD/FG max
Mounted on a specified board*
Conditions
Ratings
15
1.1
1.2
15
15
Unit
V
W
A
V
V
*Mounted on a specified board (114.3×76.1×1.6mm, Glass epoxy)
Recommended Operating Range
at Ta = 25°C
Parameter
Supply voltage
Common-phase input voltage
Range of Hall input
Symbol
VCC
VICM
Conditions
Ratings
2.8 to 14.0
0 to VCC-1.5
Unit
V
V
81005 SY PC B6-6875 No.0007-1/5
LA6584
Electrical Characteristics
at Ta = 25°C, VCC = 12V, unless especially specified.
Parameter
Circuit current
Symbol
ICC1
ICC2
Lock detection capacitor charge current
Capacitor discharge current
Capacitor charge and discharge current ratio
CT charge voltage
CT discharge voltage
OUT output L saturation voltage
OUT output H saturation voltage
Hall input sensitivity
RD/FG output pin L voltage
RD/FG output pin leak current
HB output L voltage
ICT1
ICT2
RCT
VCT1
VCT2
VOL
VOH
VHN
VRD/FG
IRD/FGL
VHBL
IO = 200mA
IO = 200mA
Zero peak value
(including offset and hysteresis)
IRD/FG = 5mA
VRD/FG = 15V
IHB = 5mA
1.3
0.1
1
1.5
0.2
30
1.7
V
µA
V
RCD = ICT1/ICT2
Conditions
min
During drive (CT = L)
During lock protection (CT = H)
4
2
2.0
0.15
9
1.6
0.6
Ratings
typ
6
4
2.8
0.23
12
1.7
0.7
0.2
0.9
7
max
9
6
3.5
0.30
15
1.8
0.8
0.3
1.2
15
mA
mA
µA
µA
-
V
V
V
V
mV
Unit
Package Dimensions
unit : mm
3313
6.5
14
8
4.4
6.4
1
1.3
(2.35)
0.65
7
0.22
0.15
1.5
SANYO : HSSOP14(225mil)
0.1 (1.3)
1.5max
0.5
No.0007-2/5
LA6584
Truth Table
IN-
H
L
-
IN+
L
H
-
H
CT
L
OUT1
H
L
OFF
OUT2
L
H
OFF
FG
L
H
-
H
During overheat protection
RD
L
Mode
During rotation
Pin Assignment
F-GND
F-GND
OUT2
(NC)
VCC
(NC)
FG
RD
NC
1
2
3
4
5
6
7
Top view
14
13
OUT1
(NC)
CT
IN-
HB
IN+
(NC)
LA6584
12
11
10
9
8
No.0007-3/5
LA6584
Sample Application Circuit
Di
*1
Cr
VCC
RD
FG
*4
R2
HB
H
IN-
*2
OUT1
HB
IN+
R2
*5
CT
OUT2
R1
GND
*3
H
IN-
On board element
IN+
*1
*2
*3
*4
*5
When Di to prevent breakdown in case of reverse connection is used, it is necessary to insert a capacitor Cr to
secure the regenerative current route. Similarly, Cr is necessary to enhance the reliability when there is no
capacitor near the fan power line.
To obtain Hall bias from VCC, carry out 1/2×VCC bias as shown in the figure. Linear driving is made through
voltage control of the coil by amplifying the Hall output. When the Hall element output is large, the startup
performance and efficiency are improved. Adjustment of the Hall element can reduce the noise further.
When the Hall bias is taken from the HB pin, constant-voltage bias is made with about 2.0V. Therefore, the Hall
element can provide the output satisfactory in temperature characteristics. Adjustment of the Hall output
amplitude is made with R1. (When VCC = 12V, the step *2 above proves advantageous for IC heat generation.)
Keep this open when not used.
When the wiring from the Hall output to IC Hall input is long, noise may be carried through the wiring.
In this case, insert the capacitor as shown in the figure.
No.0007-4/5
LA6584
Internal Equivalent Circuit
VCC
1.5VRG
HB
H
IN+
OUT1
OUT2
IN-
GND
FG
Control
Circuit
Charge/discharge circuit
RD
Discharge
pulse
CT = 0.47 to 1µF
n
Specifications of any and all SANYO products described or contained herein stipulate the performance,
characteristics, and functions of the described products in the independent state, and are not guarantees of
the performance, characteristics, and functions of the described products as mounted in the customer's
products or equipment. To verify symptoms and states that cannot be evaluated in an independent device,
the customer should always evaluate and test devices mounted in the customer's products or equipment.
n
SANYO Electric Co., Ltd. strives to supply high-quality high-reliability products. However, any and all
semiconductor products fail with some probability. It is possible that these probabilistic failures could give
rise to accidents or events that could endanger human lives, that could give rise to smoke or fire, or that
could cause damage to other property. When designing equipment, adopt safety measures so that these
kinds of accidents or events cannot occur. Such measures include but are not limited to protective circuits
and error prevention circuits for safe design, redundant design, and structural design.
n
In the event that any or all SANYO products (including technical data, services) described or contained
herein are controlled under any of applicable local export control laws and regulations, such products must
not be exported without obtaining the export license from the authorities concerned in accordance with the
above law.
n
No part of this publication may be reproduced or transmitted in any form or by any means, electronic or
mechanical, including photocopying and recording, or any information storage or retrieval system, of
otherwise, without the prior written permission of SANYO Electric Co., Ltd.
n
Any and all information described or contained herein are subject to change without notice due to
product/technology improvement, etc. When designing equipment, refer to the "Delivery Specification" for
the SANYO product that you intend to use.
n
Information (including circuit diagrams and circuit parameters) herein is for example only; it is not
guaranteed for volume production. SANYO believes information herein is accurate and reliable, but no
guarantees are made or implied regarding its use or any infringements of intellectual property rights or other
rights of third parties.
This catalog provides information as of August, 2005. Specifications and information herein are subject to
change without notice.
PS No.0007-5/5
