BC807-16/-25/-40
0.3 Watts, PNP Plastic-Encasulate Transistor
Small Signal Product
Features
◇
Ideally suited for automatic insertion
◇
Epitaxial planar die construction
◇
For switching, AF driver and amplifer applications
◇
Complementary NPN type available (BC817)
SOT-23
Mechanical Data
◇
Case : SOT- 23, Molded plastic
◇
Case material : Molded plastic, UL flammability
classification rating 94V-0
◇
Moisture sensitivity : Level 1 per J-STD-020C
◇
Terminals : Solderable per MIL-STD-202, method 208
◇
Lead free plating
◇
Marking : -16: 5A, -25: 5B, -40: 5C
◇
Weight : 0.008grams (approximately)
Ordering Information (example)
Part No.
BC807-16
Package
SOT-23
Packing
3K / 7 " Reel
Packing code
RF
Packing code
(Green)
RFG
Manufacture code
B0
Note : Detail please see "Ordering Information(detail, example)" below.
Maximum Ratings and Electrical Characteristics
Rating at 25°C ambient temperature unless otherwise specified.
Parameter
Collector-Base Breakdown Voltage
Collector-Emitter Breakdown Voltage
Collector Current - Continuous
Power Dissipation
Emitter-Base Breakdown Voltage
Collector Cut-Off Current
Collector Cut-Off Current
Emitter Cut-Off Current
Collector-Emitter Saturation Voltage
Base-Emitter Saturation Voltage
Transition Frequency
Junction Temperature
Storage Temperature Range
V
CE
= -5 V
I
E
= -1
μA
V
CB
= -45 V
V
CB
= -40 V
V
EB
= -4 V
I
C
= -500 mA
I
C
= -500 mA
I
C
= -10 mA
I
C
= 0
I
E
= 0
I
B
= 0
I
C
= 0
I
B
= 50 mA
I
B
= 50 mA
f = 100 MHz
I
C
= -10
μA
I
C
= -10 mA
I
E
= 0
I
B
= 0
Symbol
V
CBO
V
CEO
I
C
P
D
V
EBO
I
CBO
I
CEO
I
EBO
V
CE(sat)
V
BE(sat)
f
T
T
J
T
STG
Symbol
I
C
= -100 mA
h
FE(1)
BC807-16
BC807-25
-50
-45
-0.5
0.3
-5
-0.1
-0.2
-0.1
-0.7
-1.2
100
150
-55 to +150
BC807-40
Units
V
V
A
W
V
μA
μA
μA
V
V
MHz
°C
°C
Parameter
807-16
DC Current Gain
807-25
807-40
V
CE
= -1 V
Min
100
160
250
Max
250
400
600
Units
Version : E13
Small Signal Product
RATINGS AND CHARACTERISTIC CURVES
Fig. 1 Power Derating Curve
400
See Note 1
300
Fig. 2 Gain Bandwidth Product VS. Collector Current
1000
T
A
= 25
o
C
f = 20 MHz
-V
CE
= 5.0 V
-V
CE
= 1 V
200
100
f
T,
Gain Bandwidth Product (MHz)
P
D
, Power Dissipation (mW)
100
0
0
50
100
150
200
10
1
10
100
1000
I
C
, Collector Current (mA)
T
SB
, Substrate Temperature (
o
C)
Fig.3 Collector Sat Voltage VS. Collector Current
1000
- 50
o
C
1000
Fig. 4 DC Current Gain VS. Collector Current
150
o
C
-I
C,
Collector Current (mA)
100
25
o
C
Typical
- - - - - - - - Limits
at T
A
= 25
o
C
h
FE
, DC Current Gain
-V
CE
= 1V
25
o
C
100
- 50
o
C
10
150
o
C
1
-I
C
/ -I
B
= 10
0.1
0
0.1
0.2
0.3
0.4
0.5
-V
CESAT
, Collector Saturation Voltage (V)
10
0.1
1
10
100
1000
-I
C
, Collector Current (mA)
Fig.5 Typical Emitter-Collector Characterisitcs
500
3.2
1.4
2.8
2.4
-I
C
, Collector Current ( mA )
2.0
1.8
1.6
1.0
200
1.2
0.8
0.6
0.4
- I
B
= 0.2 mA
0
1
-V
CE
, Collector-Emitter Voltage (V)
2
0
0
80
100
Fig. 6 Typical Emitter-Collector Characteristics
0.4
0.35
0.3
60
0.25
0.2
0.15
20
0.1
- I
B
= 0.05 mA
10
-V
CE
, Collector-Emitter Voltage (V)
20
-I
c
, Collector Current (mA)
400
300
40
100
0
Version : E13
Small Signal Product
Ordering information (Detail, example)
Part No.
BC807-xx
(Note 1)
BC807-16
BC807-16
BC807-16
Package
SOT-23
SOT-23
SOT-23
SOT-23
Packing
3K / 7 " Reel
3K / 7 " Reel
3K / 7 " Reel
3K / 7 " Reel
Packing code
RF
RF
RF
RF
Packing code
(Green)
RFG
RFG
RFG
RFG
B0
D0
Manufacture
code
(Note 2)
Note 1 : "xx" is Device Code from "16" thru "40".
Note 2 : Manufacture special control, if empty means no special control requirement.
Dimensions
DIM.
A
B
C
D
E
F
G
H
Unit(mm)
Min
2.70
1.10
0.30
1.78
2.10
0.89
Max
3.10
1.50
0.51
2.04
2.64
1.30
Unit(inch)
Min
0.106
0.043
0.012
0.070
0.083
0.035
Max
0.122
0.059
0.020
0.080
0.104
0.051
0.550 REF
0.1 REF
0.022 REF
0.004 REF
Suggested PAD Layout
DIM.
A
B
C
D
Unit(mm)
Typ.
0.95
2.0
0.9
0.8
Unit(inch)
Typ.
0.037
0.079
0.035
0.031
Marking
Part No.
BC807-16
BC807-25
BC807-40
Marking
5A
5B
5C
Version : E13
