UNISONIC TECHNOLOGIES CO., LTD
39N20
39A, 200V N-CHANNEL
POWER MOSFET
DESCRIPTION
The UTC
39N20
is a N-channel mode power MOSFET using
UTC’s advanced technology to provide customers with a minimum
on-state resistance, low gate charge and high switching speed.
The UTC
39N20
is suitable for high voltage synchronous rectifier
and DC/DC converters, etc.
Preliminary
Power MOSFET
FEATURES
* R
DS(ON)
<66mΩ @ V
GS
=10V,I
D
=19.5A
* Low Gate Charge (Typical 18.5nC)
* High Switching Speed
SYMBOL
2.Drain
1.Gate
3.Source
ORDERING INFORMATION
Ordering Number
Lead Free
Halogen Free
39N20L-T47-T
39N20G-T47-T
Pin Assignment: G: Gate D: Drain
S: Source
Package
TO-247
Pin Assignment
1
2
3
G
D
S
Packing
Tube
Note:
www.unisonic.com.tw
Copyright © 2012 Unisonic Technologies Co., Ltd
1 of 5
QW-R502-817.a
39N20
Preliminary
Power MOSFET
ABSOLUTE MAXIMUM RATINGS
(T
C
=25°C, unless otherwise specified)
PARAMETER
SYMBOL
RATINGS
UNIT
Drain-Source Voltage
V
DSS
200
V
Gate-Source Voltage
V
GSS
±20
V
Continuous
I
D
39
A
(V
GS
=10V) T
C
=25°C
Drain Current
Pulsed
I
DM
156
A
Single Pulsed Avalanche Energy (Note 2)
E
AS
860
mJ
Power Dissipation
P
D
310
W
Junction Temperature
T
J
+150
°C
Storage Temperature
T
STG
-55~+150
°C
Notes: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
2. Starting T
J
= 25°C, L = 0.85mH, I
AS
= 39A, V
DD
=50V, R
G
=25Ω.
3. Pulse Width = 100μs
THERMAL DATA
PARAMETER
Junction to Ambient
Junction to Case
SYMBOL
θ
JA
θ
JC
RATINGS
40
0.37
UNIT
°C/W
°C/W
ELECTRICAL CHARACTERISTICS
(T
C
=25°C, unless otherwise specified)
PARAMETER
SYMBOL
TEST CONDITIONS
OFF CHARACTERISTICS
Drain-Source Breakdown Voltage
BV
DSS
I
D
=250µA, V
GS
=0V
Drain-Source Leakage Current
I
DSS
V
DS
=200V, V
GS
=0V
V
GS
=+20V, V
DS
=0V
Forward
Gate- Source Leakage
I
GSS
Current
Reverse
V
GS
=-20V, V
DS
=0V
ON CHARACTERISTICS
Gate Threshold Voltage
V
GS(TH)
V
DS
=V
GS
, I
D
=250µA
Static Drain-Source On-State Resistance R
DS(ON)
V
GS
=10V, I
D
=19.5A
DYNAMIC PARAMETERS
Input Capacitance
C
ISS
V
GS
=0V, V
DS
=25V, f=1.0MHz
Output Capacitance
C
OSS
Reverse Transfer Capacitance
C
RSS
SWITCHING PARAMETERS
Total Gate Charge at 10V
Q
G
V
GS
=10V,V
DD
=50V,I
D
=39A
Gate to Source Charge
Q
GS
Gate to Drain Charge
Q
GD
Turn-ON Time
t
ON
Turn-ON Delay Time
t
D(ON)
V
DD
=50V, I
D
=39A, V
GS
=10V,
R
G
=16Ω
Rise Time
t
R
Turn-OFF Delay Time
t
D(OFF)
SOURCE- DRAIN DIODE RATINGS AND CHARACTERISTICS
Drain-Source Diode Forward Voltage
V
SD
I
SD
=39A
Maximum Continuous Drain-Source
I
S
Diode Forward Current
Maximum Pulsed Drain-Source Diode
I
SM
Forward Current
MIN TYP MAX UNIT
200
V
1
µA
+100 nA
-100 nA
4
66
V
mΩ
pF
pF
pF
28
nC
nC
nC
ns
ns
ns
ns
V
A
A
2
56
1250
190
45
18.5
6.5
4.6
30
160
150
150
70
1.4
39
156
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
2 of 5
QW-R502-817.a
39N20
Same Type
as DUT
12V
200nF
50kΩ
V
GS
DUT
3mA
300nF
Preliminary
Power MOSFET
TEST CIRCUITS AND WAVEFORMS
V
GS
Q
G
10V
V
DS
Q
GS
Q
GD
Charge
Gate Charge Test Circuit
Gate Charge Waveforms
Resistive Switching Test Circuit
V
DS
R
G
I
D
BV
DSS
L
I
AS
Resistive Switching Waveforms
E
AS
= 1 LI
AS2
2
BV
DSS
BV
DSS
-V
DD
10V
t
P
DUT
V
DD
V
DD
I
D
(t)
V
DS
(t)
Time
t
P
Unclamped Inductive Switching Test Circuit
Unclamped Inductive Switching Waveforms
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
3 of 5
QW-R502-817.a
39N20
Preliminary
Power MOSFET
TEST CIRCUITS AND WAVEFORMS(Cont.)
+
V
DS
L
-
I
SD
V
GS
V
DD
Driver
Same Type
as DUT
dv/dt controlled by R
G
I
SD
controlled by pulse period
DUT
R
G
V
GS
(Driver
)
D=
Gate Pulse Width
Gate Pulse Period
10V
I
FM
, Body Diode Forward Current
I
SD
(DUT)
I
RM
Body Diode Reverse Current
V
DS
(DUT)
di/dt
Body Diode Recovery dv/dt
V
SD
V
DD
Body Diode Forward
Voltage Drop
Peak Diode Recovery dv/dt Test Circuit and Waveforms
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
4 of 5
QW-R502-817.a
39N20
Preliminary
Power MOSFET
UTC assumes no responsibility for equipment failures that result from using products at values that
exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges, or
other parameters) listed in products specifications of any and all UTC products described or contained
herein. UTC products are not designed for use in life support appliances, devices or systems where
malfunction of these products can be reasonably expected to result in personal injury. Reproduction in
whole or in part is prohibited without the prior written consent of the copyright owner. The information
presented in this document does not form part of any quotation or contract, is believed to be accurate
and reliable and may be changed without notice.
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
5 of 5
QW-R502-817.a
