Pitch: 5.08mm (0.200”)
Poles A(mm) B(in) Poles A(mm)
2
10.16 0.400 14
71.12
3
15.24 0.600 15
76.20
4
20.32 0.800 16
81.28
5
25.40 1.000 17
86.36
6
30.48 1.200 18
91.44
7
35.56 1.400 19
96.52
8
40.64 1.600 20 101.60
9
45.72 1.800 21 106.68
10
50.80 2.000 22 111.76
11
55.88 2.200 23 116.84
12
60.96 2.400 24 121.92
13
66.04 2.600
SPECIFICATIONS
Current rating:
Contact material:
Contact plating:
Insulation material:
Insulation resistance:
Withstanding:
Screw material:
Screw plating:
Cage clamp material:
Cage clamp plating:
Operating temp.:
16 amps
Phosphor bronze
Tin
Polyamide66, UL94V-0
2,000 megohms min.
2,000VAC for 1 min.
Steel
Nickel
Brass
Nickel
-40°C to +105°C
B(in)
2.800
3.000
3.200
3.400
3.600
3.800
4.000
4.200
4.400
4.600
4.800
A
B
C
D
D
E
E
F
RoHS compliant
Rev.
Description
Date
Approved
Drawing
Name
Approved Howard
Checked Lizzy
Drawn Tina
0.0 ± 0.35
1
2
3
4
Series
Type
Pitch
Positions
Color
CMTB
MC211
XXX
XX
GN
Terminal block Plug, vertical 500=5.00mm pitch
02-24
GN=Green
508=5.08mm pitch
381=3.81mm available
Date
08/10/99
08/10/99
08/10/99 Part No.:
F
Central Components Manufacturing
440 Lincoln Blvd., Middlesex, New Jersey 08846
Phone 732 469-5720 888 288-5152 Fax 732 469-1919
G
CMTB-MC211-508-XX-GN
7
8
9
0.00 ± 0.20 Angles ± 3’
UNIT: mm
5
6
Description: Terminal block, plug, top screw, backside wire entry, with
flanges
G
