Circulator
1310 or 1550 nm Three-port Polarization Insensitive Circulator
Parameter
Central Wavelength (λc)
Isolation (λc ± 20nm, 23° C, 2-1 or 3-2)
Insertion Loss (λc ± 15nm, 23° C)
Insertion Loss (λc ± 20nm, 0-70° C, all SOP)
Wavelength Dependent Loss
Return Loss
PMD
Maximum Power
Directivity
PDL
Operating Temperature
Storage Temperature
Package Dimensions
Note1: All values specified are without connectors.
Note2: Higher performance specifications upon request.
Note3: Fiber type Corning SMF-28e.
Premium
1310 or 1550 nm
A Grade
≥ 50 dB typical, 40 dB minimum
≤ 0.6 dB
≤ 0.8 dB
≤ 0.2 dB
≥ 50 dB
≤ 0.1 ps
500 mW
≥ 50 dB
≤ 0.15 dB
0° C ~ + 70° C
- 40° C ~ + 85° C
5.5 mm () x 60 mm (L)
≤ 0.2 dB
≤ 0.8 dB
≤ 1.0 dB
C I R -
Grade
P: Premium
A: A Grade
-
Center Wavelength
13: 1310 nm
15: 1550 nm
0 3
03: 3 ports
-
A
-
-
Pigtail Style
(=Package style)
B: bare fiber
L: 900 μm loose tube
Connector
0: None
1: FC/PC
2: FC/APC
3: SC/ PC
4: SC/APC
5: FC/SPC
6: SC/SPC
7: LC/UPC
8: LC/SPC
9: Special
A: FC/UPC
B: SC/UPC
C: ST
Fiber Length
A: 1 meter
www.lightel.com
2210 Lind Ave SW, Suite 100
Renton, WA 98057 USA
(425) 277-8000 ph.
(425) 277-5280 Fax
All rights Reserved 2009
