PL
IA
NT
Features
■
Available in E12 series
■
Unit height of 6.5 mm
■
Current up to 6 A
■
RoHS compliant*
Applications
■
Input/output of DC/DC converters
■
Power supplies for:
•
Portable communication equipment
•
Camcorders
•
LCD TVs
•
Car radios
*R
oH
S
CO
M
SRR1206 Series - Shielded High Power Inductors
Electrical Specifications
Inductance 1kHz
Bourns Part No.
(µH)
Tol. %
Q
Ref.
Test
Frequency
(MHz)
SRF
Min.
(MHz)
RDC
Max.
(mΩ)
I rms
Max.
(A)
I sat
Typ.
(A)
SRR1206-2R5ML
SRR1206-3R3ML
SRR1206-5R0ML
SRR1206-7R5ML
SRR1206-100ML
SRR1206-120ML
SRR1206-150ML
SRR1206-180ML
SRR1206-220ML
SRR1206-270ML
SRR1206-330YL
SRR1206-390YL
SRR1206-470YL
SRR1206-560YL
SRR1206-680YL
SRR1206-820YL
SRR1206-101YL
SRR1206-121YL
SRR1206-151KL
SRR1206-181KL
SRR1206-221KL
SRR1206-271KL
SRR1206-331KL
SRR1206-391KL
SRR1206-471KL
SRR1206-561KL
SRR1206-681KL
SRR1206-821KL
SRR1206-102KL
SRR1206-122KL
SRR1206-152KL
2.5
3.3
5.0
7.5
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
1500
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
20
20
20
20
20
20
20
20
20
20
15
15
15
15
15
15
15
15
10
10
10
10
10
10
10
10
10
10
10
10
10
19
20
21
22
18
18
19
19
21
21
21
23
22
21
18
16
13
13
13
12
11
11
11
13
12
13
11
10
10
10
10
7.96M
7.96M
7.96M
7.96M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
0.796M
0.796M
0.796M
0.796M
0.796M
0.796M
0.796M
0.796M
0.796M
0.796M
0.796M
0.796M
0.252M
0.252M
0.252M
30.0
26.0
25.0
22.0
18.0
17.0
16.0
14.0
11.0
10.0
9.0
9.0
7.0
7.0
7.0
6.0
6.0
5.0
5.0
4.5
4.0
3.5
3.0
2.5
2.5
2.0
2.0
2.0
1.8
1.5
1.2
16
18.5
22
25
35
38
42
50
62
68
90
100
130
155
170
185
220
260
320
380
460
520
660
870
970
1320
1500
1700
2300
2650
3500
6.20
5.80
4.70
3.80
3.30
3.00
2.80
2.50
2.30
2.00
1.90
1.75
1.60
1.45
1.30
1.20
1.10
1.00
0.90
0.80
0.70
0.65
0.60
0.55
0.50
0.45
0.40
0.35
0.30
0.25
0.20
10.00
5.40
8.30
6.90
5.70
5.50
5.10
4.70
3.80
3.70
3.10
3.00
2.50
2.50
2.20
2.10
1.90
1.80
1.60
1.30
1.20
1.10
1.00
0.95
0.83
0.80
0.70
0.65
0.54
0.51
0.42
General Specifications
Test Voltage........................................1 V
Reflow Soldering ...230 °C, 50 sec. max.
Operating Temperature ..-40 °C to +125 °C
(Temperature rise included)
Storage Temperature..-40 °C to +125 °C
Resistance to Soldering Heat
..................................260 °C for 5 sec.
Materials
Core.....................Ferrite DR and RI core
Wire .............................Enameled copper
Base ......................................LCP E4008
Terminal ....................................Cu/Ni/Sn
Rated Current..Ind. drop 10 % typ. at Isat
Temperature Rise
......................40 °C max. at rated Irms
Packaging.....................600 pcs. per reel
Product Dimensions
101
12.7
±
0.3
(.500
±
.012)
5.0
±
0.2
(.197
±
.007)
12.7
±
0.3
(.500
±
.012)
6.5
MAX.
(.256)
2.3
±
0.2
(.091
±
.007)
Electrical Schematic
Recommended Layout
7.0
(.276)
6.0
(.236)
4.0
(.157)
DIMENSIONS:
MM
(INCHES)
*RoHS Directive 2002/95/EC Jan 27, 2003 including Annex.
Specifications are subject to change without notice.
Customers should verify actual device performance in their specific applications.
SRR1206 Series - Shielded High Power Inductors
Packaging Specifications
330
DIA.
(12.99)
2.0
±
0.5
(.079
±
.020)
30.4
(1.20)
13.0
±
0.5
(.512
±
.020)
DIA.
50.0
(1.969)
21.0
±
0.8
(.827
±
.031)
THICKNESS
0.10
(.004)
MAX.
EMBOSSED
CAVITY
13.0
±
0.5
DIA.
(.512
±
.020)
26
(1.02)
EMBOSSED
CARRIER
END
4
(.157)
START
24
(.945)
6.6
(0.259)
16
(.63)
NO COMPONENT
COMPONENTS
NO COMPONENT
200
(7.874)
11200
(440.945)
400
(15.748)
USER DIRECTION OF FEED
QTY: 600 PCS. PER REEL
DIMENSIONS:
MM
(INCHES)
REV. 09/11
Specifications are subject to change without notice.
Customers should verify actual device performance in their specific applications.
