SERIES:
MD-SMK
│
DESCRIPTION:
MINI DIN CONNECTOR
FEATURES
• PCB mount
• right angle
• side shielded with kinked pins
RoHS
PART NUMBER KEY
MD -
XX
SMK
Base Number
Pin Options
30 = 3 pins
40 = 4 pins
50 = 5 pins
60 = 6 pins
70 = 7 pins
80 = 8 pins
SPECIFICATIONS
parameter
rated input voltage
rated input current
contact resistance
insulation resistance
voltage withstand
insertion force
withdrawal force
operating temperature
life
flammability rating
RoHS
UL94V-0
2011/65/EU
at 250 Vdc
for 1 minute
1
0.8
-40
1,000
50
250
4.5
3
85
at 100 Vac
at 12 Vdc
conditions/description
min
typ
100
12
1
2
30
max
units
Vac
Vdc
A
A
mΩ
MΩ
Vac
kg
kg
°C
cycles
cui.com
For more information, please visit the
product page.
CUI Inc
│
SERIES:
MD-SMK
│
DESCRIPTION:
MINI DIN CONNECTOR
date
09/05/2017
│
page
3 of 4
MECHANICAL DRAWINGS (CONTINUED)
MD-60SMK
6
4
2
1
5
3
MD-70SMK
7
4
2
1
6 5
3
MD-80SMK
8
5
2
7 6
4
1
3
13.5 0.531
5.5 0.217
(2 PLCS)
11.0 0.433
(3 PLCS)
3
0.7X2.2
(3 PLCS)
0.9±0.1 0.035
(7 PLCS)
2.6 0.102
6.8 0.268
PCB LAYOUT
TOP VIEW
5
13.5 0.531
5.5 0.217
(2 PLCS)
11.0 0.433
(4 PLCS)
3
0.7X2.2
(3 PLCS)
0.9 0.035
0.9±0.1 0.035
(8 PLCS)
2.6 0.102
6
13.5 0.531
5.5 0.217
(2 PLCS)
11.0 0.433
(2 PLCS)
3
5
0.9±0.1 0.035
(6 PLCS)
2.6 0.102
1
2
4
6
4.7 0.185
8.5 0.335
(4 PLCS)
4.7 0.185
8.5 0.335
(4 PLCS)
1
2
6
4
7
4.7 0.185
8.5 0.335
(4 PLCS)
1
4
2
7
5
8
0.9 0.035
0.7X2.2
(3 PLCS)
6.8 0.268
PCB LAYOUT
TOP VIEW
6.8 0.268
PCB LAYOUT
TOP VIEW
cui.com
For more information, please visit the
product page.
CUI Inc
│
SERIES:
MD-SMK
│
DESCRIPTION:
MINI DIN CONNECTOR
date
09/05/2017
│
page
4 of 4
REVISION HISTORY
rev.
1.0
1.01
1.02
description
initial release
new template applied
updated datasheet
date
02/23/2006
02/22/2012
09/05/2017
