* Due to "lead Free" nature, Temperature and Dwelling time for the soldering zone is higher than those for Regular. This may
cause damage to other components.
1. Recommended max past thickness > 0.25mm.
2. Devices can be cleaned using standard methods and aqueous solvent.
3. Rework use standard industry practices.
4. Storage Environment : < 30°C/60%RH
Caution:
1. If reflow temperatures exceed the recommended profile, devices may not meet the performance requirements.
2. Devices are not designed to be wave soldered to the bottom side of the board.
www.element14.com
www.farnell.com
www.newark.com
Page <2>
27/03/13
V1.0
Surface Mountable
PTC Resettable Fuse
Dimensions
Part Number
MC33189
MC33192
MC33194
MC33195
MC33197
MC33198
A
Min.
6.73
6.73
6.73
6.73
6.73
6.73
Max.
7.98
7.98
7.98
7.98
7.98
7.98
Min.
4.8
4.8
4.8
4.8
4.8
4.8
B
Max.
5.44
5.44
5.44
5.44
5.44
5.44
Min.
0.6
0.6
0.35
0.4
0.4
0.3
C
Max.
1.15
1.15
1.15
1
0.9
0.9
D
Min.
0.35
0.35
0.35
0.35
0.35
0.35
Dimensions : Millimetres
Part Number Table
Description
Hold
Trip
Current Current
IH, A
Fuse, Resettable,
SMD, 0.3A
Fuse, Resettable,
SMD, 0.5A
Fuse, Resettable,
SMD, 0.75A
Fuse, Resettable,
SMD, 1.1A
Fuse, Resettable,
SMD, 1.5A
Fuse, Resettable,
SMD, 1.85A
0.3
0.5
0.75
1.1
1.5
1.85
IT, A
0.6
1
1.5
2.2
3
3.7
Rated
Voltage
VMax, V
DC
60
60
33
33
33
33
Maximum
Current
IMax, A
10
10
40
40
40
40
Typical
power
Pd, W
1.5
1.5
1.5
1.5
1.5
1.5
Max. Time-to-
Trip
Current Time
A
1.5
2.5
8
8
8
8
Sec
3
4
0.3
0.5
2
2.5
Resistance
Tolerance
RMIN R1MAX
Ω
1
0.3
0.18
0.09
0.05
0.04
Ω
4.8
1.4
1
0.41
0.23
0.15
Time-
to-trip
Curve
Option
Option A
Option B
Option C
Option D
Option F
Option G
Thermal
Derating
Curve
option
Option A
Option A
Option A
Option A
Option B
Option B
Part
Number
MC33189
MC33192
MC33194
MC33195
MC33197
MC33198
Important Notice :
This data sheet and its contents (the “Information”) belong to the members of the Premier Farnell group of companies (the “Group”) or are licensed to it. No licence is granted
for the use of it other than for information purposes in connection with the products to which it relates. No licence of any intellectual property rights is granted. The Information is subject to change
without notice and replaces all data sheets previously supplied. The Information supplied is believed to be accurate but the Group assumes no responsibility for its accuracy or completeness, any
error in or omission from it or for any use made of it. Users of this data sheet should check for themselves the Information and the suitability of the products for their purpose and not make any
assumptions based on information included or omitted. Liability for loss or damage resulting from any reliance on the Information or use of it (including liability resulting from negligence or where the
Group was aware of the possibility of such loss or damage arising) is excluded. This will not operate to limit or restrict the Group’s liability for death or personal injury resulting from its negligence.
