MIL-DTL-38999 Series IV, Breech Coupling
38999/43 jam-nut mount receptacle
SERIES IV HERMETIC
QPL Part Number Development
Sample Part Number
D38999
Class
Shell Size
Insert Arrangement
Contact Style
Polarization
38999/43
= Jam-Nut receptacle
N
= Hermetic, CRES, nickel finish, conductive, -65°C to 200°C
Y
= Hermetic, CRES, passivate finish, conductive, -65°C to 200°C
B, C, D, E, F, G, H, J
Per MIL-STD-1560; See reference information section for details
P
= Pin, solder cup
S
= Socket, solder cup
X
= Pin, eyelet
Z
= Socket, eyelet
C
= Pin, PCB flex feedthrough
D
= Socket, PCB flex feedthrough
D38999/43
Y
B
35
P
N
N
(Normal),
A, B, C, D, K, L, M, R;
see polarization positions table
Polarization Position
XX
YY
N
110°
250°
A
100°
260°
B
90°
270°
C
80°
280°
D
70°
290°
K
120°
255°
L
120°
265°
M
120°
275°
R
120°
285°
Wire Accommodation
Contact Size
22D
20
16
12
1.449 Max
(36.8)
Master
Keyway
(Blue)
1.100
(27.9)
G
Panel
Thickness
H
Wire Gauge
#22 - #28
#20 - #24
#16 - #20
#12 - #14
Contact Size
FEEDTHROUGH CONTACT
STYLE C AND D
P
SIZE 12 AND SIZE 16
.050 ± .015
(1.27 ± 0.38)
SIZE 22D AND SIZE 20
90°/85°
O-Ring
Solder Cup
Contact (P, S)
Eyelet
Contact (X, Z)
Feedthrough
Contact (C, D)
XX°
P
B
C
Flat
Contact
Size
22D
20
16
12
ø P
.011 (0.28)
.015 (0.38)
.024 (0.61)
.028 (0.71)
.0635 (1.61)
.0615 (1.56)
.095 (2.41)
.093 (2.36)
Full-Mate
Indicator (Blue)
F Thread
Nut
Per D38999/28
.335
(8.5)
Max
P
(See Contact
Size Table)
D
DIA
E
DIA
A DIA
B
YY°
.175/.125
(4.4/3.2)
.232 (5.9) Max
56
© 2017 Glenair, Inc • 1211 Air Way, Glendale, CA 91201 • 818-247-6000 • www.glenair.com • U.S. CAGE code 06324 • MIL-DTL-38999 Series III and IV
Dimensions in inches (millimeters) are subject to change without notice
COTS EQUIVALENT
MIL-DTL-38999 Series IV, Breech Coupling
234-100-H7 jam-nut mount receptacle
SERIES IV HERMETIC
COTS Part Number Development
Sample Part Number
Series / Basic Part No.
234-100-H7
= Hermetic, jam-nut mount hermetic receptacle
Material/Finish
Shell Size
Insert Arrangement
Contact Style
Polarization
ZL
= CRES, nickel finish, conductive, -65°C to 200°C
Z1
= CRES, passivate finish, conductive, -65°C to 200°C
11, 13, 15, 17, 19, 21, 23, 25
Per MIL-STD-1560; See reference information section for details
P
= Pin, solder cup
S
= Socket, solder cup
X
= Pin, eyelet
Z
= Socket, eyelet
C
= Pin, PCB flex feedthrough
D
= Socket, PCB flex feedthrough
234-100-H7
Z1
11
-35
P
N
N
(Normal),
A, B, C, D, K, L, M, R
see polarization position position table
Additional material/finish options are available, consult factory for ordering information.
Dimensions
SHELL
SIZE
CODE
B
C
D
E
F
G
H
J
SHELL
SIZE
11
13
15
17
19
21
23
25
A
DIA
1.385(35.2)
1.362(34.6)
1.511(38.4)
1.488(37.8)
1.637(41.6)
1.614(41.0)
1.763(44.8)
1.740(44.2)
1.948(49.5)
1.925(48.9)
2.074(52.7)
2.051(52.1)
2.200(55.9)
2.177(55.3)
2.326(59.1)
2.299(58.4)
J Dia
B
1.267 (32.18)
1.232 (31.29)
1.393 (35.38)
1.358 (34.49)
1.519 (38.58)
1.484 (37.69)
1.641 (41.68)
1.606 (40.79)
1.830 (46.48)
1.795 (45.59)
1.956 (49.68)
1.921 (48.79)
2.078 (52.78)
2.043 (51.89)
2.204 (55.98)
2.169 (55.09)
C
FLAT
.754(19.2)
.745(18.9)
.941(23.9)
.932(23.7)
1.065(27.1)
1.056(26.8)
1.190(30.2)
1.181(30.0)
1.316(33.4)
1.306(33.2)
1.441(36.6)
1.431(36.3)
1.565(39.8)
1.556(39.5)
1.692(43.0)
1.681(42.7)
D
DIA
.732(18.6)
.716(18.2)
.858(21.8)
.839(21.3)
.984(25.0)
.968(24.6)
1.110(28.2)
1.091(27.7)
1.236(31.4)
1.220(31.0)
1.358(34.5)
1.342(34.1)
1.484(37.7)
1.468(37.3)
1.610(40.9)
1.594(40.5)
E DIA
±.010(0.3)
.769(19.5)
.899(22.8)
1.025(26.0)
1.147(29.1)
1.273(32.3)
1.399(35.5)
1.525(38.7)
1.647(41.8)
F THREAD
ISO METRIC
1.0-6g
M20
M25
M28
M32
M35
M38
M41
M44
G
±.033(0.8)
.092(2.3)
.092(2.3)
.092(2.3)
.092(2.3)
.092(2.3)
.092(2.3)
.092(2.3)
.092(2.3)
H
±.012(0.3)
.106(2.7)
.106(2.7)
.106(2.7)
.106(2.7)
.137(3.5)
.137(3.5)
.137(3.5)
.137(3.5)
Panel Cut-Out Dimensions
Shell Size Code
B
K
C
D
Panel Cut-Out
E
J Dia
.835 (21.21)
.825 (20.96)
1.020 (25.91)
1.010 (25.65)
1.145 (29.08)
1.135 (28.83)
1.270 (32.26)
1.260 (32.00)
K
.771 (19.58)
.761 (19.33)
.955 (24.26)
.945 (24.00)
1.085 (27.56)
1.075 (27.31)
1.210 (30.73)
1.200 (30.48)
Shell Size Code
F
G
H
J
J Dia
1.395 (35.43)
1.385 (35.18)
1.520 (38.61)
1.510 (38.35)
1.645 (41.78)
1.635 (41.53)
1.770 (44.96)
1.760 (44.70)
K
1.335 (33.91)
1.325 (33.66)
1.460 (37.08)
1.450 (36.83)
1.585 (40.26)
1.575 (40.01)
1.710 (43.43)
1.700 (43.18)
Additional Material/Finish Options
Finish Code
Z1S†
Description
CRES, passivate finish, conductive, -65°C to 200°C, space-grade
† Connectors ordered with “Z1S” include outgas processing to conform to outgassing requirements of Class H.
© 2017 Glenair, Inc • 1211 Air Way, Glendale, CA 91201 • 818-247-6000 • www.glenair.com • U.S. CAGE code 06324 • MIL-DTL-38999 Series III and IV
Dimensions in inches (millimeters) are subject to change without notice
57
