2EZ120D5: DescriptionZener Diode, 120V V(Z), 5%, 2W, Silicon, Unidirectional, DO-15, PLASTIC PACKAGE-2; CategoryDiscrete semiconductor diode; File Size169KB，4 Pages; ManufacturerMicro Commercial Components (MCC)

Download Datasheet Parametric Compare View All

2EZ120D5 Overview

Zener Diode, 120V V(Z), 5%, 2W, Silicon, Unidirectional, DO-15, PLASTIC PACKAGE-2

2EZ120D5 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Parts packaging code	DO-15
package instruction	O-PALF-W2
Contacts	2
Reach Compliance Code	compli
ECCN code	EAR99
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	ZENER DIODE
JEDEC-95 code	DO-15
JESD-30 code	O-PALF-W2
JESD-609 code	e0
Number of components	1
Number of terminals	2
Package body material	PLASTIC/EPOXY
Package shape	ROUND
Package form	LONG FORM
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
polarity	UNIDIRECTIONAL
Maximum power dissipation	2 W
Certification status	Not Qualified
Nominal reference voltage	120 V
surface mount	NO
technology	ZENER
Terminal surface	TIN LEAD
Terminal form	WIRE
Terminal location	AXIAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Maximum voltage tolerance	5%
Working test current	4.2 mA
Base Number Matches	1

Preview

Download Datasheet

View All

•

Features

omponents

20736 Marilla

Street Chatsworth

!"#

$ % !"#

2EZ11D5

THRU

2EZ200D5

2 W Glass Passivated

Junction Silicon

Zener Diode

11-200 Volts

DO-15

Low Profile Package

Built-in Strain Relief

Glass Passivated Junction

Low Inductance

Excellent Clamping Capability

Mechanical Data

CASE: JEDEC DO-15 Molded plastic over passivated junction

WEIGHT: 0.015 ounce, 0.04 gram

TERMINALS : Solder plated, solderable per MIL-STD-750,

method 2026

POLARITY : Color band denotes positive end (cathode)

Maximum Ratings @ 25

C Unless Otherwise Specified

Peak Pulse Power

Dissipation (Note A)

Derate above 75 C

Watts

mW/

Cathode

Mark

Peak Forward Surge

Current 8.3ms single

half sine-wave

FSM

superimposed on rated

load (JEDEC Method)

(Note B)

Operating And

, T

STG

Storage

Temperature Range

Amps

-55

C to

+150

NOTES:

A. Mounted on 5.0mm

(.013mm thick) land areas.

B. Measured on 8.3ms, single half sine-wave or equivalent

square wave, duty cycle = 4 pulses per minute maximum.

DIMENSIONS

INCHES

DIM

MIN

0.230

0.104

0.028

1.000

MAX

0.300

0.140

0.034

-----

MIN

5.80

2.60

0.71

25.40

MAX

7.60

3.60

0.86

-----

NOTE

www.mccsemi.com

Revision: 3

2002/12/31
