R1150H Series
Voltage Regulator (with Wide Input Voltage Range) with Reset for Automotive Applications
NO.EC-081-131127
OUTLINE
The R1150H series are CMOS-based voltage regulator (VR) ICs equipped with a voltage detector (VD). VR
function of the R1150Hxxxx has features of low dropout voltage, high output voltage accuracy, and ultra-low
supply current. Each of the R1150HxxxA series includes also a chip enable circuit. The output of built-in voltage
detector is Nch open drain type. The R1150HxxxC/D have a pin for connecting external capacitor to set a certain
reset delay time instead of chip enable control pin.
The regulator output voltage and the detector threshold voltage are fixed in the IC, Output Voltage Accuracy is
±2.0%, while Detector Threshold Accuracy is ±2.5%. The R1150HxxxA (with chip enable function) and
R1150HxxxC series can supervise input voltage by the built-in detector. R1150HxxxB can supervise SENSE pin
voltage by the built-in detector. R1150HxxxD type can supervise V
OUT
voltage, or Regulator Output Voltage of this
IC itself.
Since the package for these ICs is the SOT-89-5 package, high density mounting of the ICs on boards is
possible.
FEATURES
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Input Voltage (Maximum Rating)....................... Max. 24.0V (26V)
Supply Current .................................................. Typ. 7.0μA
Output Voltage (VR) .......................................... 2.1V to 14.0V (0.1V steps)
Detector Threshold Voltage (V
DET
) .................... 2.0V to 15.0V (R1150HxxxB/C/D)
2.3V to 15.0V (R1150HxxxA)
Output Voltage Accuracy................................... ±2.0% (VR), ±2.5% (VD)
Output Current .................................................. Min. 150mA (V
OUT
=5.0V)
Output Voltage Temperature Coefficient ........... Typ.
±100
ppm/°C
Detector Threshold Temperature Coefficient .... Typ.
±100
ppm/°C
Package ............................................................ SOT-89-5
Built-in Fold-Back Protection Circuit ................. Typ. 45mA (Current at short mode)
Built-in Thermal Shutdown Circuit (VR) ............ Thermal Shutdown Temperature: Typ. 150°C
Released Temperature: Typ. 120°C
Monitoring V
DD
voltage ...................................... R1150HxxxA/C
Monitoring sense pin (SENSE) voltage ............ R1150HxxxB
Monitoring V
OUT
pin voltage ............................... R1150HxxxD
APPLICATIONS
•
Power source for accessories such as car audios, car navigation systems, and ETC systems
•
Power source for ECUs such as EV inverter and battery charge control unit
1
R1150H
NO.EC-081-131127
SELECTION GUIDE
The output voltage, detector threshold and the usage of pin No.3 (as a kind of types in the R1150H Series) for
the ICs can be selected at the user’s request.
Product Name
R1150Hxxx∗-T1-#E
Package
SOT-89-5
Quantity per Reel
1,000 pcs
Pb Free
Yes
Halogen Free
Yes
xxx : Specify a combination of output voltage and detector threshold.
∗
: Designation of the usage of pin No.3 and detector function;
(A) with CE pin and V
IN
detect
(B) with SENSE pin
(C) with C
D
pin and V
IN
detect
(D) with C
D
pin and V
OUT
detect
# : Specify Automotive Class Code
Operating
Temperature Range
-40°C to 85°C
-40°C to 85°C
Guaranteed Specs
Temperature Range
25°C
25°C
Screening
High Temperature
High and Low Temperature
A
H
PIN DESCRIPTION
•
SOT-89-5
5
4
1
2
3
Pin No.
Symbol
Description
1
2
3
4
5
V
OUT
GND
CE
SENSE
C
D
V
DET
V
DD
Voltage Regulator Output Pin
Ground Pin
Chip Enable Pin (A Ver.)
Sense Pin for Voltage Detector (B Ver.)
Pin for Capacitor for Setting Output Delay of Voltage Detector (C/D Ver.)
Voltage Detector Output Pin
Input Pin
3
R1150H
NO.EC-081-131127
ABSOLUTE MAXIMUM RATINGS
Symbol
Item
Rating
Unit
V
IN
V
CE
V
SENSE
V
CD
V
DET
V
OUT
I
OUT1
I
OUT2
P
D
Tj
T
stg
Input Voltage
Input Voltage (CE Input Pin, A Version)
Input Voltage (SENSE Input Pin, B Version)
Input Voltage (C
D
Input Pin, C/D Version)
Output Voltage (V
DET
Output Pin)
Output Voltage
Output Current (VR)
Output Current (VD)
Power Dissipation (SOT-89-5)
∗
Junction Temperature
Storage Temperature
Standard Land Pattern
High Wattage Land Pattern
26.0
−
0.3 to V
IN
+0.3
−
0.3 to V
IN
+0.3
−
0.3 to V
IN
+0.3
−
0.3 to 26.0
−
0.3 to V
IN
+0.3
V
V
V
V
V
V
mA
mA
mW
°
C
°
C
250
10
900
1300
−
40 to 125
−
55 to 125
∗
) Refer to
PACKAGE INFORMATION
for detailed information.
ABSOLUTE MAXIMUM RATINGS
Electronic and mechanical stress momentarily exceeded absolute maximum ratings may cause the permanent
damages and may degrade the life time and safety for both device and system using the device in the field.
The functional operation at or over these absolute maximum ratings is not assured.
RECOMMENDED OPERATING RATINGS
Symbol
Item
Rating
Unit
V
DD
V
SENSE
Ta
Input Voltage
Input Voltage (SENSE Input Pin)
Operating Temperature Range
1.2 to 24.0
0 to V
IN
+ 0.3
−
40 to 85
V
V
°
C
RECOMMENDED OPERATING RATINGS
All of electronic equipment should be designed that the mounted semiconductor devices operate within the
recommended operating ratings. The semiconductor devices cannot operate normally over the recommended
operating ratings, even if when they are used over such ratings by momentary electronic noise or surge. And the
semiconductor devices may receive serious damage when they continue to operate over the recommended
operating ratings.
4
R1150H
NO.EC-081-131127
ELECTRICAL CHARACTERISTICS
•
R1150HxxxA
(Ta=25°C)
For all
Symbol
Item
Conditions
Min.
Typ.
Max.
Unit
μ
A
I
SS
Supply Current
V
IN
=V
CE
V
OUT
≥
(-V
DET
): V
IN
=V
OUT
+2.0V
V
OUT
< (-V
DET
): V
IN
=(-V
DET
)+2.0V
V
DD
=24V,
V
CE
=0V
2.3
≤
-V
DET
≤
3.0
3.1
≤
-V
DET
≤
15.0
7
2.5
3.0
150
120
14
5.0
6.0
I
standby
T
TSD
T
TSR
VR
Symbol
Standby Current
Thermal Shutdown
Temperature
Thermal Shutdown
Released Temperature
Item
μ
A
°
C
°
C
Junction Temperature
Junction Temperature
Conditions
Min.
×
0.98
Typ.
(
Ta=25°C)
Max.
Unit
×
1.02
V
OUT
I
OUT1
Δ
V
OUT
/
Δ
I
OUT
Δ
V
OUT
/
Δ
V
IN
Output Voltage
Output Current
Load Regulation
Line Regulation
Dropout Voltage
Short Current Limit
CE "H" Input Voltage
CE "L" Input Voltage
V
IN
=V
OUT
+2.0V, I
OUT
=20mA
V
IN
=V
OUT
+2.0V
V
IN
=V
OUT
+2.0V
1mA
≤
I
OUT
≤
40mA
V
IN
=V
OUT
+2.0V, I
OUT
=20 mA
V
OUT
+1V
≤
V
IN
≤
24V
I
OUT
=20mA
V
OUT
=0V
V
Refer to the
Product-specific
Electrical Characteristics
0.05
0.15
%/V
V
DIF
I
SC
V
CEH
V
CEL
VD
Symbol
Refer to the
Product-specific
Electrical Characteristics
45
1.5
0
V
IN
0.25
mA
V
V
Item
Conditions
Min.
×
0.975
Typ.
(
Ta=25°C)
Max.
Unit
×
1.025
-V
DET
V
HYS
I
OUT2
V
DDL
t
PLH
Detector Threshold
Detector Threshold
Hysteresis
Output Current
(Driver Output Pin)
Minimum Operating
Voltage
Output Delay Time
V
IN
=
2V, V
DS
=
0.05V
*Note 1
*Note 2
V
V
mA
-V
DET
×
0.03
0.17
-V
DET
×
0.05
-V
DET
×
0.07
0.9
0.5
1.2
1.0
V
ms
Note 1) This item means V
DD
Voltage when Output Voltage is equal or less than 0.1V.
(Pull-up Resistor=470kW, Pull up Voltage=5V)
Note 2) V
DET
pin is pulled up to V
DD
via 470kW. t
PLH
means time interval from rising edge of V
DD
from
(-V
DET
)
−
2.0V to (-V
DET
) +2.0V to the point of Output Voltage being 80% of pull-up voltage.
5
