MCC
Features
•
•
•
•
TM
Micro Commercial Components
omponents
20736 Marilla
Street Chatsworth
!"#
$
% !"#
DK400LP
•
Small surface mounting type
Epoxy meets UL 94 V-0 flammability rating
Moisture Sensitivity Level 1
Lead Free Finish/RoHS Compliant ("P" Suffix designates
RoHS Compliant. See ordering information)
Marking:7
100 mA
Switching Diode
80 Volts
SOD-882
D
Maximum Ratings
Symbol
V
R
I
O
I
FSM
T
J
T
STG
Rating
DC Reverse Voltage
Mean Rectifying Current
Peak Forward Surge Current*
Junction Temperature
Storage Temperature
Rating
80
100
0.5
125
-40 to +125
UnitUnit
V
mA
A
B
A
C
L
H
Electrical Characteristics @ 25
O
C Unless Otherwise Specified
Symbol
Parameter
Forward Voltage
(I
F
=100mAdc)
Reverse Current
(V
R
=80Vdc)
Reverse Recovery Time
(V
R
=6V,If=10mA,Rl=10Ohm)
Min
Typ
Max
Units
F
G
E
V
F
I
R
T
rr
---
---
---
---
---
---
1.2
0.1
4.0
Vdc
_
uAdc
ns
+
DIM
A
B
C
D
E
F
G
H
L
DIMENSIONS
INCHES
MM
MIN
MAX
MIN
MAX
0.018
0.022
0.45
0.55
0.000
0.003
0.01
0.07
0.018REF.
0.450REF.
0.037
0.041
0.95
1.05
0.022
0.026
0.55
0.65
0.016 REF.
0.400 REF.
0.011
0.013
0.275
0.325
0.000 REF.
0.010 REF.
0.011
0.013
0.275
0.325
NOTE
www.mccsemi.com
Revision:
A
1 of
3
2011/08/11
MCC
Ordering Information :
Device
Part Number-TP
Packing
Tape&Reel:
5Kpcs/Reel
***IMPORTANT NOTICE***
Micro Commercial Components Corp.
reserves the right to make changes without further notice to any product herein to
make corrections, modifications , enhancements , improvements , or other changes .
Micro Commercial Components
Corp .
does not assume any liability arising out of the application or use of any product described herein; neither does it
convey any license under its patent rights ,nor the rights of others . The user of products in such applications shall assume all
risks of such use and will agree to hold
Micro Commercial Components Corp .
and all the companies whose products are
represented on our website, harmless against all damages.
***LIFE SUPPORT***
MCC's products are not authorized for use as critical components in life support devices or systems without the express written
approval of Micro Commercial Components Corporation.
***CUSTOMER AWARENESS***
Counterfeiting of semiconductor parts is a growing problem in the industry. Micro Commercial Components (MCC) is taking
strong measures to protect ourselves and our customers from the proliferation of counterfeit parts. MCC strongly encourages
customers to purchase MCC parts either directly from MCC or from Authorized MCC Distributors who are listed by country on
our web page cited
below.
Products customers buy either from MCC directly or from Authorized MCC Distributors are genuine
parts, have full traceability, meet MCC's quality standards for handling and storage.
MCC will not provide any warranty
coverage or other assistance for parts bought from Unauthorized Sources.
MCC is committed to combat this global
problem and encourage our customers to do their part in stopping this practice by buying direct or from authorized
distributors.
www.mccsemi.com
Revision: A
3
of
3
2011/08/11
