V285ME10
PHASE NOISE (1 Hz BW, typical)
14118 Stowe Drive, Suite B | Poway, CA 92064
TEL: (858) 621-2700 | FAX: (858) 486-1927
URL: www.zcomm.com
EMAIL: applications@zcomm.com
Rev B2
Applications
•
Satellite Modems
•
Mobile Radios
•
Earthstations
Application Notes
• AN-101: Mounting and Grounding
• AN-102: Output Loading
• AN-107: Manual Soldering
£(f) (dBc/Hz)
Voltage-Controlled Oscillator
Surface Mount Module
OFFSET (Hz)
Performance Specifications
Oscillation Frequency Range
Phase Noise @ 10 kHz offset (1 Hz BW)
Harmonic Suppression (2nd)
Tuning Voltage
Tuning Sensitivity (avg.)
Power Output
Load Impedance
Input Capacitance
Pushing
Pulling (14 dB Return Loss, Any Phase)
Operating Temperature Range
Package Style
Power Supply Requirements
Supply Voltage (Vcc, nom.)
Supply Current (Icc)
Additional Notes
Min
240
Typ
-105
-9
Max
270
Units
MHz
dBc/Hz
dBc
0.5
15
3.5
6
50
4.5
8.5
200
3
1
Vdc
MHz/V
dBm
pF
MHz/V
MHz
°C
-40
MINI-16
Min
Typ
5
12
85
Max
20
Units
Vdc
mA
LFSuffix = RoHS Compliant. All specifications are subject to change without notice.
© Z-Communications, Inc. All Rights Reserved.
Page 1 of 2
FRM-S-002 B
Voltage-Controlled Oscillator
Surface Mount Module
Tuning Curve, typ.
V285ME10
Rev B2
300
FREQUENCY (MHz)
290
280
270
260
250
240
230
220
210
200
0
0.5
1
1.5
2
2.5
3
3.5
4
4.5
5
85 °C
25 °C
-40 °C
TUNING VOLTAGE (Vdc)
Power Curve, typ.
Footprint
RECOMMENDED FOOTPRINT
16
14
12
10
8
6
4
2
0
209
POWER OUTPUT (dBm)
SEVERAL HOLES OF O 0.015 ON
GND. PLANE ARE RECOMMENDED
FOR GOOD GROUNDING.
0.030 MIN. CUTBACK
FROM LIVE PADS
223
234
243
251
258
264
270
277
283
289
FREQUENCY (MHz)
85 °C
25 °C
-40 °C
Physical Dimensions
PIN CONFIGURATION
P1
P2
P3
REST
Vt
RF OUT
Vcc
GROUND
H
0.220
0.160
0.130
0.100
0.085
Z-COMM
XXXXXXXX-LF
W/O#
D/C
PACKAGE
MINI-16
MINI-16-LOW
MINI-16-L
MINI-16-UL
MINI-16-EL
NOTE: ALL DIMENSIONS ARE IN INCHES
TOL: XXX: +/- 0.010
LFSuffix = RoHS Compliant. All specifications are subject to change without notice.
© Z-Communications, Inc. All Rights Reserved.
Page 2 of 2
FRM-S-002 B
