Cross Reference Guide
TM6681 / SM6681*
* Part number for additional environmental screening.
Performance Data
Frequency
Gain
Noise Figure
P
1dB
3
rd
Order Intercept
2
nd
Order Intercept
VSWR
Reverse Isolation
Power Supply
Operating Temperature
20.0 - 500.0 MHz
17.5 dB Typical
15.5 dB Min
3.0 dB Typical
4.0 dB Max
9.5 dBm Typical
7.0 dBm Min
23.0 dBm Typical
28.0 dBm Typical
1.4/2.0 Input Typ/Max
1.1/2.0 Output Typ/Max
-37.0 dB Typical
-35.0 dB Min
15.0 Volts
29.0 mA
-55.0 - 85.0 °C
Package Drawing
Gain
dB
Frequency (MHz)
Noise Figure
dB
Frequency (MHz)
P
1dB
Compression Point
dBm
Frequency (MHz)
Reverse Isolation
dB
Frequency (MHz)
Input VSWR
Frequency (MHz)
Output VSWR
Frequency (MHz)
S-Parameters
Frequency S11 Mag S11 Ang S21 Mag S21 Ang S12 Mag S12 Ang S22 Mag S22 Ang
10.0
50.0
100.0
200.0
300.0
400.0
500.0
0.298
0.055
0.067
0.136
0.182
0.200
0.291
-83.90
-161.90
107.50
41.40
-8.80
-77.40
152.20
7.207
7.550
7.530
7.292
7.111
7.465
7.367
-156.00
164.20
139.10
93.90
48.40
-2.10
-80.90
0.011
0.011
0.011
0.010
0.011
0.007
0.005
15.40
-19.90
-19.30
-31.60
-32.10
-60.20
-122.90
0.034
0.029
0.020
0.031
0.037
0.022
0.033
165.30
167.50
-178.50
-111.00
-126.10
-114.60
-122.00
Absolute Maximum Conditions
Maximum Operating Temperature
Maximum Case Temperature
Continuous RF Input Power
Maximum Peak Power
(3 µsec max)
-55.0 - 100.0 °C
125.0 °C
10.0 dBm
0.5 W
Maximum Storage Temperature
Maximum Supply Voltage
Short Term RF Input Power
(1 minute max)
-62.0 - 125.0 °C
18.0 Volts
50.0 mW
