IHLP-2525BD-A1
Vishay Dale
Low Profile, High Current IHLP
®
Inductors
FEATURES
• Lowest height (2.4 mm) in this package
footprint
• Shielded construction
• Frequency range up to 5.0 MHz
• Lowest DCR/μH, in this package size
• Handles high transient current spikes without
saturation
• Ultra low buzz noise, due to composite
construction
• AEC-Q200 qualified
• Compliant to RoHS Directive 2002/95/EC
Manufactured under one or more of the following:
US Patents; 6,198,375/6,204,744/6,449,829/6,460,244.
Several foreign patents, and other patents pending.
STANDARD ELECTRICAL SPECIFICATIONS
L
0
INDUCTANCE
± 20 % AT 100 kHz,
0.25 V, 0 A
(μH)
0.1
0.22
0.33
0.47
0.68
0.82
1.0
1.5
2.2
3.3
4.7
6.8
8.2
10
DCR
TYP.
25 °C
(m)
1.5
2.9
3.7
6.0
8.7
10.6
13.1
18.5
28.0
36.5
45.2
72.5
84.2
115.6
HEAT
RATING SATURATION
DCR
MAX. CURRENT
CURRENT
25 °C DC TYP.
DC TYP.
(A)
(3)
(m)
(A)
(4)
1.7
3.2
4.1
6.5
9.4
11.8
14.2
21.2
34.0
51.6
63
95
106
129
30
21
18
13.5
11
10
9.0
7.5
6.5
5.0
4.5
3.5
3.0
2.5
50
34
22
21
18
17
16
15
14
13
10
9
8
7
APPLICATIONS
Engine and transmission control units
Diesel injection drivers
DC/DC converters for entertainment/navigation systems
Noise suppression for motors
- Windshield wipers
- Power seats
- Power mirrors
- Heating and ventilation blowers
- HID lighting
• LED drivers
•
•
•
•
DIMENSIONS
in inches [millimeters]
Typical Pad Layout (Min.)
0.255 ± 0.010
[6.47 ± 0.254]
0.125 ± 0.010
[3.18 ± 0.254]
0.135
[3.429]
0.270 ± 0.015
[6.86 ± 0.381]
0.325
[8.255]
0.135
[3.429]
Notes
(1)
All test data is referenced to 25 °C ambient
(2)
Operating temperature range - 55 °C to + 125 °C
(3)
DC current (A) that will cause an approximate
T
of 40 °C
(4)
DC current (A) that will cause L to drop approximately 20 %
0
(5)
The part temperature (ambient + temp. rise) should not exceed
125 °C under worst case operating conditions. Circuit design,
component placement, PWB trace size and thickness, airflow
and other cooling provisions all affect the part temperature. Part
temperature should be verified in the end application.
0.095 [2.4] Max.
0.050 ± 0.012
[1.27 ± 0.300]
DESCRIPTION
IHLP-2525BD-A1
MODEL
1.0 μH
INDUCTANCE VALUE
± 20 %
INDUCTANCE TOLERANCE
ER
PACKAGE CODE
e3
JEDEC LEAD (Pb)-FREE STANDARD
GLOBAL PART NUMBER
I
H
L
P
2
5
2
SIZE
5
B
D
E
R
1
R
INDUCTANCE
VALUE
0
M
TOL.
A
1
PRODUCT FAMILY
PACKAGE
CODE
SERIES
** Please see document “Vishay Material Category Policy”:
www.vishay.com/doc?99902
Document Number: 34240
Revision: 17-May-11
For technical questions, contact:
magnetics@vishay.com
www.vishay.com
1
This document is subject to change without notice.
