DBMAM25S-F0

Description
D Subminiature Connector, 25 Contact(s), Female, Crimp Terminal,
CategoryThe connector    The connector
File Size120KB，2 Pages
ManufacturerITT
Websitehttp://www.ittcannon.com/
Download Datasheet Parametric View All

DBMAM25S-F0 Online Shopping

Suppliers Part Number Price MOQ In stock
DBMAM25S-F0 - - View Buy Now

DBMAM25S-F0 Overview

D Subminiature Connector, 25 Contact(s), Female, Crimp Terminal,

DBMAM25S-F0 Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
MakerITT
Reach Compliance Codecompliant
Connector typeD SUBMINIATURE CONNECTOR
Contact to complete cooperationGOLD OVER NICKEL
Contact point genderFEMALE
Contact materialCOPPER ALLOY
DIN complianceNO
empty shellYES
Filter functionNO
IEC complianceNO
insulator materialDIALLYL PHTHALATE/POLYESTER
MIL complianceNO
Mixed contactsNO
Installation typeCABLE
OptionsGENERAL PURPOSE
Shell surfaceCHROMATE
Shell materialSTEEL
Housing size3/B
Termination typeCRIMP
Total number of contacts25

DBMAM25S-F0 Preview

Page 1 of 2
Home|Sign In|Contact Us
Go
Standard D (Machined)
PART NUMBER: DBMAM25S-F0
Where Sold
Product Group
Product Sub-Family
Component Type
Application Type
Cable or PC Board
Gender
Number of Signal Pins
Number of Size 8 contacts
Straight or Right Angle
Shell Plating
Hardware
Other Features
Contact Termination
Shell Size
Temperature Rating
Current Capacity
Contact Resistance
Asia Pacific, Europe, Americas
D-Subminiature
D-Sub Standard
Connector
Military/High Reliability
Cable
Receptacle
25
0
Straight
Yellow Chromate over Zinc
3,05 (.120) Through Holes
Metal Contact Retention Clips
Crimp, Contacts Sold Separatly
DB
-55°C to +125°C
5A
8 milli ohms max.
mhtml:file://\\bnsndv35\data\bitting\CF_PROCESS\BAE\08052007\ITTC\datasheet44.mht
8/13/2007
Page 2 of 2
Dielectric Withstanding Voltage
Reference Industry Specifications
Insulator Material
Shell Material
Other Information
1250 V AC at Sea Level
Mil-PRF-24308
White (or Green) Polyester (or Dially Phthalate)
Steel
See Contact Section for Crimp Contacts
