Bulletin I0149J rev. H 05/06
IR1H40CSPTR
Flipky
TM
1 Amp
Features
Ultra Low V
F
per Footprint Area
Low Leakage
Low Thermal Resistance
One-fifth Footprint of SMA
Super Low Profile (<.7mm)
Available Tested on Tape & Reel
Flipky
TM
Major Ratings and Characteristics
Characteristics
I
F(AV)
Rectangularwaveform
V
RRM
I
FSM
V
F
T
J
@ tp = 5
μs
sine
@1.0 Apk, T
J
=125°C
range
Description
Units
A
V
A
V
°C
True chip-scale packaging is available from International
Rectifier. The IR1H40CSPTR surface-mount Schottky
rectifier has been designed for applications requiring low
forward drop and very small foot prints on PC boards.
Typical applications are in disk drives, switching power
supplies, converters, free-wheeling diodes, battery charg-
ing, and reverse battery protection.
Small foot print, surface mountable
Low forward voltage drop
High frequency operation
Guard ring for enhanced ruggedness and long term
reliability
The Flipky
TM
package, is one-fifth the footprint of a
comparable SMA package and has a profile of less then
.7mm. Combined with the low thermal resistance of the die
level device, this makes the Flipky
TM
the best device for
application where printed circuit board space is at a
premium and in extremely thin application environments
such as battery packs, cell phones and PCMCIA cards.
Values
1.0
40
250
0.42
- 55 to 150
Document Number: 93433
www.vishay.com
1
IR1H40CSPTR
Bulletin I0149J rev. H 05/06
Voltage Ratings
Part number
V
R
Max. DC Reverse Voltage (V)
V
RWM
Max. Working Peak Reverse Voltage (V)
IR1H40CSPTR
40
Absolute Maximum Ratings
Parameters
I
F(AV)
Max. Average Forward Current
I
FSM
E
AS
I
AR
Max. Peak One Cycle Non-Repetitive
Surge Current @ 25°C
Non- Repetitive Avalanche Energy
Repetitive Avalanche Current
Value
1.0
250
21
10
2.0
Units
A
A
Conditions
50% duty cycle @ T
PCB
= 117 °C, rectangular wave form
5μs Sine or 3μs Rect. pulse
10ms Sine or 6ms Rect. pulse
Following any rated
load condition and
with rated V
RRM
applied
mJ
A
T
J
= 25 °C, I
AS
= 2.0A, L = 5.0mH
Current decaying linearly to zero in 1
μsec
Frequency limited by T
J
max. Va = 1.5 x Vr typical
Electrical Specifications
Parameters
V
FM
Max. Forward Voltage
Drop
* See Fig. 1
I
RM
Max. Reverse Leakage (1)
Current
* See Fig. 2
(1)
Typ.
0.48
0.53
0.36
0.43
4
0.5
0.2
0.15
2.5
0.9
0.6
0.5
Max. Units
0.52
0.57
0.42
0.50
10
1
0.5
0.3
4
2
1.5
1
160
10000
pF
V/
μs
(Rated V
R
)
mA
T
J
= 125 °C
μA
V
@ 1A
@ 2A
@ 1A
@ 2A
T
J
= 25 °C
Conditions
T
J
= 25 °C
T
J
= 125 °C
V
R
= rated V
R
V
R
= 20V
V
R
= 10V
V
R
= 5V
V
R
= rated V
R
V
R
= 20V
V
R
= 10V
V
R
= 5V
V
R
= 5V
DC
(test signal range 100kHz to 1MHz) 25°C
C
T
Max. Junction Capacitance
-
-
dv/dt Max. Volatge Rate of Charge
(1) Pulse Width < 300μs, Duty Cycle < 2%
Thermal-Mechanical Specifications
Parameters
T
J
T
stg
Max. Junction Temperature Range (*)
Max. Storage Temperature Range
Value
- 55 to 150
- 55 to 150
40
62
Units
°C
°C
°C/W DC operation
°C/W
Conditions
R
thJL
Typ. Thermal Resistance Junction
to PCB
(**)
R
thJA
Max. Thermal Resistance Junction
to Ambient
(*) dPtot
<
1
thermal runaway condition for a diode on its own heatsink
dTj
Rth( j-a)
(**) Mounted 1 inch square PCB
Document Number: 93433
www.vishay.com
2
IR1H40CSPTR
Bulletin I0149J rev. H 05/06
100
10
Reverse Current - I
R
(mA)
Tj = 150˚C
125˚C
10
1
100˚C
0.1
0.01
0.001
75˚C
50˚C
25˚C
Instantaneous Forward Current - I
F
(A)
0.0001
0
5
10
15
20
25
30
35
40
Reverse Voltage - V
R
(V)
Fig. 2 - Typical Values Of Reverse Current
Vs. Reverse Voltage (Per Leg)
1
T J = 150˚C
T = 125˚C
J
T = 25˚C
J
160
T = 25˚C
Junction Capacitance - C
T
(p F)
140
120
100
80
60
40
0
5
J
0.1
0.2
0.3
Forward Voltage Drop - V
FM
(V)
0.4
0.5
0.6
0.7
0.8
Fig. 1 - Max. Forward Voltage Drop Characteristics
(Per Leg)
10 15 20 25 30 35 40 45
Reverse Voltage - V
R
(V)
Fig. 3 - Typical Junction Capacitance
Vs. Reverse Voltage (Per Leg)
Document Number: 93433
www.vishay.com
3
IR1H40CSPTR
Bulletin I0149J rev. H 05/06
160
Allowable Case Temperature (°C)
DC
140
Average Power Loss (Watts)
D = 3/4
D = 1/2
D = 1/3
D = 1/4
D = 1/5
0.7
0.6
0.5
0.4
D = 0.20
D = 0.25
D = 0.33
D = 0.50
D = 0.75
RMS Limit
DC
120
Square wave (D = 0.50)
80% Vr applied
0.3
0.2
0.1
0
100
see note (2)
80
0
0.2 0.4 0.6 0.8
1
1.2 1.4 1.6
Average Forward Current - I
F(AV)
(A)
Fig. 4 - Max. Allowable Case Temperature
Vs. Average Forward Current (Per Leg)
0
0.2 0.4 0.6 0.8
1
1.2 1.4 1.6
Average Forward Current - I
F(AV)
(A)
Fig. 5 - Forward Power Loss Characteristics
(Per Leg)
1000
Non-Repetitive Surge Current - I
FSM
(A)
At Any Rated Load Condition
And With Rated Vrrm Applied
Following Surge
100
10
10
100
1000
10000
Square Wave Pulse Duration - t
p
(microsec)
Fig. 6 - Max. Non-Repetitive Surge Current (Per Leg)
L
HIGH-S
PEED
S CH
WIT
FREE-WHEEL
DIODE
40HF
L40S
02
+
DUT
IR
FP460
R = 25 ohm
g
Vd = 25 Volt
CURR
ENT
MONIT
OR
Fig. 8 - Unclamped Inductive Test Circuit
(2)
Formula used: T
C
= T
J
- (Pd + Pd
REV
) x R
thJC
;
Pd = Forward Power Loss = I
F(AV)
x V
FM
@ (I
F(AV)
/
D) (see Fig. 6);
Pd
REV
= Inverse Power Loss = V
R1
x I
R
(1 - D); I
R
@ 80% V
R
applied
Document Number: 93433
www.vishay.com
4
IR1H40CSPTR
Bulletin I0149J rev. H 05/06
FlipKY
TM
Outline Dimension and Tape and Reel
0.10 [.004] C
2X
B
1.524
[.060]
A
BALL ASSIGNMENTS
1 = CATHODE
2 = CATHODE
3 = ANODE
4 = ANODE
0.10 [.004] C
2X
0.675
0.595
0.280
0.240
2X
0.400
[.016]
4
3
1.524
[.060]
1.524
0.300
1
2
0.800
[.032]
4X
NOTES:
1. DIMENSIONING & TOLERANCING PER ASME Y14.5M-1994.
2. CONTROLLING DIMENSION: MILLIMETER
3. DIMENSIONS ARE SHOWN IN MILLIMETERS [INCHES].
0.395
0.355
BALL 1
LOCATION MARK
K
01 123
PART NUMBER
Ø 13"
LOT NUMBER
WORKWEEK (Y, WW)
8mm
RECOMMENDED FOOTPRINT
0.800 [.032]
A1 BALL
LOCATION
8mm
Cathode Ball 1
Cathode Ball 2
0.800 [.032]
Anode Ball 4
Anode Ball 3
4X Ø 0.25 [.010]
NOTES:
4mm
FEED DIRECTION
1. TAPE AND REEL OUTLINE CONFORMS TO EIA-481 & EIA-541.
Document Number: 93433
www.vishay.com
5
