MUX8532-S datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> The signal circuit> MUX8532-S

MUX8532-S: DescriptionSingle-Ended Multiplexer, 2 Func, 16 Channel, CQFP56, 0.800 X 0.800 INCH, 0.200 INCH HEIGHT, HERMETIC SEALED, CERAMIC, QFP-56; CategoryAnalog mixed-signal IC The signal circuit; File Size226KB，8 Pages; ManufacturerCobham Semiconductor Solutions

Download Datasheet Parametric Compare View All

MUX8532-S Overview

Single-Ended Multiplexer, 2 Func, 16 Channel, CQFP56, 0.800 X 0.800 INCH, 0.200 INCH HEIGHT, HERMETIC SEALED, CERAMIC, QFP-56

MUX8532-S Parametric

Parameter Name	Attribute value
Maker	Cobham Semiconductor Solutions
Parts packaging code	QFP
package instruction	QFF,
Contacts	56
Reach Compliance Code	unknown
Analog Integrated Circuits - Other Types	SINGLE-ENDED MULTIPLEXER
JESD-30 code	S-CQFP-F56
length	20.32 mm
Nominal Negative Supply Voltage (Vsup)	-15 V
Number of channels	16
Number of functions	2
Number of terminals	56
Maximum on-state resistance (Ron)	1000 Ω
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package body material	CERAMIC, METAL-SEALED COFIRED
encapsulated code	QFF
Package shape	SQUARE
Package form	FLATPACK
Certification status	Not Qualified
Filter level	MIL-PRF-38534 Class K
Maximum seat height	5.08 mm
Nominal supply voltage (Vsup)	15 V
surface mount	YES
Maximum disconnect time	1000 ns
Maximum connection time	1000 ns
Temperature level	MILITARY
Terminal form	FLAT
Terminal pitch	1.27 mm
Terminal location	QUAD
total dose	150k Rad(Si) V
width	20.32 mm

Preview

Download Datasheet

View All

Standard Products

www.aeroflex.com/mux

April 20, 2009

MUX8532 Dual 16-Channel Analog Multiplexer Module

Radiation Tolerant

FEATURES

32-channels provided by two independent 16-channel multiplexers

Radiation performance

- Total dose:

150 krads(Si), Dose rate = 50 - 300 rads(Si)/s

- SEU:

Immune up to 90 MeV-cm

/mg

- SEL:

Immune by process design

Full military temperature range

Low power consumption < 30mW

Separate address (A

0-3

& B

0-3

) and enable (EN

0-15

& EN

16-31

) for CH

0-15

and CH

16-31

Fast access time < 500ns typical

Break-Before-Make switching

High analog input impedance (power on or off )

Designed for aerospace and high reliability space applications

Packaging – Hermetic ceramic

- 56 leads, 0.80"Sq x 0.20"Ht quad flat pack

- Typical Weight 6 grams

DSCC SMD 5962-09232 pending

Note: Aeroflex Plainview does not currently have a DSCC certified Radiation Hardened Assurance Program.

GENERAL DESCRIPTION

Aeroflex’s MUX8532 is a radiation tolerant, Dual 16 channel multiplexer MCM (Multi Chip Module).

The MUX8532 has been specifically designed to meet exposure to radiation environments. It is available

in a 56 lead High Temperature Co-Fired Ceramic (HTCC) Quad Flatpack (CQFP). It is guaranteed

operational from -55°C to +125°C. Available screened in accordance with MIL-PRF-38534, the

MUX8532 is ideal for demanding military and space applications.

ORGANIZATION AND APPLICATION

A Section

B Section

The MUX8532 consists of two independent 16 channel multiplexers arranged as shown in the block

diagram.

Sixteen (16) channels addressable by bus A

, enabled by EN

0-15

and outputted on Output1(

0-15).

Sixteen (16) channels addressable by bus B

, enabled by EN

16-31

and outputted on Output2(

16-31).

SCD8532 Rev A

MUX8532-S Related Products

	MUX8532-S	MUX8532-201-1S	5962-0923201KXC	MUX8532-7
Description	Single-Ended Multiplexer, 2 Func, 16 Channel, CQFP56, 0.800 X 0.800 INCH, 0.200 INCH HEIGHT, HERMETIC SEALED, CERAMIC, QFP-56	Single-Ended Multiplexer, CQFP56, 0.800 X 0.800 INCH, 0.200 INCH HEIGHT, HERMETIC SEALED, CERAMIC, QFP-56	Single-Ended Multiplexer, 2 Func, 16 Channel, CQFP56, 0.800 X 0.800 INCH, 0.200 INCH HEIGHT, HERMETIC SEALED, CERAMIC, QFP-56	Single-Ended Multiplexer, 2 Func, 16 Channel, CQFP56, 0.800 X 0.800 INCH, 0.200 INCH HEIGHT, HERMETIC SEALED, CERAMIC, QFP-56
Parts packaging code	QFP	QFP	QFP	QFP
package instruction	QFF,	,	QFF,	QFF,
Contacts	56	56	56	56
Reach Compliance Code	unknown	unknown	unknown	unknown
Analog Integrated Circuits - Other Types	SINGLE-ENDED MULTIPLEXER	SINGLE-ENDED MULTIPLEXER	SINGLE-ENDED MULTIPLEXER	SINGLE-ENDED MULTIPLEXER
JESD-30 code	S-CQFP-F56	S-CQFP-F56	S-CQFP-F56	S-CQFP-F56
Number of terminals	56	56	56	56
Package body material	CERAMIC, METAL-SEALED COFIRED	CERAMIC, METAL-SEALED COFIRED	CERAMIC, METAL-SEALED COFIRED	CERAMIC, METAL-SEALED COFIRED
Package shape	SQUARE	SQUARE	SQUARE	SQUARE
Package form	FLATPACK	FLATPACK	FLATPACK	FLATPACK
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified
surface mount	YES	YES	YES	YES
Terminal form	FLAT	FLAT	FLAT	FLAT
Terminal location	QUAD	QUAD	QUAD	QUAD
Maker	Cobham Semiconductor Solutions	-	Cobham Semiconductor Solutions	Cobham Semiconductor Solutions
length	20.32 mm	-	20.32 mm	20.32 mm
Nominal Negative Supply Voltage (Vsup)	-15 V	-	-15 V	-15 V
Number of channels	16	-	16	16
Number of functions	2	-	2	2
Maximum on-state resistance (Ron)	1000 Ω	-	1000 Ω	1000 Ω
Maximum operating temperature	125 °C	-	125 °C	125 °C
Minimum operating temperature	-55 °C	-	-55 °C	-55 °C
encapsulated code	QFF	-	QFF	QFF
Maximum seat height	5.08 mm	-	5.08 mm	5.08 mm
Nominal supply voltage (Vsup)	15 V	-	15 V	15 V
Maximum disconnect time	1000 ns	-	1000 ns	1000 ns
Maximum connection time	1000 ns	-	1000 ns	1000 ns
Temperature level	MILITARY	-	MILITARY	MILITARY
Terminal pitch	1.27 mm	-	1.27 mm	1.27 mm
width	20.32 mm	-	20.32 mm	20.32 mm
