C1500/1500XLBB602AW: DescriptionRocker Switch, SPST, Latched, Quick Connect Terminal, Two Colour Rocker Actuator, Panel Mount, ROHS COMPLIANT; CategoryMechanical and electronic products switch; File Size235KB，2 Pages; ManufacturerArcolectric; Environmental Compliance

Download Datasheet Parametric View All

C1500/1500XLBB602AW Overview

Rocker Switch, SPST, Latched, Quick Connect Terminal, Two Colour Rocker Actuator, Panel Mount, ROHS COMPLIANT

C1500/1500XLBB602AW Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Arcolectric
package instruction	ROHS COMPLIANT
Reach Compliance Code	compliant
ECCN code	EAR99
Actuator type	TWO COLOUR ROCKER
Other features	DUAL SWITCH AVAILABLE
body width	25 mm
body height	25.3 mm
Body length or diameter	32 mm
Contact (AC) maximum rated R load	16A@250VAC
Maximum contact current (AC)	16 A
Maximum contact voltage (AC)	250 V
Manufacturer's serial number	1500
Installation features	PANEL MOUNT
surface mount	NO
Switch action	LATCHED
switch function	SPST
Switch type	ROCKER SWITCH
Termination type	QUICK CONNECT

Preview

Download Datasheet

View All

1500 Twin Units Switches and Indicators

16A 250Vac

Twin unit rocker switch

Choice of switching

circuits including 3

position

Push-on, solder and

PCB terminals

Choice of bezel styles

Choice of 6 panel cut

outs

We match all major

brands

rocker

switches

Matching indicator

Single pole switches

Splashproof option

Panel cut out ‘A’ style:

27.2 x 22.3mm

B

BLACK

R

RED

W

WHITE

NON-LIT

B

BLACK

R

RED

W

WHITE

A

C

G

R

LIT*

AMBER

CLEAR

GREEN

RED

‘X’ ROCKER COLOR R,G

2

125V NEON* *

Indicator only

3

250V NEON*

7

12V INCANDESCENT*

For versions with High Inrush or for 50,000 operations, see page 20.

RoHS compliant

In house test

16(4)A 250Vac T125

UL CSA 16A 250Vac

UL CSA (2 posn) 250Vac 1hp, 125Vac 1/2hp, (3 posn) 250 Vac

1/2hp, 125Vac 1/4hp

UL 85˚C, file E45221, CSA file LR10990

Inrush 36A to EN61058-1

RoHS

3mm contact gap except where marked µ.

Technical data on pages 4 & 5 (switches), 6 (indicators).

C 1500/1500 A L B R 2 602AW

ORDER FORMAT

TERMINAL

C

Approvals & ratings vary with function

ON OFF Switches - ON when pressed over terminal 1 or 4

9.1

1

4

2

5

3

6

TERMINAL

CODE

FUNCTION

CODE

FUNCTION

ROCKER

CODE

BODY BODY

CODE COLOR

ROCKER

COLOR

LAMP VOLTAGE

OR “ON LIGHT”

ROCKER

A

Softline (Matt)

LEGEND &

OPTIONS

6.3 x 0.8

H

9.1

1500

B

Softline splash resistant (Matt)

ON - OFF

4.8 x 0.8

W

Curved splash resistant (Matt)

K

9.1

2.0

1.2

1510

µ

HP rating N/A

ON - ON

2.8 x 0.8

X

Two colour (Matt) (not momentary)

ON - OFF only

T

1520

µ

7.0

Ø2.1

125V & 250V 1/2 HP

H terminal rated T100 only

ON - OFF - ON

Solder

A

Softline lens (Matt) (Indicator)

X

9.1

4.0

430

X terminal N/A

Indicator

Technical data on page 6

PCB 0.8Sq

24

26
