MTB330SGVM-8.000MHZ-G datasheet, PDF

Datasheet> All Categories > Passive components> oscillator> MTB330SGVM-8.000MHZ-G

MTB330SGVM-8.000MHZ-G: DescriptionOscillator,; CategoryPassive components oscillator; File Size141KB，2 Pages; ManufacturerMMD Monitor/Quartztek; Websitehttp://mmdcomp.com

Download Datasheet Parametric View All

MTB330SGVM-8.000MHZ-G Overview

Oscillator,

MTB330SGVM-8.000MHZ-G Parametric

Parameter Name	Attribute value
Maker	MMD Monitor/Quartztek
Reach Compliance Code	compliant
Ageing	1 PPM/YEAR
Maximum control voltage	3.15 V
Minimum control voltage	0.15 V
Frequency Adjustment - Mechanical	YES
Frequency offset/pull rate	10 ppm
frequency stability	3%
Installation features	SURFACE MOUNT
Nominal operating frequency	8 MHz
Maximum operating temperature	70 °C
Minimum operating temperature
Oscillator type	CLIPPED SINE
Output impedance	10000 Ω
Output level	1 V
Maximum supply voltage	3.465 V
Minimum supply voltage	3.135 V
Nominal supply voltage	3.3 V
surface mount	YES

Preview

Download Datasheet

View All

MTA and MTB Series

Industry Standard Package

+3.30VDC or +5.00VDC

RoHS Compliant Available

Up to 77.760MHZ

ELECTRICAL SPECIFICATIONS:

Output

Frequency Range

Load

Supply Current

Output Level

Symmetry

Freq. Stability vs Temp (Note 1)

Freq. Stability vs Aging

Freq. Stability vs Voltage

Freq. Stability vs Load

Storage Temperature

Supply Voltage (Vdd)

Control Voltage with VC option

Pin 1 Connection

No Connection

VC Option

Mechanical Trimmer when

Specified

HCMOS

Clipped Sinewave

Sinewave

1.000 MHZ to 77.760 MHZ

8.000 MHZ to 77.760 MHZ

10k Ohms // 15pF

50 Ohms

35mA max

3mA max

35mA max

Logic “1” = 90% of Vdd min

1.0V p-p min

0 dBm min

Logic “0” = 10% of Vdd max

40%/60% at 50% of

N/A

Waveform

(See Frequency Stability vs Temperature Table)

±1 ppm per year max

±0.3 ppm with a 5% change in Vdd

±0.3 ppm with a 10% change in Load

-40°C to +85°C

+3.3VDC ±5%

+1.65VDC ±1.50VDC Positive Slope

+5.0VDC ±5%

+2.50VDC ±2.00VDC Positive Slope

No Connection

±10 ppm min

±3 ppm min

If no mechanical trimmer is specified, trimmer may still be present depending on frequency

stability option.

Note 1: If no mechanical trimmer, oscillator frequency shall be ±1 ppm at +25°C ±3°C at time of shipment.

PART NUMBER GUIDE:

14 PIN DIP TCXO

Series Options

A = A Series (8.0 mm ht)

B = B Series (5.0 mm ht)

RoHS Compliant

Blank = Not Compliant

F = is Compliant

Supply Voltage

5 = +5.0VDC

3 = +3.3VDC

Frequency

Stability

10 = ±1.0 ppm

15 = ±1.5 ppm

20 = ±2.0 ppm

25 = ±2.5 ppm

30 = ±3.0 ppm

50 = ±5.0 ppm

Operating

Temperature

A = 0°C to +50°C

C = -20°C to +70°C

D = -30°C to +70°C

E = -30°C to +80°C

F = -40°C to +85°C

G = 0°C to +70°C

Value Added Options

Blank = No Added Options

G = Gull-wing

Trimmer Option

Blank = No Trimmer

M = Mechanical Trimmer

Pin 1 Connection

Blank = N/C

V = Voltage Control

FREQUENCY

Output

H = HCMOS

S = Clipped Sinewave

Z = Sinewave

Please Consult with MMD Sales Department for any other Parameters or Options.

MMD Components,

30400 Esperanza, Rancho Santa Margarita, CA, 92688

Phone: (949) 709-5075, Fax: (949) 709-3536,

www.mmdcomp.com

Sales@mmdcomp.com

Specifications subject to change without notice

Revision 09/26/06 F
