28
A
AST065
Spring clamp terminal block, solderable, centerline
5 mm / 0.197 inches, horizontal wire entry, without
eccentric lever
AST025
Spring clamp terminal block, solderable, centerline
5 mm / 0.197 inches, horizontal wire entry
Technical Data
V / A / AWG
300 / 13 / 28 - 14
Technical Data
V / A / AWG
0.08 - 1 mm²
300 / 13 / 28 - 14
250 V / 4 kV / 12 A
0.08 - 1.5 mm² 250 V / 4 kV / 12 A
Insulation co-ordination according to EN 60664-1
Clearance and creepage distances min. 4 mm
Insulating material class
CTI 600
Overvoltage category
III
III
II
Pollution degree
3
2
2
Rated voltage
320
800
800
Rated test voltage
4
6
4
Protection category according
to IEC 529
IP20
Min. insul. strip length
6 mm
Solder pin dimension
1.0 x 0.8 mm
Recommended pc board hole
dia.
Ø 1.4 mm
Solder pin length
5 mm
Pole size
2 - 24
Color
grey
Insulation co-ordination according to EN 60664-1
Clearance and creepage distances min. 4 mm
Insulating material class
CTI 400
Overvoltage category
III
III
II
Pollution degree
3
2
2
Rated voltage
250
500
500
Rated test voltage
2.5
4
2.5
Protection category according
to IEC 529
IP20
Min. insul. strip length
6 mm
Solder pin dimension
1.0 x 0.8 mm
Recommended pc board hole
dia.
Ø 1.4 mm
Solder pin length
5 mm
Pole size
2 - 24
Color
grey
Dimensions in mm
1 mm = 0.0394 in.
Dimensions in mm
1 mm = 0.0394 in.
L = (pole size - 1) x centerline + 1.6 mm / 0.065 inches
L = (pole size - 1) x centerline + 5 mm / 0.197 inches
Part numbers (P/N)
AST065
centerline 5 mm / 0.197 inches
(information: page 16)
Complete the part number by
adding the pole size.
Part numbers (P/N)
AST025
(information: page 16)
Complete the part number by
adding the pole size.
02 03 04 05 06 07 08
09 10 11 12 13 14 15 16
17 18 19 20 21 22 23 24
centerline 5 mm / 0.197 inches
02 03 04 05 06 07 08
09 10 11 12 13 14 15 16
17 18 19 20 21 22 23 24
P/N
AST065
P/N
AST025
Standard pole sizes
Available on demand. Minimum order quantity 5000
pieces per item.
Standard pole sizes
Available on demand. Minimum order quantity 5000
pieces per item.
