Series 803 Mighty Mouse
¼ Turn Bayonet Receptacle
803-004-02 and 803-003-02 Dimensions
F
Series 803
MASTER
KEYWAY
A MAX
.110/.103
(2.79/2.62)
2 PLCS
C REF
B BSC
45°
Shell
Size
5
6
7
8
9
10
12
14
A Max.
In.
.703
.788
.890
1.154
1.207
1.291
1.394
1.545
mm.
17.86
20.02
22.61
29.31
30.66
32.79
35.41
39.24
In.
.513
.598
.708
.964
1.017
1.101
1.204
1.280
B Bsc.
mm.
13.03
15.19
17.98
24.49
25.83
27.97
30.58
32.51
A BSC
øB
© 2014 Glenair, Inc.
Flange mount front or rear panel mount receptacle - shell style 02
.880 (22.35) MAX
.485 (12.32)
.425 (10.80)
.485 (12.32)
.425 (10.80)
.850 (21.59) MAX
ØD
ØF
ØD
E THREAD
Integral Band Platform
803-003-02
Accessory Thread
803-004-02
Dimensions
C Ref.
In.
.460
.522
.590
.668
.721
.795
.874
1.050
mm.
11.68
13.26
14.99
16.97
18.31
20.19
22.20
26.67
In.
.300
.362
.436
.508
.561
.635
.714
.865
ØD
mm.
7.62
9.19
11.07
12.91
14.25
16.13
18.14
21.97
E Thread
.2500-32 UNEF-2A
.3125-32 UNEF-2A
.4375-28 UNEF-2A
.5000-28 UNEF-2A
.5625-24 UNEF-2A
.6250-24 UNEF-2A
.6875-24 UNEF-2A
.9375-20 UNEF-2A
ØF
In.
.230
.286
.390
.440
.500
.562
.650
.805
mm.
5.84
7.26
9.91
11.18
12.70
14.27
16.51
20.45
Flange Mount Panel Cutout Dimensions
2X ø.122 (3.1)
Shell
Size
5
6
7
8
9
10
12
14
In.
.513
.598
.708
.964
1.017
1.101
1.204
1.280
A
mm.
13.03
15.19
17.98
17.98
25.83
27.97
30.58
32.51
In.
.365
.430
.520
.592
.645
.726
.832
.945
ØB
mm.
9.25
10.92
13.21
15.04
16.38
18.44
21.13
24.00
Flange Mount
Dimensions in Inches (millimeters) are subject to change without notice.
Series 80 Mighty Mouse
U.S. CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
