Series 804 Push-Pull Mighty Mouse
PC Tail or Solder Cup Panel Mount Plug
804-009-02, 804-021-02 Dimensions
G
Series 804
A
B
#4-40 THREADED
LOCKNUT (2 PL)
øG
øC
.025 (0.64)
TYP
.125 (3.18)
MIN
Shell
Size
In.
5
6
7
8
9
10
11
12
14
15
1.055
1.120
1.185
1.230
1.290
1.360
1.420
1.485
1.600
1.665
A
mm.
26.80
28.45
30.10
31.24
32.77
34.54
36.07
37.72
40.64
42.29
B
In.
±.005
.755
.820
.885
.930
.990
1.060
1.120
1.185
1.300
1.365
mm.
±0.13
19.18
20.83
22.48
23.62
25.15
26.92
28.45
30.10
33.02
34.67
© 2014 Glenair, Inc.
Flange mount receptacle - style 02
.950 (24.13) MAX
.050 (1.27)
.720 (18.29
KEY
øD øE øF
.560(14.22)
Dimensions
ØC
In.
.244
.330
.432
.493
.551
.620
.662
.703
.863
.912
mm.
6.20
8.38
10.97
12.52
14.00
15.75
16.81
17.86
21.92
23.16
In.
.219
.282
.351
.398
.454
.529
.587
.646
.768
.828
ØD
mm.
5.56
7.16
8.92
10.11
11.53
13.44
14.91
16.41
19.51
21.03
In.
.250
.313
.383
.429
.486
.563
.618
.676
.800
.860
ØE
mm.
6.35
7.95
9.73
10.90
12.34
14.30
15.70
17.17
20.32
21.84
In.
.320
.385
.450
.495
.555
.625
.690
.750
.865
.930
ØF
mm.
8.13
9.78
11.43
12.57
14.10
15.88
17.53
19.05
21.97
23.62
ØG
Tail Dia.
#23
.018/.022 (0.46/0.56)
#20
.024/.028 (0.61/0.71)
#16
.060/.064 (1.52/1.63)
#12
.092/.096 (2.34/2.44)
Dimensions in Inches (millimeters) are subject to change without notice.
