BUK9606-55A
N-channel TrenchMOS logic level FET
Rev. 04 — 31 May 2010
Product data sheet
1. Product profile
1.1 General description
Logic level N-channel enhancement mode Field-Effect Transistor (FET) in a plastic
package using TrenchMOS technology. This product has been designed and qualified to
the appropriate AEC standard for use in automotive critical applications.
1.2 Features and benefits
Low conduction losses due to low
on-state resistance
Q101 compliant
Suitable for logic level gate drive
sources
Suitable for thermally demanding
environments due to 175 °C rating
1.3 Applications
12 V and 24 V loads
Automotive and general purpose
power switching
Motors, lamps and solenoids
NXP Semiconductors
BUK9606-55A
N-channel TrenchMOS logic level FET
1.4 Quick reference data
Table 1.
Symbol
V
DS
I
D
P
tot
Quick reference data
Parameter
drain-source
voltage
drain current
total power
dissipation
drain-source
on-state
resistance
Conditions
T
j
≥
25 °C; T
j
≤
175 °C
V
GS
= 5 V; T
j
= 25 °C;
see
Figure 3;
see
Figure 1
T
mb
= 25 °C; see
Figure 2
[1]
Min
-
-
-
Typ
-
-
-
Max Unit
55
75
300
V
A
W
Static characteristics
R
DSon
V
GS
= 10 V; I
D
= 25 A;
T
j
= 25 °C
V
GS
= 4.5 V; I
D
= 25 A;
T
j
= 25 °C
V
GS
= 5 V; I
D
= 25 A;
T
j
= 25 °C;
see
Figure 12;
see
Figure 13
Avalanche ruggedness
E
DS(AL)S
non-repetitive
I
D
= 75 A; V
sup
≤
55 V;
drain-source
R
GS
= 50
Ω;
V
GS
= 5 V;
avalanche energy T
j(init)
= 25 °C; unclamped
-
-
1.1
J
-
-
-
4.8
-
5.3
5.8
6.7
6.3
mΩ
mΩ
mΩ
[1]
Continuous current is limited by package.
2. Pinning information
Table 2.
Pin
1
2
3
mb
Pinning information
Symbol Description
G
D
S
D
gate
drain
source
mounting base; connected to
drain
2
1
3
mb
D
Simplified outline
Graphic symbol
G
mbb076
S
SOT404 (D2PAK)
3. Ordering information
Table 3.
Ordering information
Package
Name
BUK9606-55A
D2PAK
Description
Version
plastic single-ended surface-mounted package (D2PAK); 3 leads SOT404
(one lead cropped)
Type number
BUK9606-55A
All information provided in this document is subject to legal disclaimers.
© NXP B.V. 2010. All rights reserved.
Product data sheet
Rev. 04 — 31 May 2010
2 of 14
NXP Semiconductors
BUK9606-55A
N-channel TrenchMOS logic level FET
4. Limiting values
Table 4.
Symbol
V
DS
V
DGR
V
GS
I
D
Limiting values
Parameter
drain-source voltage
drain-gate voltage
gate-source voltage
drain current
V
GS
= 5 V; T
j
= 25 °C;
see
Figure 3;
see
Figure 1
V
GS
= 5 V; T
j
= 100 °C; see
Figure 1
I
DM
P
tot
T
stg
T
j
I
S
I
SM
E
DS(AL)S
peak drain current
total power dissipation
storage temperature
junction temperature
source current
peak source current
non-repetitive
drain-source
avalanche energy
T
mb
= 25 °C
t
p
≤
10 µs; pulsed; T
mb
= 25 °C
I
D
= 75 A; V
sup
≤
55 V; R
GS
= 50
Ω;
V
GS
= 5 V; T
j(init)
= 25 °C; unclamped
[1]
[2]
[1]
[2]
[2]
In accordance with the Absolute Maximum Rating System (IEC 60134).
Conditions
T
j
≥
25 °C; T
j
≤
175 °C
R
GS
= 20 kΩ
Min
-
-
-15
-
-
-
-
-
-55
-55
-
-
-
-
Typ
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Max
55
55
15
154
75
75
616
300
175
175
154
75
616
1.1
Unit
V
V
V
A
A
A
A
W
°C
°C
A
A
A
J
T
mb
= 25 °C; t
p
≤
10 µs; pulsed;
see
Figure 3
T
mb
= 25 °C; see
Figure 2
Source-drain diode
Avalanche ruggedness
[1]
[2]
Current is limited by power dissipation chip rating.
Continuous current is limited by package.
BUK9606-55A
All information provided in this document is subject to legal disclaimers.
© NXP B.V. 2010. All rights reserved.
Product data sheet
Rev. 04 — 31 May 2010
3 of 14
NXP Semiconductors
BUK9606-55A
N-channel TrenchMOS logic level FET
200
I
D
(A)
150
03ne93
120
P
der
(%)
80
03na19
100
40
50
Capped at 75 A due to package
0
25
50
75
100
125
150
175
200
T
mb
(°C)
0
0
50
100
150
T
mb
(°C)
200
Fig 1.
Normalized continuous drain current as a
function of mounting base temperature
10
3
I
D
(A)
10
2
capped at 75 A due to package
R
DSon
= V
DS
/I
D
Fig 2.
Normalized total power dissipation as a
function of mounting base temperature
03nf02
t
p
= 10
μs
100
μs
1 ms
t
p
T
D.C.
10 ms
100 ms
10
P
δ
=
t
p
t
T
1
1
10
V
DS
(V)
10
2
Fig 3.
Safe operating area; continuous and peak drain currents as a function of drain-source voltage
BUK9606-55A
All information provided in this document is subject to legal disclaimers.
© NXP B.V. 2010. All rights reserved.
Product data sheet
Rev. 04 — 31 May 2010
4 of 14
NXP Semiconductors
BUK9606-55A
N-channel TrenchMOS logic level FET
5. Thermal characteristics
Table 5.
Symbol
R
th(j-mb)
Thermal characteristics
Parameter
thermal resistance
from junction to
mounting base
thermal resistance
from junction to
ambient
Conditions
see
Figure 4
Min
-
Typ
-
Max
0.5
Unit
K/W
R
th(j-a)
mounted on a printed-circuit board ;
minimum footprint
-
50
-
K/W
1
Z
th(j-mb)
(K/W)
10
−1
03nf03
δ
= 0.5
0.2
0.1
0.05
10
−2
0.02
P
δ
=
t
p
T
single shot
t
p
t
T
10
−3
10
−6
10
−5
10
−4
10
−3
10
−2
10
−1
t
p
(s)
1
Fig 4.
Transient thermal impedance from junction to mounting base as a function of pulse duration
BUK9606-55A
All information provided in this document is subject to legal disclaimers.
© NXP B.V. 2010. All rights reserved.
Product data sheet
Rev. 04 — 31 May 2010
5 of 14
