MAX1832EUT datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> MAX1832EUT

MAX1832EUT: Description1 A SWITCHING REGULATOR, PDSO6, MO-178AB, SOT-23, 6 PIN; CategoryPower/power management The power supply circuit; File Size1MB，15 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric Compare View All

MAX1832EUT Overview

1 A SWITCHING REGULATOR, PDSO6, MO-178AB, SOT-23, 6 PIN

MAX1832EUT Parametric

Parameter Name	Attribute value
Maker	Rochester Electronics
Parts packaging code	SOIC
package instruction	LSSOP,
Contacts	6
Reach Compliance Code	unknown
Analog Integrated Circuits - Other Types	SWITCHING REGULATOR
Maximum input voltage	5.5 V
Minimum input voltage	1.5 V
Nominal input voltage	2 V
JESD-30 code	R-PDSO-G6
length	2.9 mm
Number of functions	1
Number of terminals	6
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Maximum output current	1 A
Package body material	PLASTIC/EPOXY
encapsulated code	LSSOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, LOW PROFILE, SHRINK PITCH
Maximum seat height	1.45 mm
surface mount	YES
Switch configuration	BOOST
technology	BICMOS
Temperature level	INDUSTRIAL
Terminal form	GULL WING
Terminal pitch	0.95 mm
Terminal location	DUAL
width	1.625 mm

Preview

Download Datasheet

View All
