BUK9Y58-75B

N-channel TrenchMOS logic level FET

Rev. 04 — 7 April 2010

Product data sheet

1. Product profile

1.1 General description

Logic level N-channel enhancement mode Field-Effect Transistor (FET) in a plastic

package using TrenchMOS technology. This product has been designed and qualified to

the appropriate AEC standard for use in automotive critical applications.

1.2 Features and benefits

Low conduction losses due to low

on-state resistance

Q101 compliant

Suitable for logic level gate drive

sources

Suitable for thermally demanding

environments due to 175 °C rating

1.3 Applications

12 V, 24 V and 42 V loads

Automotive systems

DC-to-DC converters

General purpose power switching

solenoid drives

1.4 Quick reference data

Table 1.

Symbol

tot

Quick reference data

Parameter

drain-source

voltage

drain current

total power

dissipation

drain-source

on-state

resistance

Conditions

≥

25 °C; T

≤

175 °C

= 5 V; T

= 25 °C;

see

Figure 1;

see

Figure 4

= 25 °C; see

Figure 2

Min

Typ

Max Unit

20.7 A

60.4 W

Static characteristics

DSon

= 5 V; I

= 10 A;

= 25 °C; see

Figure 13

= 10 V; I

= 10 A;

= 25 °C

mΩ
