INDUCTORS
TECHNOLOGY OF TOMORROW
ØW
1
2
H
FERRITE CORE
POWER INDUCTOR
LPC 10065
A
STRUCTURE
3
4
5
1
2
3
4
5
Ferrite core
Winding wire
Epoxy adhesive
Ceramic substrate
Electrode
d
B
IDENTIFICATION
PRODUCT CODE
LPC 10065
COATING COLOR
None
MARKING
None
TYPE DESIGNATION (HOW TO ORDER)
Old Part No.
New Part No.
LPC 10065
LPC 10065
PRODUCT
CODE
L
TERMINATION
SURFACE MATERIAL
L: Sn/Pb
A: SnAg
K
TE
TE
221
221
NOMINAL
INDUCTANCE
3 digits
(Unit: µH)
K
INDUCTANCE
TOLERANCE
INDUCTANCE
TOLERANCE
TAPING*
*Please see “PACKAGING”
FEATURES
■
■
■
■
■
■
Large permissible DC current and small DC resistance
Small surface area allows high mounting density
Small size and low height
Suitable for reflow soldering
Operating temperature range: - 40° C ... + 85° C
Inductors for extended ambient temperature range: -40° C ... + 125° C on request
(Type LPC 10065 E K TE xxx) (10 µH ... 3300 µH)
■
Embossed carrier tape packaging available
DIMENSIONS (mm)
PRODUCT
CODE
LPC 10065
∅
W
10.0 ± 0.2
H
7.5 max.
A
8.0 ± 0.2
B
10.4 ± 0.2
d
2.5 ± 0.2
RATING
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
INDUCTANCE
TYPE
NOM. VALUE*
LPC 10065 TE R68
LPC 10065 TE 1R0
LPC 10065 TE 1R5
LPC 10065 TE 2R2
LPC 10065 TE 3R3
LPC 10065 TE 4R7
LPC 10065 TE 6R8
LPC 10065 TE 100
LPC 10065 TE 150
LPC 10065 TE 220
LPC 10065 TE 330
LPC 10065 TE 470
LPC 10065 TE 680
LPC 10065 TE 101
LPC 10065 TE 151
LPC 10065 TE 221
LPC 10065 TE 331
LPC 10065 TE 471
LPC 10065 TE 681
LPC 10065 TE 102
LPC 10065 TE 152
LPC 10065 TE 222
LPC 10065 TE 332
0.68 µH
1.0 µH
1.5 µH
2.2 µH
3.3 µH
4.7 µH
6.8 µH
10 µH
15 µH
22 µH
33 µH
47 µH
68 µH
100 µH
150 µH
220 µH
330 µH
470 µH
680 µH
1000 µH
1500 µH
2200 µH
3300 µH
TOLERANCE
FREQUENCY
QUALITY FACTOR
Q (MIN.)
FREQUENCY
SELF-RESONANT
FREQUENCY
(MIN.)
75.0 MHz
65.0 MHz
50.0 MHz
40.0 MHz
30.0 MHz
25.0 MHz
20.0 MHz
15.0 MHz
12.0 MHz
9.00 MHz
8.00 MHz
6.00 MHz
5.00 MHz
4.00 MHz
3.00 MHz
2.50 MHz
2.00 MHz
1.50 MHz
1.00 MHz
0.95 MHz
0.85 MHz
0.70 MHz
0.55 MHz
DC
RESISTANCE
(MAX.)
0.006
Ω
0.007
Ω
0.008
Ω
0.009
Ω
0.012
Ω
0.017
Ω
0.024
Ω
0.036
Ω
0.054
Ω
0.080
Ω
0.120
Ω
0.175
Ω
0.255
Ω
0.38
Ω
0.58
Ω
0.85
Ω
1.30
Ω
1.85
Ω
2.70
Ω
4.00
Ω
6.10
Ω
9.00
Ω
13.50
Ω
ALLOWABLE
DC CURRENT
(MAX.)
9.50 A
9.00 A
8.50 A
7.50 A
6.80 A
5.70 A
4.70 A
3.90 A
3.15 A
2.60 A
2.30 A
1.79 A
1.48 A
1.22 A
1.00 A
0.82 A
0.67 A
0.57 A
0.47 A
0.38 A
0.31 A
0.26 A
0.21 A
15
M (± 20%)
1 MHz
30
2.52 MHz
20
15
K (± 10%)
0.1 MHz
20
0.1 MHz
0.05 MHz
30
* Other inductance values on request
EUROPE GmbH • Kaddenbusch 6 • D-25578 Dägeling / ITZEHOE • PHONE: +49 (0) 48 21 / 89 89-0 • FAX: +49 (0) 48 21/ 89 89 89 • Internet: www.koaeurope.de
