CHP3010a98F
L-Band 6-Bit Digital Phase Shifter
GaAs Monolithic Microwave IC
Description
CHP3010a98F is an L-Band (1.2, 1.4GHz)
monolithic 6-bit digital phase-shifter with a
0-360° range and a high phase accuracy.
The typical RMS phase error is 1.5°. The
circuit provides 7dB insertion loss associated
with input and output return losses better
than 15dB under all logic states. An on-chip
DC-interface is compatible with both CMOS
(0/+3.3V) and TTL (0/+5V) logics.
The circuit is mainly dedicated to radar
systems and is also well suited for a wide
range of microwave applications and
systems.
The MMIC is developed on a robust 0.25µm
gate length pHEMT process and is also
available packaged in a standard surface
mount 32-lead QFN5x5.
Main Features
■ 1.5 deg RMS Phase error
■ Low I/O return losses (all states)
■ 24dBm Input P-1dB
■ 16dBm Output P-1dB
■ CMOS /TTL compatibility: V+ = +3.3/5 Volt
■ DC-decoupled I/O
■ Chip size 3.37x2.73x0.1mm
RMS Phase Error versus Frequency
Main Electrical Characteristics
Tamb.= +25°C
Symbol
Parameter
Fop
Operating frequency range
PPE
Peak Phase Error
RMS_PE RMS Phase Error
P1dB
Input power @ 1dBcomp (CW)
Min
1.2
Typ
(-1,+3)
1.5
24
Max
1.4
Unit
GHz
deg
deg
dBm
Ref. : DSCHP3010a98F4184 - 03 Jul 14
1/12
Specifications subject to change without notice
United Monolithic Semiconductors S.A.S.
Bât. Charmille - Parc SILIC - 10, Avenue du Québec - 91140 VILLEBON-SUR-YVETTE - France
Tel.: +33 (0) 1 69 86 32 00 - Fax: +33 (0) 1 69 86 34 34
CHP3010a98F
Electrical Characteristics
L-Band 6-Bit Digital
Phase Shifter
Tamb.= +25°C
Symbol
Parameter
Min
Typ.
Max Unit
Fop
Operating frequency range
1.2
1.4
GHz
PhS
Phase Shifting Range
0
360 deg
PhS step
Phase Shifting Step
5.625
deg
PPE
Peak Phase Error
(- 1, +3)
deg
RMS_PE
RMS Phase Error
1.5
deg
IL
Insertion Loss
7
dB
Av
Amplitude Variation
±0.5
dB
RMS_Av
RMS Amplitude Variation
0.15
dB
VSWR_In Input Return Loss
15
dB
VSWR_Out Output Return Loss
15
dB
P1dB
Input power @ 1dBcomp (CW)
24
dBm
OP1dB
Output power @ 1dBcomp (CW)
16
dBm
Tswitch
Switching Time
30
ns
Vlow
Control Input – low level
0
0.4
V
Vhigh
Control Input – high level
2.4
5
V
V+
Positive Supply Voltage
5 , 3.3
V
V-
Negative Supply Voltage
-5
V
I+
Positive Supply Current
4
mA
I-
Negative Supply Current
3.5
mA
Top
Operating temperature
-40
+85 deg
These values are representative of the chip’s typical performances with bonding wires of
0.15nH at the RF ports.
Ref. : DSCHP3010a98F4184 - 03 Jul 14
2/12
Specifications subject to change without notice
Bât. Charmille - Parc SILIC - 10, Avenue du Québec - 91140 VILLEBON-SUR-YVETTE - France
Tel.: +33 (0) 1 69 86 32 00 - Fax: +33 (0) 1 69 86 34 34
L-Band 6-Bit Digital
Phase Shifter
Absolute Maximum Ratings
(1)
Tamb.= +25°C
Symbol
Parameter
V+
Maximum DC positive supply voltage
V-
Maximum DC negative supply voltage
Vlow
Minimum phase shifter control voltage
Vhigh
Maximum phase shifter control voltage
Tj
Maximum junction temperature
Ta
Operating temperature range
Tstg
Storage temperature range
(1)
CHP3010a98F
Values
+6
-6
-2
+6
175
-40 to +85
-55 to +150
Unit
V
V
V
V
°C
°C
°C
Operation of this device above anyone of these parameters may cause permanent
damage.
Peak Phase Error (PPE) definition
PPE(i)
=
measured_Phase(S21)@state(i)
theoreticalPhaseValue@State(i)
-
measured_Phase(S21)@state(0)
-
Amplitude Variation (Av) definition
Av(i) = Measured_dB(S21)@state(i) - Measured_dB(S21)@state(0)
RMS Phase Error (RMS_PE) definition
PPE
RMS_PE =
i
½
0
63
2
(
i
)
64
where i is the state number (from 0 to 63)
RMS Amplitude variation (RMS_Av) definition
RMS
_
AV
½
Av
½
Av
(
i
)
i
½
0
63
64
where i is the state number (from 0 to 63)
Ref. : DSCHP3010a98F4184 - 03 Jul 14
3/12
Specifications subject to change without notice
Bât. Charmille - Parc SILIC - 10, Avenue du Québec - 91140 VILLEBON-SUR-YVETTE - France
Tel.: +33 (0) 1 69 86 32 00 - Fax: +33 (0) 1 69 86 34 34
CHP3010a98F
Typical Bias Conditions
L-Band 6-Bit Digital
Phase Shifter
Two options are possible for the positive value of the biasing circuit without any impact on RF
performances.
Option 1
Symbol
V+
V-
V+
Bit1 to Bit6
Option 2
Symbol
V+
V-
V+
Bit1 to Bit6
PAD N
o
4
5
6
7 to 12
Parameter
Positive Supply Voltage
Negative Supply Voltage
Positive Supply Voltage
Control Input Voltage
Values
+5
-5
NC
0 / +3.3
Unit
V
V
V
PAD N
o
4
5
6
7 to 12
Parameter
Positive Supply Voltage
Negative Supply Voltage
Positive Supply Voltage
Control Input Voltage
Values
+3.3
-5
+3.3
0 / +3.3
Unit
V
V
V
V
Ref. : DSCHP3010a98F4184 - 03 Jul 14
4/12
Specifications subject to change without notice
Bât. Charmille - Parc SILIC - 10, Avenue du Québec - 91140 VILLEBON-SUR-YVETTE - France
Tel.: +33 (0) 1 69 86 32 00 - Fax: +33 (0) 1 69 86 34 34
L-Band 6-Bit Digital
Phase Shifter
Phase shifter control table
Voltage to apply on Bit 1 to Bit 6 (pads 7 to 12):
State
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
0
5.625
11.25
16.875
22.5
28.125
33.75
39.375
45
50.625
56.25
61.875
67.5
73.125
78.75
84.375
90
95.625
101.25
106.875
112.5
118.125
123.75
129.375
135
140.625
146.25
151.875
157.5
163.125
168.75
174.375
Phase
(deg)
Bit
6
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
Bit
5
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
Bit
4
0
0
0
0
0
0
0
0
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
0
0
0
0
0
0
0
0
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
Bit
3
0
0
0
0
3.3
3.3
3.3
3.3
0
0
0
0
3.3
3.3
3.3
3.3
0
0
0
0
3.3
3.3
3.3
3.3
0
0
0
0
3.3
3.3
3.3
3.3
Bit
2
0
0
3.3
3.3
0
0
3.3
3.3
0
0
3.3
3.3
0
0
3.3
3.3
0
0
3.3
3.3
0
0
3.3
3.3
0
0
3.3
3.3
0
0
3.3
3.3
Bit
1
0
3.3
0
3.3
0
3.3
0
3.3
0
3.3
0
3.3
0
3.3
0
3.3
0
3.3
0
3.3
0
3.3
0
3.3
0
3.3
0
3.3
0
3.3
0
3.3
State
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
Phase
(deg)
180
185.625
191.25
196.875
202.5
208.125
213.75
219.375
225
230.625
236.25
241.875
247.5
253.125
258.75
264.375
270
275.625
281.25
286.875
292.5
298.125
303.75
309.375
315
320.625
326.25
331.875
337.5
343.125
348.75
354.375
CHP3010a98F
Bit
6
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
Bit
5
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
Bit
4
0
0
0
0
0
0
0
0
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
0
0
0
0
0
0
0
0
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
Bit
3
0
0
0
0
3.3
3.3
3.3
3.3
0
0
0
0
3.3
3.3
3.3
3.3
0
0
0
0
3.3
3.3
3.3
3.3
0
0
0
0
3.3
3.3
3.3
3.3
Bit
2
0
0
3.3
3.3
0
0
3.3
3.3
0
0
3.3
3.3
0
0
3.3
3.3
0
0
3.3
3.3
0
0
3.3
3.3
0
0
3.3
3.3
0
0
3.3
3.3
Bit
1
0
3.3
0
3.3
0
3.3
0
3.3
0
3.3
0
3.3
0
3.3
0
3.3
0
3.3
0
3.3
0
3.3
0
3.3
0
3.3
0
3.3
0
3.3
0
3.3
Ref. : DSCHP3010a98F4184 - 03 Jul 14
5/12
Specifications subject to change without notice
Bât. Charmille - Parc SILIC - 10, Avenue du Québec - 91140 VILLEBON-SUR-YVETTE - France
Tel.: +33 (0) 1 69 86 32 00 - Fax: +33 (0) 1 69 86 34 34
