SHEET 1 OF 1
SWITCH FUNCTION
POS. 1
POS. 2
POS. 3
SWITCH HOUSING
10.67
[.420 in]
[.051 in]
n
1.30
SWITCH HOUSING
1
3
5
6
4
2
ON
1-3, 4-2
(ON)
1-5, 6-2
ON
1-5, 6-2
6.35
[.250 in]
3.18
[.125 in]
10.67
[.420 in]
SCHEMATIC
(ON)=MOMENTARY
.531
- .008
in
NOTES:
.000
CONSTRUCTION DETAIL
PANEL CUTOUT
1. ALL DIMENSIONS IN MM
TERMS: 3, 4, 5, 6
2. GENERAL TOLERANCE: X.X=±0.4
X.XX=±0.25
3. TERM. NOS. FOR REFERENCE ONLY
39.80
4. ELECTRICAL LIFE: 6,000 CYCLES
+
[1.567 in]
36.50
- .50
.00
5. OPERATING TEMP: 0°C TO 85°C
+.020
6. CONTACT RESISTANCE: 10m
Ω
MAX. INITIAL
1.437
- .000
in
17.00
7. 2002/95/EC (ROHS) COMPLIANT
[.669 in]
8. CONTACT RATING:
UL APPROVED: 10R(4)A 277VAC 5E4
8.50
Ø[.335 in]
9. MATERIALS:
-BODY AND ACTUATOR: POLYAMIDE 6/6 (PA66)
POSITION 3 (PULL)
-SPRING: STEEL (65Mn)
POSITION 1 (NORMAL)
-SPRING POLE: POLYAMIDE 6/6 (PA66)
POSITION 2 (PUSH)
-HOOK SPRING: STAINLESS STEEL (1Cr13)
- ACTUATION LEVER: BRASS (H62)
-MOBILE CONTACT BAR: SILVER PLATED COPPER
-MOBILE CONTACT: SILVER/NICKEL (AgNi (10))
-STATIONARY CONTACT: SILVER/NICKEL CLAD COPPER
12.4
2.00
6.35
(AgNi (10)/Cu)
[.488 in]
[.079 in]
[.250 in]
-TERMINALS: SILVER PLATED BRASS (H62)
MAX.
10.67
10.67
10. PLASTIC COLOR: WHITE (BODY AND ACTUATOR)
15.5
TRAVEL
[.420 in]
[.420 in]
[.610 in]
11. DENOTES CRITICAL PARAMETER
OPERATING
POSITION 18.1
3 5
6 4
[.713 in]
1
2
5.09
5.09
FREE
13.00
[.200 in]
[.200 in]
POSITION
[.512 in]
23.8
11.0°
`
3°
11.0°
`
3°
[.935 in]
OPERATING
.50
5.33
[.020 in]
POSITION
[.210 in]
5.33
[.210 in]
12.33
[.485 in]
4.75
[.187 in]
6.10
[.240 in]
6.35
[.250 in]
CONSTRUCTION DETAIL
TERMS: 1 & 2
[
13.50
- .20
.00
+
+
]
[
]
C
B
A
REV
20661
20655
20574
PCR NO
Add Notes 8,9,10.
chg title from PP2-7UX-2B2
New Release
DESCRIPTION
6/26/12
6/21/12
4/26/12
DATE
rc
rc
rc
BY
E-Switch INC.
TITLE
SCALE
PP2-7U1-2B2
3/4:1
DATE
DR
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
4/26/2012
rc
DWG
REV
34-PP27U12B2
C
