Type MPF, AC Motor Run Capacitors
Oval and Round, Oil Filled, 70 ºC, Metallized Polypropylene Capacitors
Type MPF AC metallized polypropylene film dielectric capacitors
offer a reliable option for alternating current applications. All
devices are oil filled in metal cases with 4-prong quick disconnect
terminals for easy assembly. These capacitors pack high
capacitance and voltage capabilities into a small, light-weight
package. The MPF is internally protected for fail-safe operation.
These capacitors have extremely low DF that is ideal for AC motor-
run applications.
Highlights
Specifications
Capacitance Range
Capacitance Tolerance
Rated Voltage
Operating Temperature Range with Ripple
Rated Frequency
Dissipation Factor
- Low DF
- Potected with a pressure sensitive interrupter
- Small size and light weight
- UL E71645
- CSA 219950
- Air conditioning and refrigeration applications
- Power factor correction
- Motors
1 µF to 80 µF
± 10%
330 Vac, 370 Vac and 440 Vac
–40 ºC to +70 ºC
50 Hz and 60 Hz
0.1% max @ 60 Hz
RoHS Compliant
Dimensions
Click here to view hardware
Construction Details
Case Material
Encapsulation
Terminal Material
Aluminum or Tin Plated Steel
Enviromentally Safe Dielectric Fluid
Tin Plated Steel
Round Case Style
Oval Case Style
A
±.030”
Style 21, 23, 24
D
B
±.030”
Style 32, 37,38
D
B
±.030”
H ±.250”
.5”
H ±.250”
.5”
A ±.030”
See Ratings Table for “H” dimension
Round
Style
21
23
24
A
1¾"
2.0"
2½"
B
1⅞"
2⅛"
2⅝"
D
13/16"
13/16"
13/16"
Industry Type
1¾" Round
2.0" Round
2½" Round
See Ratings Table for “H” dimension
Oval
Style
32
37
38
A
1 5/16"
1 29/32"
1 31/32"
B
2 5/32"
2 29/32"
3 21/32"
D
13/16"
13/16"
13/16"
Industry Type
1¼" Flat Oval
1¾" Flat Oval
2.0" Flat Oval
CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8561 • Fax: (508)996-3830
Type MPF, AC Motor Run Capacitors
Oval Ratings
Oval and Round, Oil Filled, 70 ºC, Metallized Polypropylene Capacitors
Cap.
(µF)
1.0
2.0
3.0
4.0
5.0
6.0
7.5
10.0
12.5
12.5
15.0
17.5
20.0
22.5
25.0
27.5
30.0
30.0
35.0
35.0
40.0
40.0
45.0
45.0
50.0
70.0
Case Aluminum Catalog
H
Code
Part Number
(inches)
370V
32
32
32
32
32
32
32
32
32
37
37
37
37
37
37
38
37
38
37
38
37
38
37
38
38
38
32FD3701A-F
32FD3702A-F
32FD3703A-F
32FD3704A-F
32FD3705A-F
32FD3706A-F
32FD37075A-F
32FD3710A-F
32FD37125A-F
37FD37125A-F
37FD3715A-F
37FD37175A-F
37FD3720A-F
37FD37225A-F
37FD3725A-F
38FD37275A-F
37FD3730A-F
38FD3730A-F
37FD3735A-F
38FD3735A-F
37FD3740A-F
38FD3740A-F
37FD3745A-F
38FD3745A-F
38FD3750A-F
38FD3770A-F
2.19
2.19
2.19
2.19
2.19
2.19
2.19
2.88
2.88
2.38
2.38
2.38
2.38
2.38
2.91
2.91
2.91
2.91
3.91
2.91
3.91
2.91
3.91
2.91
2.91
3.91
Steel Catalog
H
Part Number* (inches)
32FD3701-F
32FD3702-F
32FD3703-F
32FD3704-F
32FD3705-F
32FD3706-F
32FD37075-F
32FD3710-F
32FD37125-F
37FD37125-F
37FD3715-F
37FD37175-F
37FD3720-F
37FD37225-F
37FD3725-F
38FD37275-F
37FD3730-F
38FD3730-F
37FD3735-F
38FD3735-F
37FD3740-F
38FD3740-F
37FD3745-F
38FD3745-F
38FD3750-F
38FD3770-F
2.13
2.13
2.13
2.13
2.38
2.38
2.38
2.63
3.00
2.63
2.63
2.63
2.63
2.63
2.63
3.00
3.00
3.00
3.75
3.00
3.75
3.00
3.75
3.00
3.00
3.75
Cap.
(µF)
1.0
2.0
3.0
4.0
5.0
6.0
7.5
7.5
10.0
10.0
12.5
15.0
17.5
20.0
20.0
25.0
25.0
30.0
35.0
35.0
40.0
40.0
45.0
50.0
55.0
60.0
Case
Code
32
32
32
32
32
32
32
37
32
37
37
37
37
37
38
37
38
38
37
38
37
38
38
38
38
38
Aluminum Catalog
H
Steel Catalog
H
Part Number
(inches) Part Number* (inches)
440V
32FB4401A-F
32FB4402A-F
32FB4403A-F
32FB4404A-F
32FB4405A-F
32FB4406A-F
32FB44075A-F
37FB44075A-F
32FB4410A-F
37FB4410A-F
37FB44125A-F
37FB4415A-F
37FB44175A-F
37FB4420A-F
38FB4420A-F
37FB4425A-F
38FB4425A-F
38FB4430A-F
37FB4435A-F
38FB4435A-F
37FB4440A-F
38FB4440A-F
38FB4445A-F
38FB4450A-F
38FB4455A-F
38FB4460A-F
2.19
2.19
2.19
2.19
2.19
2.19
2.88
2.38
2.88
2.38
2.38
2.38
2.91
2.91
2.91
3.91
3.91
3.91
4.75
3.91
4.75
3.91
3.91
3.91
4.75
4.75
32FB4401-F
32FB4402-F
32FB4403-F
32FB4404-F
32FB4405-F
32FB4406-F
32FB44075-F
37FB44075-F
32FB4410-F
37FB4410-F
37FB44125-F
37FB4415-F
37FB44175-F
37FB4420-F
38FB4420-F
37FB4425-F
38FB4425-F
38FB4430-F
37FB4435-F
38FB4435-F
37FB4440-F
38FB4440-F
38FB4445-F
38FB4450-F
38FB4455-F
38FB4460-F
2.13
2.13
2.38
2.38
2.63
2.63
2.63
2.63
3.75
2.63
2.63
2.63
2.63
3.00
3.00
3.75
3.75
3.75
4.75
3.75
4.75
3.75
3.75
3.75
4.75
4.75
*Steel cases are not for new design. Check parametric search for product availability.
CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8561 • Fax: (508)996-3830
Type MPF, AC Motor Run Capacitors
Round Ratings
Oval and Round, Oil Filled, 70 ºC, Metallized Polypropylene Capacitors
Cap.
(µF)
Case Aluminum Catalog
H
Steel Catalog
H
Code
Part Number
(inches) Part Number* (inches)
330 V
Cap.
(µF)
Case
Code
Aluminum Catalog
Part Number
370V
H
(inches)
Steel Catalog
H
Part Number* (inches)
4.0
5.0
6.0
7.0
8.0
10.0
3.0
4.0
5.0
6.0
7.0
8.0
10.0
12.5
15.0
17.5
20.0
25.0
25.0
30.0
30.0
35.0
35.0
40.0
40.0
45.0
45.0
23
23
23
23
23
23
21
21
21
21
21
21
21
21
21
21
21
21
23
21
23
21
23
21
23
23
24
23FD3304A-F
23FD3305A-F
23FD3306A-F
23FD3307A-F
23FD3308A-F
23FD3310A-F
21FD3703A-F
21FD3704A-F
21FD3705A-F
21FD3706A-F
21FD3707A-F
21FD3708A-F
21FD3710A-F
21FD37125A-F
21FD3715A-F
21FD37175A-F
21FD3720A-F
21FD3725A-F
23FD3725A-F
21FD3730A-F
23FD3730A-F
21FD3735A-F
23FD3735A-F
21FD3740A-F
23FD3740A-F
23FD3745A-F
24FD3745A-F
2.38
2.38
2.38
2.38
2.38
2.38
370V
2.38
2.38
2.38
2.38
2.38
2.38
2.38
2.38
2.38
2.38
2.38
2.84
2.91
2.84
2.91
3.84
2.91
3.84
2.91
3.84
2.91
23FD3304-F
23FD3305-F
23FD3306-F
23FD3307-F
23FD3308-F
23FD3310-F
21FD3703-F
21FD3704-F
21FD3705-F
21FD3706-F
21FD3707-F
21FD3708-F
21FD3710-F
21FD37125-F
21FD3715-F
21FD37175-F
21FD3720-F
21FD3725-F
23FD3725-F
21FD3730-F
23FD3730-F
21FD3735-F
23FD3735-F
21FD3740-F
23FD3740-F
23FD3745-F
24FD3745-F
2.63
2.63
2.63
2.63
2.63
2.63
2.63
2.63
2.63
2.63
2.63
2.63
2.63
2.63
2.63
2.63
2.63
3.00
3.00
3.00
3.00
3.75
3.00
3.75
3.00
3.75
3.00
50.0
50.0
55.0
55.0
60.0
60.0
65.0
70.0
80.0
15.0
20.0
20.0
22.5
22.5
25.0
25.0
30.0
30.0
35.0
35.0
40.0
40.0
45.0
50.0
55.0
60.0
70.0
23
24
23
24
23
24
24
24
24
21
21
23
21
23
21
23
23
24
23
24
23
24
24
24
24
24
24
23FD3750A-F
24FD3750A-F
23FD3755A-F
24FD3755A-F
23FD3760A-F
24FD3760A-F
24FD3765A-F
24FD3770A-F
24FD3780A-F
440V
21FB4415A-F
21FB4420A-F
23FB4420A-F
21FB44225A-F
23FB44225A-F
21FB4425A-F
23FB4425A-F
23FB4430A-F
24FB4430A-F
23FB4435A-F
24FB4435A-F
23FB4440A-F
24FB4440A-F
24FB4445A-F
24FB4450A-F
24FB4455A-F
24FB4460A-F
24FB4470A-F
3.84
2.91
3.84
2.91
3.84
2.91
3.91
3.91
4.75
2.38
2.84
2.91
2.84
2.91
3.84
2.91
3.84
2.91
3.84
2.91
3.84
3.91
3.91
3.91
3.91
4.75
4.75
23FD3750-F
24FD3750-F
23FD3755-F
24FD3755-F
23FD3760-F
24FD3760-F
24FD3765-F
24FD3770-F
24FD3780-F
21FB4415-F
21FB4420-F
23FB4420-F
21FB44225-F
23FB44225-F
21FB4425-F
23FB4425-F
23FB4430-F
24FB4430-F
23FB4435-F
24FB4435-F
23FB4440-F
24FB4440-F
24FB4445-F
24FB4450-F
24FB4455-F
24FB4460-F
24FB4470-F
3.75
3.00
3.75
3.00
3.75
3.00
3.75
3.75
4.75
2.63
3.00
3.00
3.00
3.00
3.75
3.00
3.75
3.00
3.75
3.00
3.75
3.75
3.75
3.75
3.75
4.75
4.75
*Steel cases are not for new design. Check parametric search for product availability.
CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8561 • Fax: (508)996-3830
Type MPF, AC Motor Run Capacitors
Oval and Round, Oil Filled, 70 ºC, Metallized Polypropylene Capacitors
Notice and Disclaimer:
All product drawings, descriptions, specifications, statements, information and
data (collectively, the “Information”) in this datasheet or other publication are subject to change. The
customer is responsible for checking, confirming and verifying the extent to which the Information con-
tained in this datasheet or other publication is applicable to an order at the time the order is placed. All
Information given herein is believed to be accurate and reliable, but it is presented without any guaran-
tee, warranty, representation or responsibility of any kind, expressed or implied. Statements of suitability
for certain applications are based on the knowledge that the Cornell Dubilier company providing such
statements (“Cornell Dubilier”) has of operating conditions that such Cornell Dubilier company regards
as typical for such applications, but are not intended to constitute any guarantee, warranty or representa-
tion regarding any such matter – and Cornell Dubilier specifically and expressly disclaims any guarantee,
warranty or representation concerning the suitability for a specific customer application, use, storage,
transportation, or operating environment. The Information is intended for use only by customers who
have the requisite experience and capability to determine the correct products for their application. Any
technical advice inferred from this Information or otherwise provided by Cornell Dubilier with reference
to the use of any Cornell Dubilier products is given gratis (unless otherwise specified by Cornell Dubilier),
and Cornell Dubilier assumes no obligation or liability for the advice given or results obtained. Although
Cornell Dubilier strives to apply the most stringent quality and safety standards regarding the design
and manufacturing of its products, in light of the current state of the art, isolated component failures may
still occur. Accordingly, customer applications which require a high degree of reliability or safety should
employ suitable designs or other safeguards (such as installation of protective circuitry or redundancies
or other appropriate protective measures) in order to ensure that the failure of an electrical component
does not result in a risk of personal injury or property damage. Although all product-related warnings,
cautions and notes must be observed, the customer should not assume that all safety measures are indi-
cated in such warnings, cautions and notes, or that other safety measures may not be required.
Domestic Chip Exchange
京公网安备 11010802033920号
EEWORLD
