BUK9K52-60E_15

Description
Dual N-channel 60 V, 55 m logic level MOSFET
File Size248KB,13 Pages
ManufacturerPhilips Semiconductors (NXP Semiconductors N.V.)
Websitehttps://www.nxp.com/
Download Datasheet View All

BUK9K52-60E_15 Overview

Dual N-channel 60 V, 55 m logic level MOSFET

LFP
AK
56
BUK9K52-60E
24 February 2015
D
Dual N-channel 60 V, 55 mΩ logic level MOSFET
Product data sheet
1. General description
Dual logic level N-channel MOSFET in an LFPAK56D (Dual Power-SO8) package using
TrenchMOS technology. This product has been designed and qualified to AEC Q101
standard for use in high performance automotive applications.
2. Features and benefits
Dual MOSFET
Q101 Compliant
Repetitive avalanche rated
Suitable for thermally demanding environments due to 175 °C rating
True logic level gate with V
GS(th)
rating of greater than 0.5 V at 175 °C
3. Applications
12 V Automotive systems
Motors, lamps and solenoid control
Transmission control
Ultra high performance power switching
4. Quick reference data
Table 1.
Symbol
V
DS
I
D
P
tot
R
DSon
Quick reference data
Parameter
drain-source voltage
drain current
total power dissipation
Conditions
T
j
≥ 25 °C; T
j
≤ 175 °C
V
GS
= 5 V; T
mb
= 25 °C;
Fig. 2
T
mb
= 25 °C;
Fig. 1
V
GS
= 5 V; I
D
= 5 A; T
j
= 25 °C;
Fig. 12
Min
-
-
-
Typ
-
-
-
Max
60
16
32
Unit
V
A
W
Static characteristics FET1 and FET2
drain-source on-state
resistance
gate-drain charge
-
47.3
55
Dynamic characteristics FET1 and FET2
Q
GD
I
D
= 5 A; V
DS
= 48 V; V
GS
= 5 V;
T
j
= 25 °C;
Fig. 14; Fig. 15
-
2.3
-
nC
Scan or click this QR code to view the latest information for this product
