SMD Wire-wound Chip Inductors
ctparts.com
CT1008LS Series
From 1.0 µH to 15 µH
Part
Number
CT1008LS_-102_
CT1008LS_-122_
CT1008LS_-152_
CT1008LS_-182_
CT1008LS_-222_
CT1008LS_-272_
CT1008LS_-332_
CT1008LS_-392_
CT1008LS_-472_
CT1008LS_-562_
CT1008LS_-682_
CT1008LS_-822_
CT1008LS_-103_
CT1008LS_-153_
Not shown at actual size.
SPECIFICATIONS
Please specify tolerance code when ordering.
CT1008LS-122_
J = ±5%, K = ±10%, M = ±20%
CT1008LSF
Please specify “F” for RoHS compliant
Inductance
(µH)
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
15
L Test
Freq.
(MHz)
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
Q
Fact.
Min.
48
48
41
39
34
34
32
32
31
31
31
23
31
35
Q Test
Freq.
(MHz)
50
50
50
50
50
50
50
7.9
7.9
7.9
7.9
7.9
7.9
7.9
SRF
Min.
(MHz)
230
210
190
170
150
135
120
105
90
80
70
65
60
38
DCR
Max.
Ω
(Ω)
0.62
0.68
0.76
0.84
1.10
1.28
1.46
1.56
1.68
1.82
2.00
2.65
2.95
2.40
Rated
DC
(mA)
700
650
630
600
520
490
450
420
400
380
360
330
300
450
PHYSICAL DIMENSIONS
Size
mm
inches
Max.
2.99
0.118
A
Max.
2.79
0.110
B
Max.
2.2
0.087
C
D
0.70
0.028
E
1.52
0.060
F
0.51
0.020
G
2.03
0.080
CHARACTERISTICS
Description:
SMD ferrite core wire-wound chip inductor
Applications:
LC resonant circuits such as oscillator and signal
generators, impedance matching, circuit isolation, RF filters, disk
drives and computer peripherals, audio and video equipment, TV,
radio and telecommunication equipment
Operating Temperature:
-25°C to +85°C
Inductance Tolerance:
±5%, ±10%, ±20%
Testing:
Inductance and Q are tested on an HP4286A at
specified frequency
Packaging:
Tape & Reel, 2,000 parts per reel
Miscellaneous:
RoHS Compliant available.
Marking:
Parts are marked with color dots (nH)
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
C
B
overall
F
A
E
F
D
G
terminal
PAD LAYOUT
2.54
(0.100)
1.02
(0.040)
1.27
(0.050)
1.02
(0.040)
