Protection in Portable Electronics Applications.
PG05UBUL2
Single Line TVS Diode for ESD
Protection in Portable Electronics
FEATURES
・Transient
protection for data lines to
IEC 61000-4-2(ESD) :
±20kV(air/contact)
IEC 61000-4-4(EFT) : 2.5kV/50A
IEC 61000-4-5(Surge) 3A(tp=8/20μ
s)
・Small
package for use in portable electronics.
・Suitable
replacement for Multi-Layer Varistors in ESD
protection applications.
(* Multi-Layer Varistors [0402 Size])
・Protects
on I/O or power line.
・Low
clamping voltage.
・Low
leakage current.
APPLICATIONS
・USB
2.0, 10/100/1000 Ethernet, FireWire, DVI, HDMI, S-ATA
・Mobile
Communication
・Consumer
Products (STB, MP3, DVD, DSC...)
・LCD-Display,
Camera
・Notebooks
and desktop computers, peripherals
MAXIMUM RATING (Ta=25℃)
CHARACTERISTIC
Peak Pulse Power (tp=8/20μ
s)
Peak Pulse Current (tp=8/20μ
s)
Operating Temperature Range
Storage Temperature
SYMBOL
P
PK
I
PP
T
OP
T
stg
RATING
63
3
-55½125
-55½150
UNIT
W
A
℃
℃
ELECTRICAL CHARACTERISTICS (Ta=25℃)
CHARACTERISTIC
Reverse Stand-Off Voltage
Reverse Breakdown Voltage
Reverse Leakage Current
Clamping Voltage
Junction Capacitance
SYMBOL
V
RWM
V
BR
I
R
V
C
C
J
I
t
=1mA
V
RWM
=5.3V
I
PP
=1A, tp=8/20μ
s
I
PP
=3A, tp=8/20μ
s
V
R
=0V, f=1MHz
TEST CONDITION
-
MIN.
5.3
7
-
-
-
-
TYP.
-
-
-
11
14
0.27
MAX.
5.3
-
100
-
V
21
0.4
pF
UNIT
V
V
nA
2010. 6. 7
Revision No : 2
1/3
