PROGRAMMABLE CRYSTAL OSCILLATOR
AP3S
*PB FREE & ROHS COMPLIANT
• Short lead time
• Suitable for mass production
• Alternative to long lead-time XO's
3.2 x 2.5 x 1.1mm
| | | | | | | | | | | | | | |
FEATURES:
• Performance equivalent to fixed frequency oscillator
• Lowest peak-to-peak jitter
• Low supply current
STANDARD SPECIFICATIONS:
3.3V OPERATION (STANDARD)
Characteristics
Frequency Range
Operation Temperature Range
*(See Options)
Frequency Stabilty * (See Options)
Input Voltage (Operating Vdd)
Vdd Sensitivity (±10%)
Supply Current
0.8MHz ≤ Fo ≤ 20MHz
20MHz ≤ Fo ≤ 40MHz
40MHz ≤ Fo ≤ 75MHz
75MHz ≤ Fo ≤ 90MHz
90MHz < Fo
Transition Time : Rise / Fall Time *
Duty Cycle
Output
Output High (Logic "1")
Output Low (Logic "0")
Start Time
Tri-state (Input to Pin 1)
Output Active
Output in High Impedacne State
Absolute Clock Period Jitter
Standby Current
Storage Temp. Range
Unit
MHz
°C
ppm
VDC
ppm
Minimum
0.8
-10
-100
2.97
-2
--
--
--
--
--
--
45
2.97
--
--
0.7
--
--
--
-55
Typical
--
--
--
3.3
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
Maximum
110
60
100
3.63
2
10
15
15
20
25
5.0
55
--
0.33
8
--
0.3
150
10
125
mA
nSec
%
V
V
nSec
V
pSec
µ
A
°C
* Inclusive of calibration @25°C, operating temperature range, input voltage variation, load variation, aging, shock, and vibration.
* Transition times are measured between 10% and 90% of Vdd with an output load of 15 pf.
TEST CIRCUIT:
ABRACON IS
ISO 9001 / QS 9000
CERTIFIED
30332 Esperanza, Rancho Santa Margarita, California 92688
tel 949-546-8000
|
fax 949-546-8001
| www.abracon.com
Revised: 1.1.07
PROGRAMMABLE CRYSTAL OSCILLATOR
AP3S
*PB FREE & ROHS COMPLIANT
3.2 x 2.5 x 1.1mm
| | | | | | | | | | | | | | |
STANDARD SPECIFICATIONS (cont’d):
2.5V OPERATION
Characteristics
Frequency Range
Operation Temperature Range
*(See Options)
Frequency Stabilty * (See Options)
Input Voltage (Operating Vdd)
Vdd Sensitivity (±10%)
Supply Current
0.8MHz ≤ Fo ≤ 20MHz
20MHz ≤ Fo ≤ 40MHz
40MHz ≤ Fo ≤ 75MHz
75MHz ≤ Fo ≤ 90MHz
90MHz < Fo
Transition Time : Rise / Fall Time *
Duty Cycle
Output
Output High (Logic "1")
Output Low (Logic "0")
Start Time
Tri-state (Input to Pin 1)
Output Active
Output in High Impedacne State
Absolute Clock Period Jitter
Standby Current
Storage Temp. Range
1.8V OPERATION
Characteristics
Frequency Range
Operation Temperature Range
*(See Options)
Frequency Stabilty * (See Options)
Input Voltage (Operating Vdd)
Vdd Sensitivity (±10%)
Supply Current
0.8MHz ≤ Fo ≤ 20MHz
20MHz ≤ Fo ≤ 40MHz
40MHz ≤ Fo ≤ 75MHz
75MHz ≤ Fo ≤ 90MHz
90MHz < Fo
Transition Time : Rise / Fall Time *
Duty Cycle
Output
Output High (Logic "1")
Output Low (Logic "0")
Start Time
Tri-state (Input to Pin 1)
Output Active
Output in High Impedacne State
Absolute Clock Period Jitter
Standby Current
Storage Temp. Range
ABRACON IS
ISO 9001 / QS 9000
CERTIFIED
Unit
MHz
°C
ppm
VDC
ppm
Minimum
0.8
-10
-100
2.25
-2
--
--
--
--
--
--
45
2.25
--
--
0.7
--
--
--
-55
Typical
--
--
--
2.5
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
Maximum
90
60
100
2.75
2
8
10
10
15
--
5.0
55
--
0.25
8
--
0.3
150
10
125
mA
nSec
%
V
V
nSec
V
pSec
µ
A
°C
Unit
MHz
°C
ppm
VDC
ppm
Minimum
0.8
-10
-100
1.62
-2
--
--
--
--
--
--
45
1.62
--
--
0.7
--
--
--
-55
Typical
--
--
--
1.8
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
Maximum
75
60
100
1.98
2
6
7
10
--
--
5.0
55
--
0.18
8
--
0.3
150
10
125
mA
nSec
%
V
V
nSec
V
pSec
µ
A
°C
30332 Esperanza, Rancho Santa Margarita, California 92688
tel 949-546-8000
|
fax 949-546-8001
| www.abracon.com
Revised: 1.1.07
PROGRAMMABLE CRYSTAL OSCILLATOR
AP3S
*PB FREE & ROHS COMPLIANT
3.2 x 2.5 x 1.1mm
| | | | | | | | | | | | | | |
STANDARD SPECIFICATIONS (cont’d):
* Inclusive of calibration @25°C, operating temperature range, input voltage variation, load variation, aging, shock, and vibration.
* Transition times are measured between 10% and 90% of Vdd with an output load of 15 pf.
MARKING:
Frequency "XXX.X" or
Blank for unprogrammed
AZY
Year : e.g. 6 for 2006
Month : A to Z
Month
January
February
March
April
May
June
Code
A
B
C
D
E
F
Month
July
August
September
October
November
December
Code
G
H
I
J
K
L
OPTIONS AND PART IDENTIFICATION
(Left blank if standard)
:
AP3SX-Frequency-XX-X
Frequency Stability
Over Operating Temp.
-20°C to +70°C
± 20 ppm
EJ
-20°C to +70°C
± 25 ppm
ER
-20°C to +70°C
± 50 ppm
EC
LJ*
-40°C to +85°C
± 20 ppm
-40°C to +85°C
± 25 ppm
LR
-40°C to +85°C
± 50 ppm
LC
*EJ : Please ask availability.
Supply Voltage
Blank*
3.3 V
1
2.5 V
2
1.8 V
*3.3V : Standard
Packaging
Bulk
B
T
Tape and Reel
*Ask for Tube Package
OUTLINE DRAWING:
PIN
1
2
3
4
FUNCTION
Tristate
Ground
Output
Vdd
Dimensions: inch (mm)
ABRACON IS
ISO 9001 / QS 9000
CERTIFIED
30332 Esperanza, Rancho Santa Margarita, California 92688
tel 949-546-8000
|
fax 949-546-8001
| www.abracon.com
Revised: 1.1.07
