PRODUCT SPECIFICATION
Series Number
PLBT5730
Details
•
•
•
•
Thin 0.90mm SMD
120° viewing angle.
Emitting color: Cool White,
Natural White, Warm White
InGaN dice used
Features
•
•
Low thermal resistance, Even heat
dissipation
RoHS Compliant
Mechanical Dimensions
Notes:
1. Dimension in millimeter [inch], and tolerance is ±0.1mm unless otherwise noted.
www.p-tec.net
04.07.15 Rev1 JAS
Page 1 of 9
Device Selection Guide
Model Number
PLBT5730-YDCW
PLBT5730-YDNW
PLBT5730-YDWW
Chip
Material
InGaN
Emitting Color
Cool White
Natural White
Warm White
Absolute Maximum Ratings at Ta=25°C
Parameter
Power Dissipation
Continuous Forward Current
Pulse Forward Current
Reverse Voltage
Operating Temperature
Storage Temperature
Junction Temperature
Solder Temperature
Electrical and Optical Characteristics at Ta=25°C
Parameter
Forward Voltage
Luminous Flux
Color Rendering Index
Reverse Current
Color Temperature
Viewing Angle
Thermal Resistance
Antistatic ability
Notes:
1.(LM) ±10%Luminous Flux (LM)10%
2.VF ±0.1 Forward Voltage(VF)±0.1V
3.(X,Y)±0.01 Wavelength(X,Y)±0.01 (CCT±5%)
4.(CRI)±0.2 Color Rendering Index(CRI)±2
5.(2θ1/2)±5 Viewing angle(2θ1/2)±5
Symbol
P
D
I
F
I
FP
Vr
Topr
Tstg
Tj
Ts
Rating
270
200
1000
5
-30~+85
-40~+100
110
260 for 10sec
Unit
mW
mA
mA
V
°C
°C
°C
°C
Symbol
VF
Φ
v
CRI
IR
CCT
2θ1/2
Rθjs
ESD
Min.
2.8
45
70
--
2965
--
Typ.
3.2
55
--
--
4000
120°
45
HBM
MM
Max.
3.4
65
90
10
6530
--
Unit
V
Lm
nm
μA
°K
Deg
°C/W
-4000V
-3000V
Condition
IF=150mA
IF=150mA
IF=150mA
VR=5V
IF=150mA
IF=150mA
IF=150mA
www.p-tec.net
04.07.15 Rev1 JAS
Page 2 of 9
