SFS0863C-LF Overview

Fixed Frequency Synthesizer Surface Mount Module

Preview

Download Datasheet

View All

SFS0863C-LF

Rev A1

Fixed Frequency Synthesizer

Surface Mount Module

Applications

• Basestations

• Test Instrumentation

•

Application Notes

• AN-107: Manual Soldering Technique

• AN-205: Measuring Phase Noise for SFS Series

Performance Specifications

Frequency

Phase Noise @ 10 kHz offset (1 Hz BW)

Harmonic Suppression (2nd)

Spurious Suppression

Power Output

Load Impedance

Settling Time

Operating Temperature Range

Package Style

Min

863.5

Typ

-118

-15

-70

Max

863.5

Units

MHz

dBc/Hz

dBc

-2

dBm

-40

PLL-V12C

°C

Power Supply Requirements

Supply Voltage 1: PLL (Vcc, nom)

Supply Voltage 2: VCO (Vcc, nom)

Supply Current 1: PLL (Icc, typ)

Supply Current 2: VCO (Icc, typ)

Min

3.0

4.80

Typ

Max

3.5

5.15

Units

Vdc

Reference Oscillator Signal

Frequency

Phase Noise @1 kHz Offset

Min

Typ

-145

Max

Units

MHz

dBc/Hz

Additional Notes

LFSuffix = RoHS Compliant. All specifications are subject to change without notice.

14118 Stowe Drive, Suite B | Poway, CA 92064 | TEL: (858) 621-2700 | FAX: (858) 486-1927

URL: www.zcomm.com | EMAIL: applications@zcomm.com

Page 1 of 2

FRM-S-002 B
