PDS835L
Green
8A LOW VF SCHOTTKY BARRIER RECTIFIER
POWERDI
®
Features
•
•
•
•
•
•
•
Guard Ring Die Construction for Transient Protection
Low Forward Voltage Drop
For Use in Low Voltage, High Frequency Inverters, Free
Wheeling, and Polarity Protection Applications
High Forward Surge Current Capability
Lead-Free Finish; RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
Qualified to AEC-Q101 Standards for High Reliability
Mechanical Data
•
•
•
•
•
•
Case: POWERDI5
Case Material: Molded Plastic, “Green” Molding Compound. UL
Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminals: Finish – Matte Tin annealed over Copper leadframe.
Solderable per MIL-STD-202, Method 208
Polarity: See Diagram
Weight: 0.094 grams (approximate)
POWERDI5
LEFT PIN
RIGHT PIN
BOTTOMSIDE
HEAT SINK
Top View
Bottom View
Note: Pins Left & Right must
be electrically connected
at the printed circuit board.
Ordering Information
(Note 4)
Part Number
PDS835L-13
PDS835L-7
Notes:
Case
POWERDI5
POWERDI5
Packaging
5000/Tape & Reel
1500/Tape & Reel
1. EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant. All applicable RoHS exemptions applied.
2. See http://www.diodes.com for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green" and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. For packaging details, go to our website at http://www.diodes.com.
Marking Information
S835L
YYWWK
S835L = Product type marking code
= Manufacturers’ code marking
YYWW = Date code marking
YY = Last two digits of year (ex: 04 for 2004)
WW = Week code (01 - 53)
K = Factory Designator
POWERDI is a registered trademark of Diodes Incorporated.
PDS835L
Document number: DS30488 Rev. 11 - 2
1 of 5
www.diodes.com
October 2012
© Diodes Incorporated
PDS835L
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
RMS Reverse Voltage
Average Rectified Output Current (See also figure 5)
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
Symbol
V
RRM
V
RWM
V
R
V
R(RMS)
I
O
I
FSM
Value
35
25
8
120
Unit
V
V
A
A
Thermal Characteristics
Characteristic
Thermal Resistance Junction to Soldering Point
Thermal Resistance Junction to Ambient Air (Note 5) T
A
= +25°C
Thermal Resistance Junction to Ambient Air (Note 6) T
A
= +25°C
Thermal Resistance Junction to Ambient Air (Note 7) T
A
= +25°C
Operating Temperature Range
Storage Temperature Range
Symbol
R
θ
JS
R
θ
JA
R
θ
JA
R
θ
JA
T
J
T
STG
Typ
⎯
100
65
45
-65 to +125
-65 to +150
Max
3.0
⎯
⎯
⎯
Unit
°C/W
°C/W
°C/W
°C/W
°C
°C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Reverse Breakdown Voltage (Note 8)
Forward Voltage
Reverse Leakage Current (Note 8)
Notes:
Symbol
V
(BR)R
V
F
I
R
Min
35
⎯
⎯
⎯
⎯
Typ
⎯
0.46
⎯
0.05
7
Max
⎯
0.51
0.41
1.4
35
Unit
V
V
mA
Test Condition
I
R
= 1mA
I
F
= 8A, T
S
= +25°C
I
F
= 8A, T
S
= +125°C
T
S
= +25°C, V
R
= 35V
T
S
= +100°C, V
R
= 35V
5. FR-4 PCB, 2 oz. Copper, minimum recommended pad layout per http://www.diodes.com
6. Polymide PCB, 2 oz. Copper, minimum recommended pad layout per http://www.diodes.com.
7. Polymide PCB, 2 oz. Copper. Cathode pad dimensions 9.4mm x 7.2mm. Anode pad dimensions 2.7mm x 1.6mm.
8. Short duration pulse test used to minimize self-heating effect.
POWERDI is a registered trademark of Diodes Incorporated.
PDS835L
Document number: DS30488 Rev. 11 - 2
2 of 5
www.diodes.com
October 2012
© Diodes Incorporated
PDS835L
3
2
1
0
0
1
3
5
7
8
4
6
9 10
2
I
F(AV)
, AVERAGE FORWARD CURRENT (A)
Fig. 1 Forward Power Dissipation
I
F
, INSTANTANEOUS FORWARD CURRENT (A)
4
P
D
, POWER DISSIPATION (W)
0
0.1 0.2 0.3 0.4
0.5
V
F
, INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 2 Typical Forward Characteristics
10
1
0.1
0.01
0.001
0.0001
20
25
30
5
10
15
0
35
V
R
, INSTANTANEOUS REVERSE VOLTAGE (V)
Fig. 3 Typical Reverse Characteristics
I
R
, INSTANTANEOUS REVERSE CURRENT (mA)
100
0
5
10
15
20
30
25
35
V
R
, INSTANTANEOUS REVERSE VOLTAGE (V)
Fig. 4 Typical Reverse Characteristics
10
I
F(AV)
, AVERAGE FORWARD CURRENT (A)
C
T
, TOTAL CAPACITANCE (pF)
8
6
4
Note 9
2
Note 5
0
0
V
R
, DC REVERSE VOLTAGE (V)
Fig. 5 Total Capacitance vs. Reverse Voltage
25
75
100
125
50
T
A
, AMBIENT TEMPERATURE (°C)
Fig. 6 Forward Current Derating Curve
150
POWERDI is a registered trademark of Diodes Incorporated.
PDS835L
Document number: DS30488 Rev. 11 - 2
3 of 5
www.diodes.com
October 2012
© Diodes Incorporated
PDS835L
150
T
A
, DERATED AMBIENT TEMPERATURE (°C)
Note 5
120
90
60
30
0
0
10
20
25
30
15
V
R
, DC REVERSE VOLTAGE (V)
Fig. 7 Operating Temperature Derating
5
35
Notes:
9. Polymide PCB, 2 oz. Copper. Cathode pad dimensions 18.8mm x 14.4mm. Anode pad dimensions 5.6mm x 3.0mm.
Package Outline Dimensions
Please see AP02002 at http://www.diodes.com/datasheets/ap02002.pdf for latest version.
A
D
b2
A2
D2
L
E
E1
E2
W
L1
e
b1
b1
A2
POWERDI5
Dim
Min
Max
A
1.05
1.15
A2
0.33
0.43
b1
0.80
0.99
b2
1.70
1.88
D
3.90
4.05
D2
3.054 Typ
E
6.40
6.60
e
1.84 Typ
E1
5.30
5.45
E2
3.549 Typ
L
0.75
0.95
L1
0.50
0.65
W
1.10
1.41
All Dimensions in mm
Suggested Pad Layout
Please see AP02001 at http://www.diodes.com/datasheets/ap02001.pdf for the latest version.
X
Y
X1
(2x)
Y1
(2x)
C
G
Dimensions
C
G
X
X1
Y
Y1
Value (in mm)
1.840
0.852
3.360
1.390
4.860
1.400
POWERDI is a registered trademark of Diodes Incorporated.
PDS835L
Document number: DS30488 Rev. 11 - 2
4 of 5
www.diodes.com
October 2012
© Diodes Incorporated
PDS835L
