SBL3040CTP
30A SCHOTTKY BARRIER RECTIFIER
Features
•
•
•
•
•
Low Forward Voltage Drop
Soft, Fast Switching Capability
Schottky Barrier Chip
ITO-220S Heat Sink Tab Electrically Isolated from Cathode
UL Approval in Accordance with UL 1557, Reference No.
E94661
Mechanical Data
•
•
•
•
Case: ITO-220S
Case Material: Molded Plastic, UL Flammability Classification
Rating 94V-0
Terminals: Matte Tin Finish annealed over Copper leadframe.
Solderable per MIL-STD-202, Method 208
Weight: 1.335 grams (approximate)
4 Isolated
2
Common
1 Cathode 3
Anode
Anode
Top View
Bottom View
Package Pin Out
Configuration
Ordering Information
(Notes 1 & 2)
Part Number
SBL3040CTP
SBL3040CTP-G
Notes:
Case
ITO-220S
ITO-220S
Packaging
50 pieces/tube
50 pieces/tube
1. For packaging details, go to our website at http://www.diodes.com.
2. For Green Molding compound version part number, add “-G” suffix to part number. Example: SBL3040CTP-G.
Marking Information
SBL
3040CTP
YYWW AB
SBL3040CTP = Product Type Marking Code
AB = Foundry and Assembly Code
YYWW = Date Code Marking
YY = Last two digits of year (ex: 08 = 2008)
WW = Week (01 - 53)
SBL3040CTP
Document number: DS31462 Rev. 6 - 2
1 of 4
www.diodes.com
April 2011
© Diodes Incorporated
SBL3040CTP
Maximum Ratings (Per Leg)
@T
A
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
(Per Leg)
Average Rectified Output Current
(Total)
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
Isolation Voltage
From Terminal Heatsink t = 1 min.
Symbol
V
RRM
V
RWM
V
RM
I
O
I
FSM
V
AC
Value
40
15
30
230
2000
Unit
V
A
A
V
Thermal Characteristics (Per Leg)
Characteristic
Typical Thermal Resistance Junction to Case
Operating and Storage Temperature Range
Symbol
R
θ
JC
T
J
, T
STG
Value
3
-65 to +150
Unit
°C/W
ºC
Electrical Characteristics (Per Leg)
@T
A
= 25°C unless otherwise specified
Characteristic
Forward Voltage Drop
Leakage Current (Note 3)
Notes:
3. Short duration pulse test used to minimize self-heating effect.
Symbol
V
F
I
R
Min
-
-
-
Typ
-
0.15
-
Max
0.60
1
75
Unit
V
mA
Test Condition
I
F
= 15A, T
J
= 25ºC
V
R
= 40V, T
J
= 25ºC
V
R
= 40V, T
J
= 100ºC
I
F
, INSTANTANEOUS FORWARD CURRENT (A)
I
R
, INSTANTANEOUS REVERSE CURRENT (µA)
100
1,000,000
100,000
T
A
= 150°C
T
A
= 125°C
10
T
A
= 150°C
T
A
= 125°C
10,000
1
T
A
= 85°C
T
A
= 85°C
1,000
T
A
= 25°C
T
A
= -55°C
100
T
A
= 25°C
0.1
10
0.01
0
200
400
600
800
V
F
, INSTANTANEOUS FORWARD VOLTAGE (mV)
Fig. 1 Typical Forward Characteristics
1
0
10
20
30
40
V
R
, INSTANTANEOUS REVERSE VOLTAGE (V)
Fig. 2 Typical Reverse Characteristics
SBL3040CTP
Document number: DS31462 Rev. 6 - 2
2 of 4
www.diodes.com
April 2011
© Diodes Incorporated
SBL3040CTP
