DFLS2100Q-7: Description2 A, 100 V, SILICON, RECTIFIER DIODE; Categorysemiconductor Discrete semiconductor; File Size195KB，5 Pages; ManufacturerDiodes; Websitehttp://www.diodes.com/

Download Datasheet Parametric Compare View All

DFLS2100Q-7 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	DFLS2100Q-7	-	-	View	Buy Now

DFLS2100Q-7 Overview

2 A, 100 V, SILICON, RECTIFIER DIODE

DFLS2100Q-7 Parametric

Parameter Name	Attribute value
Number of terminals	2
Number of components	1
Processing package description	GREEN, PLASTIC, POWERDI123, 2 PIN
Lead-free	Yes
EU RoHS regulations	Yes
state	ACTIVE
packaging shape	RECTANGULAR
Package Size	SMALL OUTLINE
surface mount	Yes
Terminal form	FLAT
terminal coating	MATTE TIN
Terminal location	DUAL
Packaging Materials	PLASTIC/EPOXY
Craftsmanship	SCHOTTKY
structure	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
application	GENERAL PURPOSE
Phase	1
Maximum repetitive peak reverse voltage	100 V
Maximum average forward current	2 A
Maximum non-repetitive peak forward current	40 A

Preview

Download Datasheet

View All

Green

DFLS2100

2.0A HIGH VOLTAGE SCHOTTKY BARRIER RECTIFIER

Product Summary

RRM

(V)

100

(A)

2.0

F(MAX)

(V) @+25°C

0.86

R(MAX)

(µA) @+25°C

Features and Benefits

•

Low Forward Voltage (V

) Minimizes Conduction Losses and

Improving Efficiency

Reduced High Temperature Reverse Leakage; Increased

Reliability against Thermal Runaway Failure in High Temperature

Operation

Patented Interlocking Clip Design for High Surge Current Capacity

Lead-Free Finish; RoHS Compliant (Notes 1 & 2)

Halogen and Antimony Free. “Green” Device (Note 3)

Qualified to AEC-Q101 Standards for High Reliability

An Automotive–Compliant Part is Available Under Separate

Datasheet (DFLS2100Q)

•

Description and Applications

The device is a single rectifier packaged in PowerDI123. Offering

low V

and excellent high temperature stability this device is ideal for

use in general rectification applications as a:

•

Boost Diode

Reverse Protection Diode

Blocking Diode

•

Mechanical Data

•

Case: PowerDI123

Case Material: Molded Plastic, “Green” Molding Compound. UL

Flammability Classification Rating 94V-0

Moisture Sensitivity: Level 1 per J-STD-020

Terminal Connections: Cathode Band

Terminals: Finish – Matte Tin Annealed over Copper Leadframe.

Solderable per MIL-STD-202, Method 208

Weight: 0.01 grams (Approximate)

PowerDI123

Top View

Ordering Information

(Note 4)

Part Number

DFLS2100-7

Notes:

Case

PowerDI123

Packaging

3000/Tape & Reel

1. EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant. All applicable RoHS exemptions applied.

2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"

and Lead-free.

3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and

<1000ppm antimony compounds.

4. For packaging details, go to our website at http://www.diodes.com/products/packages.html.

Marking Information

F09A = Product Type Marking Code

YM = Date Code Marking

Y = Year (ex: D = 2016)

M = Month (ex: 9 = September)

F09A

Date Code Key

Year

Code

Month

Code

2016

Jan

2017

Feb

2018

Mar

2019

Apr

2020

May

Jun

2021

Jul

2022

Aug

2023

Sep

2024

Oct

2025

Nov

2026

Dec

POWERDI is a registered trademark of Diodes Incorporated.

DFLS2100

Document number: DS31475 Rev. 4 - 2

1 of 5

www.diodes.com

April 2016

DFLS2100

IMPORTANT NOTICE

DIODES INCORPORATED MAKES NO WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, WITH REGARDS TO THIS DOCUMENT,

INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE

(AND THEIR EQUIVALENTS UNDER THE LAWS OF ANY JURISDICTION).

Diodes Incorporated and its subsidiaries reserve the right to make modifications, enhancements, improvements, corrections or other changes

without further notice to this document and any product described herein. Diodes Incorporated does not assume any liability arising out of the

application or use of this document or any product described herein; neither does Diodes Incorporated convey any license under its patent or

trademark rights, nor the rights of others. Any Customer or user of this document or products described herein in such applications shall assume

all risks of such use and will agree to hold Diodes Incorporated and all the companies whose products are represented on Diodes Incorporated

website, harmless against all damages.

Diodes Incorporated does not warrant or accept any liability whatsoever in respect of any products purchased through unauthorized sales channel.

Should Customers purchase or use Diodes Incorporated products for any unintended or unauthorized application, Customers shall indemnify and

hold Diodes Incorporated and its representatives harmless against all claims, damages, expenses, and attorney fees arising out of, directly or

indirectly, any claim of personal injury or death associated with such unintended or unauthorized application.

Products described herein may be covered by one or more United States, international or foreign patents pending. Product names and markings

noted herein may also be covered by one or more United States, international or foreign trademarks.

This document is written in English but may be translated into multiple languages for reference. Only the English version of this document is the

final and determinative format released by Diodes Incorporated.

LIFE SUPPORT

Diodes Incorporated products are specifically not authorized for use as critical components in life support devices or systems without the express

written approval of the Chief Executive Officer of Diodes Incorporated. As used herein:

A. Life support devices or systems are devices or systems which:

1. are intended to implant into the body, or

2. support or sustain life and whose failure to perform when properly used in accordance with instructions for use provided in the

labeling can be reasonably expected to result in significant injury to the user.

B. A critical component is any component in a life support device or system whose failure to perform can be reasonably expected to cause the

failure of the life support device or to affect its safety or effectiveness.

Customers represent that they have all necessary expertise in the safety and regulatory ramifications of their life support devices or systems, and

acknowledge and agree that they are solely responsible for all legal, regulatory and safety-related requirements concerning their products and any

use of Diodes Incorporated products in such safety-critical, life support devices or systems, notwithstanding any devices- or systems-related

information or support that may be provided by Diodes Incorporated. Further, Customers must fully indemnify Diodes Incorporated and its

representatives against any damages arising out of the use of Diodes Incorporated products in such safety-critical, life support devices or systems.

www.diodes.com

POWERDI is a registered trademark of Diodes Incorporated.

DFLS2100

Document number: DS31475 Rev. 4 - 2

5 of 5

www.diodes.com

April 2016
