DPLS350E
LOW V
CE(SAT)
PNP SURFACE MOUNT TRANSISTOR
Please click here to visit our online spice models database.
Features
•
•
•
•
•
Epitaxial Planar Die Construction
Ideally Suited for Automated Assembly Processes
Ideal for Medium Power Switching or Amplification Applications
Lead Free By Design/RoHS Compliant (Note 1)
"Green" Device (Note 2)
Mechanical Data
•
•
•
•
•
•
•
COLLECTOR
2,4
Case: SOT-223
Case Material: Molded Plastic, "Green” Molding Compound.
UL Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020D
Terminals: Finish — Matte Tin annealed over Copper leadframe
(Lead Free Plating). Solderable per MIL-STD-202, Method 208
Marking Information: See Page 4
Ordering Information: See Page 4
Weight: 0.115 grams (approximate)
3 E
C 4
2 C
1 B
Pin Out Configuration
1
BASE
3
EMITTER
Top View
Device Schematic
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Symbol
V
CBO
V
CEO
V
EBO
I
CM
I
C
I
B
Value
-60
-50
-6
-5
-3
-1
Unit
V
V
V
A
A
A
Characteristic
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Peak Pulse Current
Continuous Collector Current
Base Current
Thermal Characteristics
Characteristic
Power Dissipation (Note 3) @ T
A
= 25°C
Thermal Resistance, Junction to Ambient Air (Note 3) @ T
A
= 25°C
Operating and Storage Temperature Range
Notes:
Symbol
P
D
R
θ
JA
T
J
, T
STG
Value
1
125
-55 to +150
Unit
W
°C/W
°C
1. No purposefully added lead.
2. Diodes Inc.'s "Green" policy can be found on our website at http://www.diodes.com/products/lead_free/index.php.
3. Device mounted on FR-4 PCB; pad layout as shown on page 4 or in Diodes Inc. suggested pad layout document AP02001, which can
be found on our website at http://www.diodes.com/datasheets/ap02001.pdf.
DPLS350E
Document number: DS31230 Rev. 4 - 2
1 of 5
www.diodes.com
April 2009
© Diodes Incorporated
DPLS350E
Electrical Characteristics
Characteristic
OFF CHARACTERISTICS (Note 4)
Collector-Base Cutoff Current
Emitter-Base Cutoff Current
Collector-Base Breakdown Voltage
Collector-Emitter Breakdown Voltage
Emitter-Base Breakdown Voltage
ON CHARACTERISTICS (Note 4)
DC Current Gain
@T
A
= 25°C unless otherwise specified
Symbol
I
CBO
I
EBO
V
(BR)CBO
V
(BR)CEO
V
(BR)EBO
Min
⎯
⎯
⎯
-50
-50
-5
200
200
100
⎯
⎯
⎯
⎯
⎯
⎯
100
⎯
Typ
⎯
⎯
⎯
⎯
⎯
⎯
⎯
⎯
⎯
⎯
⎯
⎯
67
⎯
⎯
⎯
⎯
Max
-100
-50
-100
⎯
⎯
⎯
⎯
⎯
⎯
-100
-180
-300
150
-1.2
-1.1
⎯
40
Unit
nA
μA
nA
V
V
V
Test Conditions
V
CB
= -50V, I
E
= 0
V
CB
= -50V, I
E
= 0, T
A
= 150°C
V
EB
= -5V, I
C
= 0
I
C
= -100μA
I
C
= -10mA
I
E
= -100μA
V
CE
= -2V, I
C
= -0.5A
V
CE
= -2V, I
C
= -1A
V
CE
= -2V, I
C
= -2A
I
C
= -0.5A, I
B
= -50mA
I
C
= -1A, I
B
= -50mA
I
C
= -2A, I
B
= -200mA
I
E
= -2A, I
B
= -200mA
I
C
= -2A, I
B
= -200mA
V
CE
= -2V, I
C
= -1A
V
CE
= -5V, I
C
= -100mA,
f = 100MHz
V
CB
= -10V, f = 1MHz
h
FE
⎯
Collector-Emitter Saturation Voltage
Equivalent On-Resistance
Base-Emitter Saturation Voltage
Base-Emitter Turn-on Voltage
SMALL SIGNAL CHARACTERISTICS
Transition Frequency
Output Capacitance
Notes:
V
CE(SAT)
R
CE(SAT)
V
BE(SAT)
V
BE(ON)
f
T
C
obo
mV
mΩ
V
V
MHz
pF
4. Measured under pulsed conditions. Pulse width = 300μs. Duty cycle
≤2%.
1.2
I
B
= -10mA
-I
C
, COLLECTOR CURRENT (A)
P
D
, POWER DISSIPATION (W)
1.0
I
B
= -8mA
0.8
I
B
= -6mA
0.6
I
B
= -4mA
0.4
I
B
= -2mA
0.2
25
50
75
100
125
150 175
T
A
, AMBIENT TEMPERATURE (°C)
Fig. 1 Power Dissipation vs. Ambient Temperature (Note 3)
0
0
1
2
3
4
5
-V
CE
, COLLECTOR-EMITTER VOLTAGE (V)
Fig. 2 Typical Collector Current vs.Collector-Emitter Voltage
0
DPLS350E
Document number: DS31230 Rev. 4 - 2
2 of 5
www.diodes.com
April 2009
© Diodes Incorporated
DPLS350E
0.3
V
CE
= -2V
I
C
/I
B
= 10
TA = 150°C
-V
CE(SAT)
, COLLECTOR-EMITTER
SATURATION VOLTAGE (V)
h
FE
, DC CURRENT GAIN
TA = 85°C
0.2
TA = 25°C
0.1
T A = 150°C
TA = 85°C
T A = 25°C
TA = -55°C
TA = -55°C
0
0.0001
-I
C
, COLLECTOR CURRENT (A)
Fig. 3 Typical DC Current Gain
vs. Collector Current
-V
BE(ON)
, BASE-EMITTER TURN-ON VOLTAGE (V)
-V
BE(SAT)
, BASE-EMITTER SATURATION VOLTAGE (V)
0.001
0.01
0.1
1
10
-I
C
, COLLECTOR CURRENT (A)
Fig. 4 Typical Collector-Emitter Saturation Voltage
vs. Collector Current
V
CE
= -2V
I
C
/I
B
= 10
TA = -55°C
TA = -55°C
TA = 25°C
TA = 25°C
T A = 85°C
TA = 85°C
TA = 150°C
T A = 150°C
-I
C
, COLLECTOR CURRENT (A)
Fig. 5 Typical Base-Emitter Turn-On Voltage
vs. Collector Current
-I
C
, COLLECTOR CURRENT (A)
Fig. 6 Typical Base-Emitter Saturation Voltage
vs. Collector Current
240
f
T
, GAIN-BANDWIDTH PRODUCT (MHz)
210
180
150
120
90
60
V
CE
= -5V
f = 100MHz
C
obo
, OUTPUT CAPACITANCE (pF)
f = 1MHz
30
0
V
R
, REVERSE VOLTAGE (V)
Fig. 7 Typical Output Capacitance Characteristics
-I
C
, COLLECTOR CURRENT (mA)
Fig. 8 Typical Gain-Bandwidth Product vs. Collector Current
DPLS350E
Document number: DS31230 Rev. 4 - 2
3 of 5
www.diodes.com
April 2009
© Diodes Incorporated
DPLS350E
Ordering Information
Part Number
DPLS350E-13
Notes:
(Note 5)
Case
SOT-223
Packaging
2500/Tape & Reel
5. For packaging details, go to our website at http://www.diodes.com/datasheets/ap02007.pdf.
Marking Information
P35 = Product Type Marking Code
= Manufacturer’s Code Marking
YWW = Date Code Marking
Y = Last digit of year (ex: 7 = 2007)
WW = Week code 01 - 52
YWW
P35
Package Outline Dimensions
A
A1
SOT-223
Dim Min Max Typ
A
1.55 1.65 1.60
A1
0.010 0.15 0.05
b1
2.90 3.10 3.00
b2
0.60 0.80 0.70
C
0.20 0.30 0.25
D
6.45 6.55 6.50
E
3.45 3.55 3.50
E1
6.90 7.10 7.00
e
—
—
4.60
e1
—
—
2.30
L
0.85 1.05 0.95
Q
0.84 0.94 0.89
All Dimensions in mm
Suggested Pad Layout
X1
Y1
C1
Y2
C2
X2
Dimensions
X1
X2
Y1
Y2
C1
C2
Value (in mm)
3.3
1.2
1.6
1.6
6.4
2.3
DPLS350E
Document number: DS31230 Rev. 4 - 2
4 of 5
www.diodes.com
April 2009
© Diodes Incorporated
